2013 TOYOTA PRIUS PLUG-IN HYBRID engine

622 6-1. Specifications
PRIUS PHV_OM_OM47787U_(U)
■Gasoline quality standards
● Automotive manufacturers in the U.S.A., Europe and Japan have devel-
oped a specification for fuel quality called the World-Wide Fuel Charter
(WWFC), which is expected to be applied worldwide.
● The WWFC consists of four categories that are based on required emis-
sion levels. In the U.S., category 4 has been adopted.
● The WWFC improves air quality by lowering emissions in vehicle fleets,
and improves customer satisfaction through better performance.
■ Recommendation of the use of gaso line containing detergent additives
● Toyota recommends the use of gasoline that contains detergent additives
to avoid the build-up of engine deposits.
● All gasoline sold in the U.S.A. contains minimum detergent additives to
clean and/or keep clean intake systems, per EPA’s lowest additives con-
centration program.
● Toyota strongly recommends the use of Top Tier Detergent Gasoline. For
more information on Top Tier Detergent Gasoline and a list of marketers,
please go to the official website www.toptiergas.com.
■ Recommendation of the use of cleaner burning gasoline
Cleaner burning gasoline, including reformulated gasoline that contains oxy-
genates such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is available in
many areas.
Toyota recommends the use of cleaner burning gasoline and appropriately
blended reformulated gasoline. These types of gasoline provide excellent
vehicle performance, reduce vehicle emissions and improve air quality.

623
6-1. Specifications
6
Vehicle specifications
PRIUS PHV_OM_OM47787U_(U)
■
Non-recommendation of the use of blended gasoline
● If you use gasohol in your vehicle, be sure that it has an octane rating no
lower than 87.
● Toyota does not recommend the use of gasoline containing methanol.
■ Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancing additive called MMT (Methyl-
cyclopentadienyl Manganese Tricarbonyl).
Toyota does not recommend the use of gasoline that contains MMT. If fuel
containing MMT is used, your emission control system may be adversely
affected.
The malfunction indicator lamp on the instrument cluster may come on. If
this happens, contact your Toyota dealer for service.
■ If your engine knocks
● Consult your Toyota dealer.
● You may occasionally notice light knocking for a short time while acceler-
ating or driving uphill. This is normal and there is no need for concern.
●Use only gasoline containing a maxi-
mum of 10% ethanol.
DO NOT use any flex-fuel or gasoline
that could contain more than 10% etha-
nol, including from any pump labeled
E15, E30, E50, E85 (which are only
some examples of fuel containing more
than 10% ethanol).DO NOT use gasoline
containing more than
10% ethanol.
(15% ethanol)
(50% ethanol)
(85% ethanol)

624 6-1. Specifications
PRIUS PHV_OM_OM47787U_(U)
NOTICE
■Notice on fuel quality
● Do not use improper fuels. If improper fuels are used, the engine will be
damaged.
● Do not use leaded gasoline.
Leaded gasoline can cause damage to your vehicle’s three-way catalytic
converters causing the emission control system to malfunction.
● Do not use gasohol other than the type previously stated.
Other gasohol may cause fuel system damage or vehicle performance
problems.
● Using unleaded gasoline with an octane number or rating lower than the
level previously stated will cause persistent heavy knocking.
At worst, this will lead to engine damage.
■ Fuel-related p oor driveability
If poor driveability is encountered after using a different type of fuel (poor hot
starting, vaporization, engine knocking, etc.), discontinue the use of that type
of fuel.
■ When refueling with gasohol
Take care not to spill gasohol. It can damage your vehicle’s paint.
■ Notice about fuel
For plug-in hybrid vehicles, fuel may remain in the tank for a long time and
undergo changes in quality depending on the how the vehicle is used.
Refuel at least 5.3 gal. (20 L, 4.4 Imp.gal.) of fuel every 6 months (refuel a
total of at least 5.3 gal. [20 L, 4.4 Imp.gal.] over a 6-month period), as this
may affect components of the fuel system or the gasoline engine.

631
6-1. Specifications
6
Vehicle specifications
PRIUS PHV_OM_OM47787U_(U)
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

670 Alphabetical index
PRIUS PHV_OM_OM47787U_(U)
Child restraint systemBooster seats, definition ........ 204
Booster seats, installation ..... 212
Convertible seats, definition ............................. 204
Convertible seats,
installation ...........................212
Front passenger occupant classification system ...........198
Infant seats, definition ...........204
Infant seats, installation.........212
Installing child restraint system with LATCH anchors ...........210
Installing child restraint system with seat belts ..................... 212
Installing child restraint system with top tether strap ............216
Child safety
Airbag precautions ................192
Back door precautions .......... 142
Child restraint system............204
Child-protectors ..................... 135
How to charge ......................... 80
How your child should wear the seat belt ........................159
Installing child restraints ........ 209
Power window lock switch..... 171
Power window precautions ...173
Remote Air Conditioning System precautions ............374
Removed electronic key
battery precautions ............. 494
Seat belt extender precautions .........................164
Seat belt precautions ............160
Seat heater precautions ........ 398
12-volt battery precautions ....474 Child-protectors ....................... 135
Cleaning
Exterior.................................. 424
Interior ................................... 428
Seat belts .............................. 429
Clock ......................................... 275
Condenser ................................ 466
Console box ............................. 387
Cooling system
Engine overheating ............... 600
Hybrid system overheating ... 600
Cruise control
Cruise control ........................ 308
Dynamic radar cruise control ................................. 312
Cup holders .............................. 388
Curtain shield airbags ............. 184
Customizable features ............ 639

672 Alphabetical index
PRIUS PHV_OM_OM47787U_(U)
EngineAccessory mode.................... 240
Compartment ........................459
Hood......................................442
How to start the hybrid system ................................238
Identification number ............. 611
If the hybrid system will not start .....................................588
Ignition switch........................238
Overheating...........................600
“POWER” switch ...................238
Engine coolant Capacity ................................617
Checking ............................... 464
Preparing and checking before winter ....................... 349
Engine/power control
unit coolant Capacity ................................617
Checking ............................... 464
Preparing and checking before winter ....................... 349
Engine oil Capacity ................................614
Checking ............................... 460
Preparing and checking before winter ....................... 349
Enhanced VSC .........................328
EPS ............................................ 328
EV driving ratio indicator ........ 271
EV driving range ................58, 268
Event data recorder ...................25
EV/HV mode selection switch .......................................37 Floor mats ................................ 401
Fluid
Brake..................................... 619
Washer.................................. 469
Fog lights Replacing light bulbs ............. 507
Switch ................................... 298
Wattage................................. 620
Foot lights ................................ 382
Front fog lights
Replacing light bulbs ............. 507
Switch ................................... 298
Wattage................................. 620
Front passenger occupant classification system ............ 198
Front passenger’s seat belt reminder light ........................ 537
Front seats
Adjustment ............................ 146
Front side marker light Replacing light bulbs ............. 507
Wattage................................. 620
Front turn signal lights Replacing light bulbs ............. 507
Switch ................................... 254
Wattage................................. 620
Fuel Capacity ................................ 613
Fuel gauge ............................ 257
Information ............................ 621
Refueling ............................... 174
Type ...................................... 621
Fuel door .................................. 174
Fuel filler door .......................... 174
Fuses ........................................ 495F

673
Alphabetical index
PRIUS PHV_OM_OM47787U_(U)
Garage door opener ................ 407
Gauges ..................................... 257
Glove boxes ............................. 386
Hands-free system
(for cellular phone)
*
Hazard lights Switch ................................... 524
Head restraints Adjustment .......................... 152
Headlight cleaner .................... 307
Headlights
Cleaner ................................. 307
Replacing light bulbs ............ 507
Switch ................................... 292
Wattage ................................ 620
Heaters
Automatic air conditioning system................................ 358
Seat heaters ......................... 397
Side mirrors .......................... 375
Hill-start assist control ........... 333
Hood ......................................... 442
Hooks Cargo.................................... 403
Horn .......................................... 256
Hybrid system Emergency shut off system .... 45
Energy monitor/consumption screen ............. 52
High voltage components ....... 44
Hybrid System Indicator ....... 268
Ignition switch ....................... 238
Monthly fuel consumption record ................................... 64
“POWER” switch .................. 238 I/M test.......................................438
Identification
Engine ...................................612
Vehicle ..................................611
Ignition switch ..........................238
Illuminated entry system .........382
Immobilizer system..................179
Indicator lights .........................262
Initialization Items to initialize....................647
Inside rear view mirror ............166
Instrument panel light control ....................................260
Interior lights Interior lights..................383, 384
Switch............................383, 384
Wattage .................................620
Jack Positioning a floor jack ..........445
Vehicle-equipped jack ...........448
Jack handle ..............................448
Keyless entry............................132
Keys Electronic key ........................105
If the electronic key does not
operate properly..................591
If you lose your keys .............590
Key number ...........................105
Keyless entry.........................132
Keys ......................................105
Mechanical key .....................105
“POWER” switch ...................238
Wireless remote
control key ..........................132
Knee airbag ..............................184
G
H
I
J
K
*: Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.

675
Alphabetical index
PRIUS PHV_OM_OM47787U_(U)
Odometer ................................. 266
Oil
Engine oil.............................. 460
Opener Back door ............................. 140
Fuel filler door....................... 174
Hood ..................................... 442
Outside rear view mirrors Adjusting and folding ............ 169
Outside rear view mirror defogger switch .................... 375
Outside temperature
display ................................... 394
Overheating ............................. 600
Parking brake .......................... 255
Parking lights Switch ................................... 292
PCS ........................................... 335
Personal lights Switch ................................... 383
Wattage ................................ 620
Plug-in hybrid system Driving tips.............................. 67
EV driving range ..................... 58
EV mode................................. 35
EV/HV mode selection
switch ................................... 37
Features ................................. 32
How to charge ........................ 80
HV mode ................................ 36
Plug-in Hybrid Applications .... 70
Power outlets........................... 395
Power sources........................... 77
“POWER” switch ..................... 238
Power windows ....................... 171
Pre-collision system ............... 335 Radar cruise control
system ....................................312
Radiator ....................................466
Radio
*
Radio data system*
RDS*
Rear seats
Adjustment ............................149
Folding down .........................150
Rear turn signal lights Replacing light bulbs .............507
Wattage .................................620
Rear view mirror...............166, 169
Rear view monitor system
*
Rear window and outside rear view mirror
defoggers ...............................375
Rear window wiper and
washer ....................................304
Remote Air C onditioning
System ....................................371
Replacing
Electronic key battery ............493
Fuses ....................................495
Light bulbs .............................507
Tires ......................................448
Reporting safety defects for U.S. owners ............................650
O
P
R
*: Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.
