2013 TOYOTA TUNDRA engine coolant

5
When trouble arises
655
5-2. Steps to take in an emergency
The coolant level is satisfac-
tory if it is between the “FULL”
and “LOW” line on the reser-
voir.
Reservoir
“FULL”
“LOW”
Add coolant if necessary.
Water can be used in an emer-
gency if coolant is unavailable.
Start the engine and check that the radiator cooling fan
operates and to check for coolant leaks from the radiator or
hoses.
If the fan is not operating: Stop the engine immediately and contact your Toyota
dealer.
If the fan is operating: Have the vehicle inspected at the nearest Toyota dealer.

656 5-2. Steps to take in an emergency
CAUTION
■To prevent an accident or injury when inspecting under the hood of
your vehicle
● If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot, caus-
ing serious injuries such as burns.
● Keep hands and clothing (especially a tie, a scarf or a muffler) away from
the fan and belts. Failure to do so may cause the hands or clothing to be
caught, resulting in serious injury.
● Do not loosen the radiator cap and the coolant reservoir cap while the
engine and radiator are hot.
Serious injury, such as burns, may result from hot coolant and steam
released under pressure.
NOTICE
■When adding engine coolant
Wait until the engine has cooled down before adding engine coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot engine too
quickly can cause damage to the engine.
■ To prevent damage to the cooling system
Observe the following precautions:
●Avoid contaminating the coolant with foreign matter (such as sand or dust
etc.).
● Do not use commercially available coolant additives.

677
6-1. Specifications
6
Vehicle specifications
How to read oil container label:
The ILSAC (International Lubric
ant Standardization and Approval
Committee) Certification Mark is added to some oil containers to help
you select the oil you should use.
Cooling system
Capacity
4.0L V6
(1GR-FE)
engine 11.3 qt. (10.7 L, 9.4 Imp.qt.)
4.6L V8
(1UR-FE)
engine Vehicles without towing package
12.8 qt. (12.1 L, 10.6 Imp.qt.)
Vehicles with towing package
13.9 qt. (13.2 L, 11.6 Imp. qt.)
5.7L V8
(3UR-FE,
3UR-FBE)
engineVehicles without towing package
12.8 qt. (12.1 L, 10.6 Imp.qt.)
Vehicles with towing package
13.7 qt. (13.0 L, 11.4 Imp. qt.)
Coolant type Use either of the following.
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-silicate, non-amine, non-nitrite, and
non-borate coolant with long-life hybrid
organic acid technology
Do not use plain water alone.

695
6-1. Specifications
6
Vehicle specifications
Warning: The temperature grades for this tire are established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation, or
excessive loading, either sepa-
rately or in combination, can caus e heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure
Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those stan-
dard items which may be replaced) of trans-
mission, power steering, power brakes, power
windows, power seats, radio and heater, to the
extent that these items are available as factory-
installed equipment (whether installed or not)
Curb weight
The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
* that
follows

737
Alphabetical index
Emergency flashers ................ 602
Emergency flashers switch .... 602
Emergency, in case of
Blown fuse ............................ 579
If the engine will not start...... 644
If the shift lever cannot be shifted from P ..................... 646
If the vehicle has
discharged battery ............. 650
If the warning buzzer sounds ............................... 611
If the warning light turns on ....................................... 611
If the warning message
is displayed ........................ 622
If you have a flat tire ............ 626
If you lose your keys............. 649
If you think something is wrong.............................. 609
If your vehicle becomes
stuck................................... 657
If your vehicle has to be stopped in an emergency... 658
If your vehicle needs to be towed ............................ 603
If your vehicle overheats ...... 654 Engine
Compartment ........................545
Engine switch ........................178
Exhaust gas ..........................174
Hood......................................544
How to start the
engine .................................178
Identification number .............672
If the engine will not start ......644
Ignition switch .......................178
Immobilizer system ...............115
Overheating...........................654
Warning light .........................612
Engine coolant
Capacity ................................677
Checking ...............................550
Preparing and checking before winter .......................268
Engine coolan t temperature
gauge ......................................189
Engine immobilizer system.....115
Engine oil Capacity ................................675
Checking ...............................547
Preparing and checking before winter .......................268
Engine switch ...........................178
Event data recorder ...................38E

747
What to do if...
What to do if...
A tire puncturesP. 626If you have a flat tire
The engine does not start
P. 644If the engine will not start
P. 1 1 5Engine immobilizer system
P. 650If the vehicle battery is discharged
The shift lever cannot be
moved outP. 646If the shift lever cannot be shifted
from P
The engine coolant temperature
gauge enters the red zone
Steam can be seen coming
from under the hood
P. 654If your vehicle overheats
The key is lostP. 649If you lose your keys
The battery runs outP. 650If the vehicle battery is discharged
The doors cannot be lockedP. 4 9Side doors
The horn begins to soundP. 1 1 7Alarm
The vehicle is stuck in
mud or sandP. 657If the vehicle becomes stuck
