2013 TOYOTA SEQUOIA CD player

411
3-4. Using the rear seat entertainment system
3
Interior features
Turning on the BD/DVD mode
Insert a disc or Press the “DIS C” button with a disc inserted.
The player will start to play the disc automatically.
Playing/pausing a disc
Press to play/pause.
Press and hold while pausing, the video is played slowly.
Selecting a chapter Vehicles with a navigation system
Press or until the desired chapter appears.
Vehicles without a navigation system
Press / or “ ” / “ ” on the “CHAPTER” button until the
desired chapter appears.
Fast forwarding/rewinding a disc
Press and hold or .
Operating the disc menu Press the “TOP MENU” or “MENU” button. Select the menu item using the
“ ”, “ ”, “ ” or “ ” on ,
and press to enter.

422 3-4. Using the rear seat entertainment system
●Setting a sound dynamic range
The difference between the lowest and highest sound volumes can
be adjusted.
Each time “Sound Dynamic
Range” is selected, the setting
changes in the following order:
“MAX”: Maximum dynamic range
“STD”: Standard dynamic range 
“MIN”: Minimum dynamic range
■ Discs that can be used ( P. 397)
■ BD/DVD video discs
●Compatible media
Media that can be used for playback are BD-ROMs, BD-Rs, BD-REs,
DVD-ROMs, DVD-Rs and DVD-RWs.
● Compatible disc formats
Disc formats that can be used for playback are BD video formats, BDAV
formats, AVCHD formats, and DVD video formats
● This player conforms to NTSC/PAL color TV formats.
● Region codes
Some BD/DVD video discs have a region code indicating the region in
which you can use the BD/DVD video disc.
If the BD video disc is not labeled “A” or “ABC” or if the DVD video disc is
not labeled “1” or “ALL”, you cannot use it on this player.
If you attempt to play BD/DVD video discs with incompatible region codes
on this player, an error message appears on the screen. Even if the BD/
DVD video disc does not have a region code, in some cases it cannot be
used.

424 3-4. Using the rear seat entertainment system
■BD/DVD video disc information
●Parental controls
This feature limits what can be viewed in conformity with the level of
restrictions of the country. The level of restrictions varies depending on the
BD/DVD video disc. Some BD/DVD video discs cannot be played at all, or
violent scenes are skipped or replaced with other scenes.
• DVD video
Level 1: DVD video discs for children can be played.
Level 2 - 7: DVD video discs for children and G-rated movies can be
played.
Level 8: All types of DVD video discs can be played.
• BD video Parental controls of BD videos can be set up by inputting an age. If the
target age of BD video exceeds the age restriction that was set up, then
playback will not be possible.
● Multi-angle feature
You can enjoy the same scene from different angles.
● Multi-language option
You can select the subtitle and audio languages.
● Region codes
The region codes are provided on BD /DVD players and BD/DVD discs. If
the BD/DVD disc does not have the same region code as the BD/DVD
player, you cannot play the disc on the player.
● Title and chapter
Video and audio programs stored in BD/DVD video discs are divided into
parts by title and chapter.
Title: The largest unit of the video and audio programs stored on BD/DVD
video discs. Usually, one movie, one album, or one audio program is
assigned as a title.
Chapter: A title comprises of one or more chapters.

425
3-4. Using the rear seat entertainment system
3
Interior features
●
AVCHD
AVCHD is a new format (standard) for high definition video cameras that
can record and play high-resolution HD images.
DVDs and SD cards with videos recorded in AVCHD format can playback
on this system.
● BDAV (Blu-ray Disc™ Audio/Visual)
BDAV is one of the audio/video recording formats for Blu-ray Disc™, has
been made primarily for the purpose of broadcasting the recording.
It is used when recording to BD-R and BD-RE by Blu-ray™ recorder.
● BD-J
Some BD video discs contain Java applications, and these applications
are called BD-J. You can enjoy various interactive features in addition to
playing normal video.
● Pop-up menu
Some BD video discs have a pop-up navigation menu that can be called
up and be operated on the screen without interrupting playback.
● Picture-in-picture
This is a function of BD video that plays the primary video and secondary
video simultaneously. For instance, the function is capable of playing the
original movie as the primary video while playing video commentary from
the film director on a small screen as a secondary video.
● DUBA (Disc Unbound BD-J Application)
For BD videos that come as a 2 disc set or more, after finishing and eject-
ing one of the discs, continuation of the video can be seen shortly after
replacing the disc with the proper disc.
● Playlist (BDAV only)
A playlist of favorite scenes by Blu-ray™ recorder can be created and the
scenes can playback via playlist.
■ Audio
This player can play liner PCM, Dolby digital, DTS and MPEG audio format.
Other decoded types cannot be played.

429
3-4. Using the rear seat entertainment system
3
Interior features
NOTICE
■
Discs and adapters that cannot be used
Do not use the following types of discs, 8 cm (3 in.) disc adapters or Dual
Discs.
Doing so may damage the player and/or disc insert/eject function.
●Discs that have a diameter that is not
12 cm (4.7 in.).
● Low-quality or deformed discs.
● Discs with a transparent or translucent
recording area.
● Discs that have tape, stickers or labels
attached to them, or that have had the
label peeled off.

430 3-4. Using the rear seat entertainment system
NOTICE
■Player precautions
Failure to follow the precautions below may result in damage to the discs or
the player itself.
●Do not insert anything other than discs into the disc slot.
● Do not apply oil to the player.
● Store discs away from direct sunlight.
● Never try to disassemble any part of the player.

431
3-4. Using the rear seat entertainment system
3
Interior features
Playing an audio CD and MP3/WMA discs
: If equipped
Press the “DISC” button if a disc has already been loaded in the disc
slot. The player will start to play the disc automatically.
■ Remote controller
Vehicles with a navigation system
Selecting a control icon
Inputting the selected con-
trol icon
Volume up/down
Fast-forward/rewind
Play/pause
Selecting a track/file
Selecting a folder
Turning on the audio CD
and MP3/WMA mode

433
3-4. Using the rear seat entertainment system
3
Interior features
Turning on the audio CD and MP3/WMA mode
Insert a disc or Press the “DIS C” button with a disc inserted.
The player will start to play the disc automatically.
Selecting a track/file
Press or until the desired track/file number appears.
Fast forwarding or rewinding a track/filePress and hold or .
Selecting a folder (MP3/WMA)Press “ ” or “ ” on the “FOLDER” button until the desired folder num-
ber appears.
Press and hold “ ” on the “FOLDER” button, the top file stored in the top
folder in the disc will be selected.
Repeat play
Each time “RPT” is selected , the mode changes as follow:
Audio CD
“RPT” (track repeat)  Off
MP3/WMA
“RPT” (file repeat)  “FLD.RPT” (folder repeat)  Off
