2013 VOLKSWAGEN CC tires

– Mirror adjust
Individually
Both mirrors
Back
– Factory setting
– Back
▪ Lights & Vision
– Coming Home
– Leaving Home
– Footwell light
– Conv. turn sig. (convenience turn signal)
– Factory setting
– Back
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
– Back
▪ Snow tires (winter tires)
– On
– + 5 mph
– - 5 mph
– Back
▪ Compass (vehicles without navigation system)
– Zone
– Calibrate
– Back
▪ Units
– Temperature
– Consump./dist.
– Air pressure
– Back
▪ Service

Menu Function See
Vehicle
status
Current warning and information
messages.
This menu item is only displayed
when warning or information
messages are available. The
number of available messages is
shown in the display. Example:
1/1 or 2/2.

Settings Includes the Convenience and
Lights & Vision submenus, as
well as many settings such as
time, speed warning for winter
tires, language, and units.

MFI menu (Multi-Function Indicator)

Settings
menu
Function
Lights &
Vision
Vehicle lighting settings
Time Set hours and minutes for the instrument cluster
clock, the Radio & Navigation System clock, and the
analog clock. The digital clocks can be set to show
the time in 12 or 24 hour format, and can also be set
to daylight savings time.
Snow tires Set up a visual and acoustic speed warning. Use the
feature only when winter tires are installed that have
a speed rating less than top vehicle speed.
Compass Calibrate the compass on vehicles without a factory-
installed navigation system. To calibrate, follow the
instructions in the instrument cluster display
Units Set the units in which temperature, fuel consumption,
and distances should be displayed (for example,
whether to show distance driven in miles or kilome-
ters).
Service View the service reminder display
Factory
setting
Reset the functions in the Settings menu back to the
factory settings.

Lights & Vision submenu

d For gasoline engines: Is unleaded fuel with the right octane rating
readily available?
d Are engine oil (⇒ Engine oil) and other operating fluids that meet
Volkswagen quality and performance requirements available where
you will be driving? For more information, please see
⇒ Booklet Warranty and Maintenance.
d Does the factory-installed navigation system work in the countries
where you will be driving, and is navigation data available?
d Are special or heavy-duty tires necessary for the kind of driving
expected?
NOTICE
Volkswagen is not responsible for mechanical damage that may
result from substandard fuel or service or the unavailability of
Genuine Volkswagen parts.
Driving through water on roads

Tire inflation pressure label
A tire inflation pressure label is on the driver door jamb ⇒ Tires and
wheels.
Fuel grade sticker
An information sticker listing the correct fuel grade for your vehicle ⇒ 
Refueling.
Engine data

Secure luggage in the luggage compartment using suitable straps
and the tie downs ⇒ Tie-downs. Also see ⇒  Luggage compartment.
Adjust the headlight range, if necessary ⇒  Lights.
Check the pressure in all 4 tires when the tires are still cold. Never
reduce air pressure in warm tires to match cold tire inflation pressure.
Heed the information on the tire pressure label ⇒  Tires and wheels.
Pay especially close attention to your vehicle's Tire Pressure Moni-
toring System when driving with a heavy load ⇒ Tire Pressure Moni-
toring System (TPMS).
NOTICE
Wires in the rear windows such as for heating or for an antenna
can be damaged by objects that rub against them.
Please review the information on loading a trailer⇒ Trailer towing
and a roof rack ⇒  Roof rack.
Driving with an open luggage compartment lid

Combined towing weight
Combined towing weight is the weight of the loaded towing vehicle
plus the weight of the loaded trailer.
This vehicle has not been designed to tow a Class II trailer and must
never be retrofitted to tow a Class II trailer. Always make sure that
your vehicle has been designed to tow the trailer you want to use and
that it is legal to tow the trailer where you will be driving.
Loading the trailer
The weight distribution in the vehicle and trailer must be balanced.
Use the maximum permissible tongue weight and make sure that the
load in the trailer is evenly distributed and that it is not front-heavy or
tail-heavy:
Distribute the load in the trailer so that heavy objects are directly
above the axle or as close as possible to the axle.
Secure loads properly on the trailer.
Tire pressure
Always follow the trailer manufacturer's tire pressure recommenda-
tions for the trailer tires.
When towing, inflate the towing vehicle's tires to the maximum per-
missible pressure listed on the tire pressure label ⇒ Tire inflation
pressure.
WARNING
Exceeding the gross weight ratings for axle, tongue, vehicle,
trailer or combined weight can cause accidents and serious
personal injury.
Never exceed the specified values.
Never let the actual weights at the front and rear axles exceed
the Gross Axle Weight Rating. Never let the combined front and
rear weights exceed the Gross Vehicle Weight Rating.

Tires and wheels
