2013 TOYOTA xB sensor

51
1-3. Adjustable components (s
eats, mirrors, steering wheel)
1
Before driving
Scion_xB_OM_OM12G05U_(U)
CAUTION
Observe the following precautions to reduce the risk of injury in the event of
sudden braking, sudden swerving or an accident.
Failure to do so may cause death or serious injury.
■Wearing a seat belt
● Ensure that all passengers wear a seat belt.
● Always wear a seat belt properly.
● Each seat belt should be used by one person only. Do not use a seat belt
for more than one person at once, including children.
● Scion recommends that children be seated in the rear seat and always
use a seat belt and/or an appropriate child restraint system.
● To achieve a proper seating position, do not recline the seat more than
necessary. The seat belt is most effective when the occupants are sitting
up straight and well back in the seats.
● Do not wear the shoulder belt under your arm.
● Always wear your seat belt low and snug across your hips.
■ When children are in the vehicle
Do not allow children to play with the seat belt. If the seat belt becomes
twisted around a child’s neck, it may lead to choking or other serious injuries
that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used
to cut the belt.
■ Seat belt pretensioners
● Do not place anything, such as a cushion, on the front passenger’s seat.
Doing so will disperse the passenger’s weight, which prevents the sensor
from detecting the passenger’s weight properly. As a result, the seat belt
pretensioner for the front passenger’s seat may not activate in the event of
a collision.
● If the pretensioner has activated, the SRS warning light will come on. In
that case, the seat belt cannot be used again and must be replaced at
your Scion dealer.

70 1-7. Safety information
Scion_xB_OM_OM12G05U_(U)
SRS airbag system componentsFront airbag sensors
Front passenger occupant
classification system (ECU
and sensors)
Front passenger’s seat
position sensor
Front passenger airbag
Side impact sensors (front
door)
Curtain shield airbags
“AIR BAG ON” and “AIR
BAG OFF” indicator lights
Side and curtain shield air-
bag sensors Side airbags
Seat belt pretensioners and
force limiters
SRS warning light
Driver airbag
Curtain shield airbag sen-
sors
Front passenger’s seat belt
buckle switch
Driver’s seat position sen-
sor
Driver’s seat belt buckle
switch
Airbag sensor assembly

71
1-7. Safety information
1
Before driving
Scion_xB_OM_OM12G05U_(U)
Your vehicle is equipped with
ADVANCED AIRBAGS designed based
on the US motor vehicle safety standards (FMVSS208). The airbag
sensor assembly (ECU) controls ai rbag deployment based on infor-
mation obtained from the sensors etc. shown in the system compo-
nents diagram above. This inform ation includes crash severity and
occupant information. As the air bags deploy, a chemical reaction in
the inflators quickly fills the airbag s with non-toxic gas to help restrain
the motion of the occupants.
■ If the SRS airbags deploy (inflate)
● Bruising and slight abrasions may result from contact with a deploying
(inflating) SRS airbag.
● A loud noise and white powder will be emitted.
● Parts of the airbag module (steering wheel hub, airbag cover and inflator)
as well as the front seats, parts of the front and rear pillars, and roof side
rails, may be hot for several minutes. The airbag itself may also be hot.
● The windshield may crack.

263
4-3. Do-it-yourself maintenance
4
Maintenance and care
Scion_xB_OM_OM12G05U_(U)
25 IG2
15 AIGN, METER, IG2 NO.2
26 IG2 NO.27.5 A Starting system
27 EFI NO.2 10 AAir conditioning system, rear O2
sensor, front air flow sensor
28 EFI NO.1 10 AMultiport fuel injection system/
sequential multiport fuel injection
system, air flow meter
29 H-LP RH HI 10 A Right hand headlight (high beam)
30 H-LP LH HI 10 A Left hand headlight (high beam)
31 H-LP RH LO 15 A Right hand headlight (low beam)
32 H-LP LH LO 15 A Left hand headlight (low beam)
FuseAmpereCircuit

5
When trouble arises
297
5-2. Steps to take in an emergency
Scion_xB_OM_OM12G05U_(U)
*1: Driver’s seat belt buzzer:
The driver’s seat belt buzzer sounds to alert the driver that his or her seat
belt is not fastened. Once the engine switch is turned to the “ON” or
“START” position, the buzzer sounds for 5 seconds. If the vehicle reaches a
speed of 12 mph (20 km/h), the buzzer sounds intermittently for 10 seconds.
Then, if the seat belt is still unfastened, the buzzer will sound in a different
tone for 20 more seconds.
*2: Front passenger’s seat belt buzzer:The front passenger’s seat belt buzzer sounds to alert the front passenger
that his or her seat belt is not fastened. The buzzer sounds intermittently for
10 seconds after the vehicle reaches a speed of 12 mph (20 km/h). Then, if
the seat belt is still unfastened, the buzzer will sound in a different tone for
20 more seconds.
*3: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s ManualSupplement” for the maintenance interval applicable to your vehicle.
■ SRS warning light
This warning light system monitors the airbag sensor assembly, front airbag
sensors, side and curtain shield airbag sensors, curtain shield airbag sen-
sors, driver’s seat position sensor, driver’s seat belt buckle switch, front pas-
senger occupant classification system (ECU and sensors), “AIR BAG ON”
indicator light, “AIR BAG OFF” indicator light, front passenger’s seat belt
buckle switch, seat belt pretensioner assemblies, inflators, interconnecting
wiring and power sources. ( P. 69)

298 5-2. Steps to take in an emergency
Scion_xB_OM_OM12G05U_(U)
■Front passenger detection sensor, passenger seat belt reminder and
warning buzzer
● If luggage is placed on the front passenger seat, the front passenger
detection sensor may cause the warning light to flash and the warning
buzzer to sound even if a passenger is not sitting in the seat.
● If a cushion is placed on the seat, the sensor may not detect a passen-
ger, and the warning light may not operate properly.
■ If the malfunction indicator lamp comes on while driving
First check the following:
● Is the fuel tank empty?
If it is, fill the fuel tank immediately.
● Is the fuel tank cap loose?
If it is, tighten it securely.
The malfunction indicator lamp will go off after taking driving trips.
If the malfunction indicator lamp does not go off even after several trips, con-
tact your Scion dealer as soon as possible.
■
When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level.
Pushing the tire pressure warning reset switch will not turn off the tire
pressure warning light.
■The tire pressure warning light may come on due to natural causes
The tire pressure warning light may come on due to natural causes such
as natural air leaks and tire inflat ion pressure changes caused by tem-
perature. In this case, adjusting the tire inflation pressure will turn off the
warning light (after a few minutes).
■When a tire is replaced with a spare tire
The compact spare tire is not equipped with a tire pressure warning
valve and transmitter. If a tire goes flat, the tire pressure warning light will
not turn off even though the flat tire has been replaced with the spare
tire. Replace the spare tire with the re paired tire and adjust the tire infla-
tion pressure. The tire pressure wa rning light will go off after a few min-
utes.

385
Alphabetical index
Scion_xB_OM_OM12G05U_(U)
Tires
Chains .................................. 161
Checking .............................. 238
Compact spare tire ............... 304
If you have a flat tire ............. 303
Inflation pressure .................. 246
Inflation pressure sensor ...... 239
Information ........................... 345
Replacing ............................. 303
Rotating tires ........................ 238
Size ...................................... 340
Snow tires............................. 161
Spare tire .............................. 303
Tire pressure warning system................................ 238
Tools......................................... 303
Total load capacity .................. 160
Towing Dinghy towing ............... 167, 168
Emergency towing ................ 282
Trailer towing ........................ 166
TRAC ........................................ 150
Traction control ....................... 150
Trailer towing........................... 166
Transmission shift
switches................................. 123
Turn signal lights Replacing light bulbs ............ 268
Switch ................................... 126
Wattage ................................ 341
Valet key..................................... 24
Vanity mirrors .......................... 193
Vehicle data recordings............ 17
Vehicle identification number................................... 332
Vehicle stability control .......... 150
VSC ........................................... 150
Warning buzzers Brake system........................ 290
Seat belt reminder ................ 294 Warning lights
Anti-lock brake system ..........292
Brake assist system ..............292
Brake system ........................290
Charging system .... ...............291
Electric power steering system
warning light........................293
Electronic engine control system ................................292
High coolant temperature ......291
Low engine oil pressure ........291
Low fuel level ........................294
Low tire pressure...................296
Low washer fluid ...................294
Malfunction indicator lamp ....292
Open door .............................294
Pretensioners ........................292
Seat belt reminder light .........294
SRS airbags ..........................292
Tire pressure warning light ....296
Washer Checking ...............................236
Preparing and checking
before winter .......................161
Switch....................................141
Washing and waxing ...............204
Weight Cargo capacity ......................155
Load limits .............................160
Weight ...................................332
Wheels ......................................250
Window glasses ........................58
Window lock switch ...................58
Windows
Power windows .......................58
Rear window defogger ..........178
Washer ..................................141
Windshield wipers ...................141
Wireless remote control key Locking/Unlocking ...................26
Replacing the battery ............256
Wireless remote control key ....26
