2013 TOYOTA PRIUS PLUG-IN HYBRID headlight bulb

521
4-3. Do-it-yourself maintenance
PRIUS PHV_OM_OM47787U_(U)
4
Maintenance and care
CAUTION
■
Replacing light bulbs
● Be sure to stop the hybrid system and turn off the lights. Do not attempt to
replace the bulb immediately after turning off the lights.
The bulbs become very hot and may cause burns.
● Do not touch the glass portion of the light bulb with bare hands. Hold the
bulb by the plastic or metal portion.
If the bulb is scratched or dropped, it may blow out or crack.
● Fully install light bulbs and any parts used to secure them. Failure to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.
■ To prevent damage or fire
Make sure bulbs are fully seated and locked.

620 6-1. Specifications
PRIUS PHV_OM_OM47787U_(U)
Light bulbs
A: H11 halogen bulbs
B: HB3 halogen bulbs
C: H16 halogen bulbs
D: Wedge base bulbs (amber)
E: Wedge base bulbs (clear)
F: Double end bulbs

*
: If equipped
Light BulbsBulb No.WTy p e
Exterior Halogen headlights
Low beam
High beam
LED headlights High beam H11
9005
9005 55
60
60A
B
B
Fog lights
*H16 19 C
Front turn signal lights WY21W 21 D
Front side marker lights W5W 5 E
Parking lights
(halogen headlights) W5W 5 E
Rear turn signal lights WY21W 21 D
Back-up lights W21W 21 E
License plate lights W5W 5 E
InteriorFront interior/personal lights
5E
Rear interior light 8F
Vanity lights 8E
Door courtesy lights 5E
Luggage compartment light 5F

673
Alphabetical index
PRIUS PHV_OM_OM47787U_(U)
Garage door opener ................ 407
Gauges ..................................... 257
Glove boxes ............................. 386
Hands-free system
(for cellular phone)
*
Hazard lights Switch ................................... 524
Head restraints Adjustment .......................... 152
Headlight cleaner .................... 307
Headlights
Cleaner ................................. 307
Replacing light bulbs ............ 507
Switch ................................... 292
Wattage ................................ 620
Heaters
Automatic air conditioning system................................ 358
Seat heaters ......................... 397
Side mirrors .......................... 375
Hill-start assist control ........... 333
Hood ......................................... 442
Hooks Cargo.................................... 403
Horn .......................................... 256
Hybrid system Emergency shut off system .... 45
Energy monitor/consumption screen ............. 52
High voltage components ....... 44
Hybrid System Indicator ....... 268
Ignition switch ....................... 238
Monthly fuel consumption record ................................... 64
“POWER” switch .................. 238 I/M test.......................................438
Identification
Engine ...................................612
Vehicle ..................................611
Ignition switch ..........................238
Illuminated entry system .........382
Immobilizer system..................179
Indicator lights .........................262
Initialization Items to initialize....................647
Inside rear view mirror ............166
Instrument panel light control ....................................260
Interior lights Interior lights..................383, 384
Switch............................383, 384
Wattage .................................620
Jack Positioning a floor jack ..........445
Vehicle-equipped jack ...........448
Jack handle ..............................448
Keyless entry............................132
Keys Electronic key ........................105
If the electronic key does not
operate properly..................591
If you lose your keys .............590
Key number ...........................105
Keyless entry.........................132
Keys ......................................105
Mechanical key .....................105
“POWER” switch ...................238
Wireless remote
control key ..........................132
Knee airbag ..............................184
G
H
I
J
K
*: Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.

674 Alphabetical index
PRIUS PHV_OM_OM47787U_(U)
Language .................................. 280
License plate lightsReplacing light bulbs ............. 507
Wattage .................................620
Light bulbs Replacing ..............................507
Wattage .................................620
Lights Emergency flasher switch ..... 524
Fog light switch ..................... 298
Foot lights..............................382
Hazard light switch ................524
Headlight switch .................... 292
Interior lights.................. 383, 384
Personal lights....................... 383
Replacing light bulbs ............. 507
Shift lever lighting .................. 382
Turn signal lever.................... 254
Turn signal light switch .......... 254
Vanity lights ...........................393
Wattage .................................620
Load capacity ...........................348
Luggage compartment light
Switch.................................... 141
Wattage .................................620
Luggage cover .........................404 Maintenance
Do-it-yourself maintenance ....................... 439
General maintenance............ 434
Maintenance data ................. 610
Maintenance requirements....................... 431
Maintenance data..................... 432
Meter Instrument panel light control ................................. 260
Meters ................................... 257
Speed unit select button ....... 259
Trip information display ......... 274
Micro dust and pollen filter ..... 362
Microphone
*............................ 415
Mirrors Inside rear view mirror .......... 166
Side mirror heater ................. 375
Side mirrors........................... 169
Vanity mirrors ........................ 393
MP3 disc
*
Multi-information display ........ 266
Navigation system
(refer to “Navigation
System Owner’s Manual”)
Noise from under vehicle .......... 22
LM
N

678 Alphabetical index
PRIUS PHV_OM_OM47787U_(U)
Tonneau cover .........................404
Tools ......................................... 448
Total load capacity...................348
Touch tracer display ................258
TowingDinghy towing........................355
Emergency towing.................526
Trailer towing.........................354
TRAC ......................................... 328
Traction control........................328
Trailer towing ...........................354
Transmission
Hybrid transmission............... 245
P position switch ...................248
Trip information ....................... 274
Trip meter .................................257
Turn signal lights Replacing light bulbs ............. 507
Switch.................................... 254
Wattage .................................620
USB port
*.................................381
Vanity lights Vanity lights ...........................393
Wattage .................................620
Vanity mirrors...........................393
Vehicle data recordings ............ 24
Vehicle identification number ...................................611
Vehicle proximity notification system ...................................... 38
Vehicle stability control...........328
VSC............................................ 328 Warning buzzers
Brake system ........................ 533
Open door ............................ 537
Seat belt reminder................. 537
Warning lights Anti-lock brake system
(ABS) .................................. 535
Automatic headlight leveling system ................................ 536
Brake system ................ 533, 536
Charging system .... ............... 534
Cruise control ........................ 536
Electric power steering
system ................................ 535
High coolant temperature...... 534
Hybrid system ....................... 535
Low fuel level ........................ 537
Low tire pressure .................. 538
Malfunction indicator lamp .... 535
Open door ............................. 537
Pre-collision system .............. 536
Radar cruise control. ............. 536
Seat belt warning light........... 537
Slip indicator ......................... 536
SRS airbags .......................... 535
Tire pressure warning light.... 538U
