2013 Peugeot 508 Hybrid technical data

.
.
Contents
Child seats 153
ISOFIX child seats 160
Child lock 164
Child safety
Direction indicators 165
Emergency or assistance call 166
Horn 166
Tyre under-infl ation detection 167
ESC system 168
Seat belts 171
Airbags 174
Safety
Te m p o r a ry puncture repair kit 178
Changing a wheel 184
Changing a bulb 191
Changing a fuse 200
12 V battery 204
Energy economy mode 207
Changing a wiper blade 208
To w i ng the vehicle 209
To w i ng a trailer 211
Fitting roof bars 213
Accessories 214
Practical information
Opening the bonnet 217
Running out of fuel (Diesel) 218
Petrol engines 219
Diesel engines 220
Checking levels 222
Checks 225
Checks
Petrol engines 227
Petrol weights 228
Diesel engines 230
Diesel weights 233
Dimensions 236
Identifi cation markings 237
Technical data
Emergency or assistance 239
JBL equipment 241
Peugeot Connect Navigation (RT6) 243
Audio system 297
Audio equipment and telematics
Alphabetical index
Visual search

212
Practical information
Driving advice
Distribution of loads
FDistribute the load in the trailer so that theheaviest items are as close as possible to
the axle and the nose weight approaches
the maximum permitted without
excee
ding it.
Air density decreases with altitude, thus reducingengine performance. Above 1 000 metres, the maximum towed load must be reduced by 10 %
for every 1 000 metres of altitude.
Side wind
FTake into account the increased sensitivity
to side wind.

Cooling

To w i ng a trailer on a slope increases the
temperature of the coolant.
As the fan is electricall
y controlled, its cooling capacity is not dependent on the engine speed.
F
To lower the engine speed, reduce your speed.
The maximum towed load on a long incline
depends on the
gradient and the ambient
temperature.
In all cases, keep a check on the coolant
temperature.
FIf the warning lamp and the
STOP warning lamp come on, stop the vehicle and switch off
the engine as soon as possible.



Braking

To w i ng a trailer increases the braking distance.
To avoid overheating of the brakes on a longmountain type of descent, the use of engine braking is recommended.


Tyres
F
Check the tyre pressures of the towingvehicle and of the trailer, obser ving the recommended pressures.



Lighting
F
Check the electrical lighting and signalling on the trailer.


The rear parking sensors will be deactivated automatically if a genuine PEUGEOT towbar is used.
R
efer to the "Technical Data" section for details
of the weights and towed loads which apply to your vehicle.

10
227
Technical data
Petrol engines1.6 litre VTi120 hp1.6 litre THP15 6 hp1.6 litre THP 160 hp
Gearboxes

Electronic gear control (6-speed)Manual (6-speed)

Automatic (6-speed)


Manual (6-speed)

Model codes8D5FH8/P - 8E5FH8/P8D5FS8/P - 8E5FS8/P 8D5FV8 - 8E5FV8 8D5FNA - 8E5FNA 8D5FVA - 8E5FVA -

Cubic capacity (cc) 1 598
1 598
1 598

Bore x stroke
(mm) 77 x 85.8 77 x 85.8
77 x 85.8
Max power: EU standard
(kW) 8588
11 0115-

Max power engine speed (rpm) 6 000
6 000
-
Max torque: EU standard
(Nm)

160 240 -

Max torque engine speed (rpm)
4 250
1 400
-

Fuel Unleaded Unleaded Unleaded
Catal
ytic converter yes
yes
yes

Oil capacities (in litres
)
Engine (with filter replacement)
4.25

4.25

4.25















Petrol engines and gearboxes

228
Technical data
*
The kerb weight is equal to the unladen weight + driver (75 kg). **

The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

















Petrol weights and towed loads (in kg)
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

Petrol engines1.6 litre V Ti120 hp1.6 litre THP156 hp
GearboxesElectronic gear control(6-speed)


Manual(6-speed)
Automatic(6-speed)

Model codes

8D5FH8/P - 8E5FH8/P 8D5FS8/P - 8E5FS8/P 8D5FV8 - 8E5FV8
8D5FNA - 8E5FNA 8D5FVA - 8E5FVA
BodySaloon
SW
Saloon SW
Saloon
SW


- Unladen wei
ght 1 390
1 410
1 400
1 420
1 410
1 430



- Kerb weight *

1 465 1 485
1 475 1 495
1 485
1 505


- Gross vehicle wei
ght (GV W)
1 945 2 0551 9952 080
2 015 2 10 0



- Gross train weight (GTW)

on a 12 % gradient 3 3453 355
3 595
3 5803 515
3 600



- Braked trailer
(within GTW limit) on a 10 % or 12 % gradient1 400
1 3001 6001 500

1 600

1 500



- Braked trailer ** (with load transfer within the
GTW limit) 1 675 1 575 1 875 1 7751 875 1 775


-
Unbraked trailer

730
740735

745

740
750



- Recommended nose weight 7575

10
229
Technical data
Petrol engine1.6 litre THP 160 hp
Gearbox

Manual(6-speed)
Model code
-

Body
Saloon
SW


- Unladen wei
ght -
-


- Kerb weight
*-
-



- Gross vehicle wei
ght (GV W)
-
-


-
Gross train weight (GTW)

on a 12 % gradient --



- Braked trailer (within GTW limit) on a 10 % or 12 % gradient--



- Braked trailer ** (with load transfer within the
GTW limit) -
-


-
Unbraked trailer --



- Recommended nose weight
-
*
The kerb weight is equal to the unladen weight + driver (75 kg). **

The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Petrol weights and towed loads (in kg)


The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

230
Technical data
Diesel engine1.6 litre HDi110 hp
Gearboxes
Manual(5-speed)


Electronic gear control (6-speed)

Model codes8D9HL0 - 8E9HL0
8D9HR8/PS - 8E9HR8/PS

Body
SaloonSW
Saloon
SW

Cubic capacity (cc) 1 560
1 560
Bore x stroke
(mm)

75 x 88.3

75 x 88.3

Max power: EU standard
(kW) 8484
Max power en
gine speed (rpm) 3 600
3 600

Max torque: EU standard
(Nm) 240
270

Max torque engine speed (rpm) 1 750

1 750

F
uel Diesel

Catalytic conver ter yes
Particle emission filter yes
Oil capacities (in litres)

Engine (with filter replacement) 3.25















Diesel engines and gearboxes

10
231
Technical data
Diesel engines2.0 litre HDi 140 hp2.0 litre HDi163 hp
GearboxesManual (6-speed)


Automatic
(6-speed)Manual (6-speed)

Model codes8DRHR8 - 8ERHR8 8DRHF8 - 8ERHF88DRHHA - 8ERHHA
8DRHDA - 8ERHDA
8DRHH8 - 8ERHH8
BodySaloon
SW
SaloonSW Saloon
SW

Cubic capacity (cc) 1 997
1 997
Bore x stroke
(mm) 85 x 88
85 x 88

Max power: EU standard (kW)
10 0
103 10 0
120
Max power en
gine speed (rpm)
4 000
3 750

Max torque: EU standard (Nm)
320340

Max torque engine speed (rpm)
2 000
2 000

Fuel Diesel

Catalytic converter
yes

Particle emission filter yes
no

Oil capacities
(in litres)
Engine (with filter replacement) 5.255

Diesel engines and gearboxes

232
Technical data
Diesel engines and gearboxes
Dieselengine2.2 litre HDi204 hp
Gearbox

Automatic
(6-speed)
Model codes
8D4HLA - 8E4HLA
BodySaloon
SW

Cubic capacity (cc)

2 179
Bore x stroke
(mm)
85 x 96

Max power: EU standard
(kW) 150

Max power en
gine speed (rpm) 3 500

Max torque: EU standard
(Nm)
450

Max torque engine speed (rpm)
2 000

F
uel Diesel

Catalytic conver ter yes
Particle emissions filter yes
Oil capacities(in litres)

Engine (with filter replacement) 5.25
