2013 TOYOTA 4RUNNER air conditioning

TABLE OF CONTENTS
4RUNNER_U
1
1Before drivingAdjusting and operating features such as door locks,
mirrors, and steering column.
2When drivingDriving, stopping and safe-driving information.
3Interior
featuresAir conditioning and audio systems, as well as other in-
terior features for a comfortable driving experience.
4Maintenance
and careCleaning and protecting your vehicle, performing do-it-
yourself maintenance, and maintenance information.
5When trouble
arisesWhat to do if the vehicle needs to be towed, gets a flat
tire, or is involved in an accident.
6Vehicle
specificationsDetailed vehicle information.
7For ownersReporting safety defects for U.S. owners, and seat belt
and SRS airbag instructions for Canadian owners.
IndexAlphabetical listing of information contained in this
manual.

1
2
3
4
5
6
7
4RUNNER_U
3
2-3. Operating the lights and wipers
Headlight switch .................. 203
Fog light switch ................... 209
Windshield wipers and washer .............................. 211
Rear window wiper and washer .............................. 214
2-4. Using other driving systems Cruise control ...................... 217
Intuitive parking assist......... 221
Rear view monitor system .............................. 226
Four-wheel drive system (part-time 4WD models).... 236
Four-wheel drive system (full-time 4WD models) ..... 241
Active traction control system .............................. 245
AUTO LSD system.............. 247
Rear differential lock system .............................. 250
Downhill assist control system .............................. 253
Crawl Control ...................... 256
Multi-terrain Select .............. 260
Driving assist systems ........ 268
2-5. Driving information Off-road precautions ........... 277
Cargo and luggage ............. 282
Vehicle load limits ............... 288
Winter driving tips ............... 290
Trailer towing ...................... 295
Dinghy towing ..................... 313 3-1. Using the air conditioning
system and defogger
Manual air conditioning system .............................. 316
Automatic air conditioning system .............................. 322
Rear window and outside rear view
mirror defoggers ............... 331
Windshield wiper de-icer .... 333
3-2. Using the audio system Audio system types ............ 334
Using the radio ................... 341
Using the CD player ........... 348
Playing MP3 and WMA discs ................................. 357
Operating an iPod .............. 365
Operating a USB memory ............................ 372
Optimal use of the audio system .............................. 379
Using the AUX port............. 384
Using the steering wheel audio switches.................. 385
Detachable pole antenna ............................ 388
3Interior features

1
2
3
4
5
6
7
4RUNNER_U
5
4-1. Maintenance and careCleaning and protecting the vehicle exterior............ 508
Cleaning and protecting the vehicle interior............. 511
4-2. Maintenance Maintenance requirements ..................... 514
General maintenance.......... 517
Emission inspection and maintenance (I/M)
programs........................... 521
4-3. Do-it-yourself maintenance Do-it-yourself service precautions ....................... 522
Hood ................................... 525
Engine compartment ........... 526
Tires .................................... 542
Tire inflation pressure ......... 548
Wheels ................................ 552
Air conditioning filter............ 555
Wireless remote control/ electronic key battery ........ 557
Checking and replacing fuses ................................. 560
Light bulbs........................... 570 5-1. Essential information
Emergency flashers............ 582
If your vehicle needs to be towed........................... 583
If you think something is wrong ............................... 589
Fuel pump shut off system .............................. 590
5-2. Steps to take in an emergency
If a warning light turns on or a warning buzzer
sounds.............................. 591
If you have a flat tire ........... 607
If the engine will not start.... 620
If the shift lever cannot be shifted from P ................... 622
If you lose your keys........... 623
If you cannot operate back door opener ...................... 624
If the electronic key does not operate properly ......... 625
If the vehicle battery is discharged........................ 627
If your vehicle overheats .... 631
If the vehicle becomes stuck ................................. 634
If your vehicle has to be stopped in an
emergency ....................... 635
4Maintenance and care5When trouble arises

4RUNNER_U
15
CTHPIAS061
A
CTHPIAS060Security indicator
light
P. 113, 116
Front passenger “AIR BAG ON” and
“AIR BAG OFF” indicator
P. 136
: If equipped
*1: Refer to “Navigation System Owner’s Manual”.
*2: Refer to “Display Audio System Owner’s Manual”.
Vehicles with a manual air conditioning system
Vehicles with an automatic air conditioning system Rear window and outside rear
view mirror defoggers
P. 331
Security indicator
light
P. 113, 116
Front passenger “AIR BAG ON” and
“AIR BAG OFF” indicator
P. 136
Rear window and outside rear
view mirror defoggers
P. 331
Intuitive parking assist
indicator light
 P. 221
Intuitive parking assist
indicator light
 P. 221
Front passenger’s seat belt
reminder light
P. 595
Front passenger’s seat belt
reminder light
P. 595

314
4RUNNER_U
3-1. Using the air conditioning system and defogger
Manual air conditioning system ........................... 316
Automatic air conditioning system ........................... 322
Rear window and outside rear view
mirror defoggers ............ 331
Windshield wiper de-icer ............................ 333
3-2. Using the audio system Audio system types .......... 334
Using the radio ................. 341
Using the CD player ......... 348
Playing MP3 and WMA discs............................... 357
Operating an iPod ............ 365
Operating a USB memory .......................... 372
Optimal use of the audio system .................. 379
Using the AUX port .......... 384
Using the steering wheel audio switches ............... 385
Detachable pole antenna .......................... 388
Interior features3

316
4RUNNER_U
3-1. Using the air conditioning system and defogger
Manual air conditioning system
Adjusting the settings■ Basic setting
To turn on the air conditioning system and adjust the fan
speed, turn the fan speed control knob clockwise (increase) or
counterclockwise (decrease).
Turning the knob to “OFF” turns off the fan.
: If equipped
Fan speed control knob Air outlet selector knob
Cooling and dehumidification
function on/off button Temperature control knob
Outside/recirculated air mode button
STEP 1

317
3-1. Using the air conditioning system
and defogger
3
Interior features
4RUNNER_UTo adjust the temperature setting, turn the temperature control
knob clockwise (warm) or countercloc
kwise (cool).
If is not pressed, the system will blow ambient temperature
air or heated air.
For quick cooling, turn the temper ature control knob to “MAX A/C”.
The air conditioning will automatically turn on and, if an air outlet
position other than or is selected, the system will be
set to recirculated air mode. While “MAX A/C” is selected, it is not
possible to turn off the air conditioning.
To select the air outlets, set th e air outlet selector knob to the
desired position.
The positions between the air outlet selections shown below can
also be selected for more delicate adjustment.
Air flows to the upper body.
Air flows to the upper body and
feet.
STEP 2
STEP 3
CTH31AS004
CTH31AS005

318 3-1. Using the air conditioning system and defogger
4RUNNER_U Mainly air flows to the feet.
Air flows to the feet and the
windshield defogger operates.
The air intake is automatically
switched to outside air mode.
Pressing
to turn the cool-
ing and dehumidification function
on clears the windshield and side
windows faster.
Air flows to the windshield and
side windows.
The air intake is automatically
switched to outside air mode. It is
not possible to return to recircu-
lated air mode when the switch is
on.
Pressing
to turn the cool-
ing and dehumidification function
on clears the windshield and side
windows faster.
CTH31AS006
CTH31AS007
CTH31AS008
