2013 TOYOTA SEQUOIA display

380 3-3. Using the Bluetooth
® audio system
Fast-forwarding and reversing tracksPress and hold “
” or “ ” on .
Switching the display
Press .
Each time is pressed, the display changes in the following order:
Track title  Track title/Artist name  Track title/Album name  Track
title/Elapsed time
Using the steering wheel audio switches
 P. 3 6 8
■Bluetooth® audio system functions
Depending on the portable player that is connected to the system, certain
functions may not be available.
■ Error messages
“BT AUDIO ERROR”: This indicates a problem in the system.

381
3-3. Using the Bluetooth® audio system
3
Interior features
Setting up a Bluetooth® enabled por table player
Registering a portable playerSelect “Pair Audio Player” using a voice command or , and
perform the procedure for registering a portable player. ( P. 376)
Registering a portable player in the Bluetooth® audio system allows
the system to function. The following functions can be used for reg-
istered portable players:
■ Functions and operation procedures
Press until “BT AUDIO” is displayed.
Press that corresponds to “SETUP”.
Select one of the following functions using a voice com-
mand or .
● Registering a portable player
“Pair Audio Player”
● Selecting a portable player to be used
“Select Audio Player”
● Changing the registered name
“Change Name”
● Listing the registered portable players
“List Audio Players”
● Changing the passkey
“Set Passkey”
● Deleting a registered portable player
“Delete Audio Player (Delete Audio)”

386
3-3. Using the Bluetooth® audio system
Bluetooth® audio system setup
■System setup items and operation procedures
●Setting voice guidance volume
1. “Setup”  2. “System Setup”  3. “Guidance Volume”
(  P. 470)
● Displaying the Bluetooth
® device address and name
1. “Setup”  2. “System Setup”  3. “Device Name”
(  P. 471)
● Initialization
1. “Setup”  2. “System Setup”  3. “Initialize”
(  P. 471)

387
3
Interior features
3-4. Using the rear seat entertainment system
Rear seat enter tainment system features
: If equipped
The rear seat entertainment system is designed for the rear passen-
gers to enjoy video such as Blu-ray Disc™ (BD) and DVD disc.
Vehicles with a navigation system
The sounds of the rear seat en tertainment system are available
from both vehicle speakers and headphones.
Rear seat entertainment system
Remote controller
A/V input port
Headphone volume control dials and headphone jacks
Navigation system
The rear seat entertainment system can be operated from the naviga-
tion system. (P. 396)
The video played by the rear seat entertainment system is not dis-
played on the navigation system’s screen. In addition, the DVD video
played by the navigation system is not displayed on the rear seat enter-
tainment system’s screen.

389
3-4. Using the rear seat entertainment system
3
Interior features
Opening and closing the display
■ Opening the display
Press the lock release button to
open the display.
Pull the display down to an easily
viewable angle.
■ Closing the display
Push the display up until a click
is heard.
The illumination of the screen
automatically turns off when the
display is closed. However, the
rear seat entertainment system is
not turned off. (The sound is not
turned off.)

393
3-4. Using the rear seat entertainment system
3
Interior features
Turning on/off the rear seat entertainment system
Press to turn on the rear seat entertainment system.
Press once again to turn off the system.
Adjusting the volume (vehicles with a navigation system)
Press “+” or “-” on the “VOL” button to adjust the volume.
When the speaker output is off, the volume cannot be adjusted.
Turning on/off the speaker output (vehicles with a navigation system)
Press to turn on/off the speaker output.
On: The sound is available from both vehicle speakers and headphones.
Off: The sound is available from the headphones only.
Selecting a control icon Press “ ”, “ ”, “ ” or “ ” on to select the control icon on the
screen.
Then press to enter.
Changing the screen sizeEach time the “SIZE” button is pressed, the screen size changes in
the following order:
Normal: Displays the screen at the original ratio

Wide 1: Widens the 4:3 aspect screen horizontally to fill the screen

Wide 2: Widens the screen vertically and horizontally, at the same ratio, to fill th e entire screen
The screen size can be changed for each media mode individually.

394 3-4. Using the rear seat entertainment system
Adjusting the screen settingsYou can adjust the color, contrast, tone and brightness of the screen.
The screen setting le vels can be adjusted for day mode and night
mode individually.
Press the “SETTING” button
.
The screen settings can be adjusted. After adjustments,
select “OK”.
“DISC”/“SD” mode
Turning on/off the “LCD AI”
The “LCD AI” automatically deter-
mines the tone of the video image
and sets the contrast to an opti-
mum level, displaying a sharp
image.
Turning on/off the speaker
output (vehicles with a naviga-
tion system only)
On: The sound is available from
both vehicle speakers and head-
phones.
Off: The sound is available from
the headphones only.
Adjusting the screen settings
“VIDEO” mode

401
3-4. Using the rear seat entertainment system
3
Interior features
●
This product is licensed under the AVC patent portfolio license and the
VC-1 patent portfolio license for the personal use of a consumer or other
uses in which it does not receive remuneration to (i) encode video in
compliance with the AVC Standard and the VC-1 Standard (“AVC/VC-1
Video”) and/or (ii) decode AVC/VC-1 Video that was encoded by a con-
sumer engaged in a personal activity and/or was obtained from a video
provider licensed to provide AVC/VC-1 Video. No license is granted or
shall be implied for any other use. Additional information may be
obtained from MPEG LA, LLC.
See http://www.mpegla.com.
● Cinavia Notice
This product uses Cinavia technology to limit the use of unauthorized cop-
ies of some commercially-produced film and videos and their soundtracks.
When a prohibited use of an unauthorized copy is detected, a message
will be displayed and playback or copying will be interrupted.
More information about Cinavia technology is provided at the Cinavia
Online Consumer Information Center at http://www.cinavia.com
. To
request additional information about Cinavia by mail, send a postcard with
your mailing address to: Cinavia Consumer Information Center, P.O. Box
86851, San Diego, CA, 92138, USA.
● This product incorporates proprietary technology under license from
Verance Corporation and is protected by U.S. Patent 7,369,677 and
other U.S. and worldwide patents issued and pending as well as
copyright and trade secret protection for certain aspects of such
technology. Cinavia is a trademark of Verance Corporation. Copyright
2004-2010 Verance Corporation. All rights reserved by Verance. Reverse
engineering or disassembly is prohibited.
● WMA (Windows Media Audio), Micros oft, Windows, and Windows Media
are the registered trademarks of Microsoft Corporation in the U.S. and
other countries.
● This item incorporates copy protection technology that is protected by
U.S. patents and other intellectual property rights of Rovi Corporation.
Reverse engineering and disassembly are prohibited.
