Page 140 of 268

Peugeot Partner Tepee 2013 Owners Manual - RHD (UK, Australia) 138

Levels

Cooling system

Only use the ﬂ uid recommended by the
manufacturer.
Otherwise, you risk seriously damaging
your engine.
When the engine is warm, the
temperature o

138

Levels

Cooling system

Only use the ﬂ uid recommended by the
manufacturer.
Otherwise, you risk seriously damaging
your engine.
When the engine is warm, the
temperature of the coolant is controlled
by the engine fan. As this fan can
operate with the ignition key removed
and because the cooling system is
pressurised, wait for at least one hour
after the engine has stopped before
carrying out any work.
Slacken the cap by 1/4 of a turn to
release the pressure to prevent any
risk of scalding. When the pressure
has dropped, remove the cap and top
up the level with coolant.
If ﬂ uid has to be added frequently,
this indicates a fault which must be
checked by a PEUGEOT dealer as
soon as possible.

Power steering fluid level

The vehicle must be parked on level
ground with the engine cold. Unscrew
the cap integrated with the gauge and
check the level which must be between
the MIN and MAX marks. In order to regenerate the ﬁ lter, you
are advised to drive at a speed higher
than 40 mph (60 km/h) for at least ﬁ ve
minutes as soon as possible, when
trafﬁ c conditions permit (until the
message disappears and the service
warning lamp goes off).
During regeneration of the particle
emission ﬁ lter, the noise of a relay
operating may be heard under the
dashboard.
If the message is still displayed and
if the service warning lamp remains
on, consult a PEUGEOT dealer or a
qualiﬁ ed workshop.

Topping up
The level must be between the MIN
and MAX marks on the expansion
bottle. If more than 1 litre of ﬂ uid is
required to top up the level, have
the system checked by a PEUGEOT
dealer or a qualiﬁ ed workshop.

Screenwash and headlamp
wash level
For best quality cleaning and for your
safety, we would advise that you use
products of the PEUGEOT range.
For optimum cleaning and to avoid
freezing, this ﬂ uid must not be topped
up or replaced with plain water.
Capacity of the screenwash reservoir:
approximately 3 litres.
If your vehicle is ﬁ tted with headlamp
washers, the capacity of the reservoir
is 6 litres.

Diesel additive level
(Diesel with particle
emission filter)
The minimum level of this
additive is indicated by lighting of the
service warning lamp, accompanied by
an audible signal and a message in the
screen.
When this occurs with the engine
running it is due to the start of
saturation of the particle emission ﬁ lter
(exceptionally prolonged urban type
driving conditions: low speed, long
trafﬁ c jams, ...).
Topping up
This additive must be topped up by
a PEUGEOT dealer or a qualiﬁ ed
workshop without delay.

Waste products

Avoid prolonged contact of used oil
with the skin.
Brake ﬂ uid is harmful to health and
very corrosive.
Do not dispose of used oil, brake ﬂ uid
or coolant into drains or into the ground
but into the containers dedicated to this
use at PEUGEOT dealer (France) or
an authorised waste disposal site.
