2013 TOYOTA RAV4 display

370
RAV4_OM_OM42809U_(U)
5-2. Using the audio system
Select “Passkey” using the “TUNE•SCROLL” knob.
Select a 4 to 8-digit passkey using the knob.
Input the number 1 digit at a time.
When the entire number to be registered as a passkey has been
input, press (ENTER).
If the passkey to be registered has 8 digits, pressing (ENTER) is not
necessary.
If “BT power” is set to on, the registered device will be connected
automatically when the engine switch is turned to the “ACC” position
(vehicles without a smart key sy stem) or ACCESSORY mode (vehi-
cles with a smart key system).
Select “BT Power” using the “TUNE•SCROLL” knob.
Select “ON” or “OFF” using the knob.
Select “Bluetooth
* info” using the “TUNE•SCROLL” knob.
● Displaying the device name
Select “Device name” using the “TUNE•SCROLL” knob.
● Displaying the device address
Select “Device address” using the “TUNE•SCROLL” knob.
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Changing the passkey
Setting automatic connection of the device on or off
Displaying the device status
1
2
3
1
2

RAV4_OM_OM42809U_(U)
3715-2. Using the audio system
5
Interior features
If the “Display setting” is set to on, the portable player connection sta-
tus will be displayed when the engine sw itch is turned to the “ACC” or
“ON” position (vehicles without a smart key system) or ACCESSORY
or IGNITION ON mode (vehicl es with a smart key system).
Select “Display setting” us ing the “TUNE•SCROLL” knob.
Select “ON” or “OFF” using the knob.
Select “Initialize” using the “TUNE•SCROLL” knob.
● Initializing the sound settings
Select “Sound setting” using the “TUNE•SCROLL” knob and press
(YES).
For details about sound settings: P. 372
●Initializing the device information
Select “Car device info” using the “TUNE•SCROLL” knob and press
(YES).
Automatic connection of a portable device, automatic connection confirma-
tion display and the passkey will be initialized.
● Initializing all the settings
Select “All initialize” using the “TUNE•SCROLL” knob and press
(YES).
■The number of Bluetooth® device that can be registered
Up to 5 Bluetooth
® device can be registered in the system.
■ Bluetooth
® audio/phone system functions
Certain functions may not be available during driving.
Setting the automatic connection confirmation display to on or
off
Initialization
1
2

RAV4_OM_OM42809U_(U)
3755-2. Using the audio system
5
Interior features
Select “Delete contacts” using the “TUNE•SCROLL” knob.
Select the desired phone number using the knob and press
(YES).
To delete all the registered phone numbers, press (ALL) and then
press (YES).
Press (A-Z) to display the regi stered names in alphabetical order
of the initial.
Select “Delete other PB” using the “TUNE•SCROLL” knob.
Select the desired phonebook using the knob and press (YES).
Select “Auto transfer” usi ng the “TUNE•SCROLL” knob.
Select “ON” or “OFF” using the knob.
Select “Call volume” using the “TUNE•SCROLL” knob.
Change the call volume.
To decrease the volume: Turn the “TUNE•SCROLL” knob counterclock-
wise.
To increase the volume: Turn the “TUNE•SCROLL” knob clockwise.
To set the volume, press (SAVE).
Select “Ringtone volume” using the “TUNE•SCROLL” knob.
Change the ring tone volume.
To decrease the volume: Turn the “TUNE•SCROLL” knob counterclock-
wise.
To increase the volume: Turn the “TUNE•SCROLL” knob clockwise.
To set the volume, press (SAVE).
Deleting a registered phone number
Deleting another cellular phone’s phonebook
Setting automatic transferring of the phonebook on or off
Setting call volume
Setting ring tone volume
1
2
1
2
1
2
1
2
1
2

396
RAV4_OM_OM42809U_(U)
5-5. Other interior features
Clock
Adjusts the hours.
Adjusts the minutes.
■The clock is displayed when
Vehicles without a smart key system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system
The engine switch is in ACCESSORY or IGNITION ON mode.
■ When disconnecting and reco nnecting battery terminals
The clock data will be reset.
The clock can be adjusted by pressing the buttons.
1
2

RAV4_OM_OM42809U_(U)
4136-2. Maintenance
6
Maintenance and care
■Repair and replacement
It is recommended that genuine Toyota parts be used for repairs to ensure
performance of each system. If non-Toyota parts are used in replacement or if
a repair shop other than a Toyota dealer performs repairs, confirm the war-
ranty coverage.
■ Reset the maintenance data (U.S.A. only)
After the required maintenance is performed according to the maintenance
schedule, please reset the maintenance data.
To reset the data, follow the procedure described below:
Vehicles without a smart key system
Switch the display to the trip meter A (P. 90) and then turn the engine
switch to the “LOCK” position.
While pressing the “DISP” button ( P. 90), turn the engine switch to the
“ON” position (do not start the engine because reset mode will be can-
celed).
Continue to press and hold the button until the trip meter displays “000000”.
Vehicles with a smart key system
Switch the display to the trip meter A (P. 90) and then turn the engine
switch off.
While pressing the “DISP” button ( P. 90), turn the engine switch to IGNI-
TION ON mode (do not start the engine because reset mode will be can-
celed).
Continue to press and hold the button until the trip meter displays “000000”.
■ Allow inspection and repairs to be performed by a Toyota dealer
●Toyota technicians are well-trained specialists and are kept up to date with
the latest service information. They are well informed about the operations
of all systems on your vehicle.
● Keep a copy of the repair order. It proves that the maintenance that has
been performed is under warranty cove rage. If any problem should arise
while your vehicle is under warranty, your Toyota dealer will promptly take
care of it.
1
2
3
1
2
3

579
RAV4_OM_OM42809U_(U)
8-2. Customization
8
Vehicle specifications
Customizable features
Some function settings are changed simultaneously with other func-
tions being customized. Contact your Toyota dealer for further details.
Vehicles with a Display Audio syst em: Settings that can be changed
using the Display Audio system (For further information on custom-
izing settings using the Display A udio system, refer to the “Display
Audio System Owner’s Manual”.)
Settings that can be changed by your Toyota dealer
Your vehicle includes a variety of electronic features that can be
personalized to your preferences. Programming these prefer-
ences requires specialized equipment and may be performed by
your Toyota dealer.
Customizable features
1
2

RAV4_OM_OM42809U_(U)
5838-2. Customization
8
Vehicle specifications
Automatic
light control
system
(P. 217)
Light sensor sensitivity*1Level 3Level 1 to 5OO
Time elapsed before the
headlights automatically
turn off after the doors are
closed
30
seconds
Off
OO
60
seconds
90
seconds
Automatic High Beam*1OnOff—O
Lights
( P. 217)Daytime running lights*4OnOffOO
Turn signal
lever
(P. 214)Time of flashing of the
lane change signal flash-
ers
3Off—O
Instrument
cluster
(P. 8 7 )Eco Driving Indicator
Light
*5OnOff—O
Multi-
information
display
(P. 8 9 )Switching the display
when the average fuel
consumption is displayedEngine
coolant
tempera-
ture gaugeEco Driving Indicator Zone
Display
—O
Automatic
air condition-
ing system
*1
(  P. 295)
A/C Auto switch operationOnOff—O
Switching between out-
side air and recirculated
air mode linked to “AUTO”
switch operation
OnOff—O
ItemFunctionDefault
settingCustom-
ized setting12

603
RAV4_OM_OM42809U_(U)
Index
What to do if... (Troubleshooting) .................... 604
Alphabetical index ..................... 609
For vehicles with a Display Audio system, refer to the
“Display Audio System Owner’s Manual” for information
regarding the equipment listed below.
• Navigation system
• Audio system
• Rear view monitor system
