2013 Peugeot 308 SW BL Owner's Manual

7
FAMILIARISATION
ACCESS

Panoramic sunroof
Boot




95


1.
Opening the blind.

2.
Closing the blind.

1.
Unlocking the vehicle.

2.
Opening the boot.



94

8
FAMILIARISATION
INTERIOR


Interior mood lighting
This dimmed lighting of the passenger
compartment improves visibility inside
the vehicle when the light is poor.



109


6-speed electronic gear control
gearbox
This system offers driving combining a
fully automatic mode and a a manual
mode.



153

Audio and communication systems
This equipment benefi ts from the latest
technology: MP3 compatible Peugeot
Connect Sound (RD5), Bluetooth,
Peugeot Connect Navigation (RT6) or
Peugeot Connect Media Navigation
(NG4 3D) with 16/9 retractable colour
screen, JBL audio system, auxiliary
sockets.

Peugeot Connect Sound (RD5)




345

Peugeot Connect Navigation (RT6)




291


Peugeot Connect Media Navigation (NG4 3D)





247

9
FAMILIARISATION
INSTRUMENTS AND CONTROLS



1.
Cruise control / speed limiter
switches.

2.
Steering wheel adjustment control.

3.
Lighting and direction indicator
control stalk.

4.
Instrument panel.

5.
Driver's airbag.
Horn.

6.
Gear lever.

7.
Parking brake lever.

8.
Panoramic sunroof blind control.

9.
Heated seat control.

10.
Bonnet release.

11 .
Door mirror controls.
Electric window controls.

12.
Fusebox.

13.
Manual headlamp height
adjustment.
Stop & Start button.

14.
Front side window demisting vent.

15.
Speaker (tweeter).

16.
Windscreen demisting vent.

10
FAMILIARISATION
INSTRUMENTS AND CONTROLS



1.
Steering lock and ignition.

2.
Audio and telematics system
steering mounted control.

3.
Wiper / screenwash / trip computer
control stalk.

4.
Central adjustable air vents.

5.
Multifunction screen.

6.
Sunshine sensor.

7.
Passenger's airbag.

8.
Side adjustable air vent.

9.
Passenger's airbag deactivation.

10.
Glove box / Audio/video sockets.

11 .
Storage compartment or instrument
panel navigator associated with
Peugeot Connect Media Navigation
(NG4 3D).

12.
12 V accessory socket.

13.
Front ashtray.

14.
Heating / air conditioning controls.

15.
Open storage.

16.
Audio and telematics system.

17.
Emergency call button.
Alarm button.
Central locking button.
Hazard warning lamps button.
Dynamic stability control (ESP/
ASR) button.
Parking sensors button.
PEUGEOT services button

11
FAMILIARISATION
SITTING COMFORTABLY

Driver's seat

Manual adjustment

Electric adjustment


Forwards-backwards



68




69
Seat back angle


Height

FAMILIARISATION

Steering wheel adjustment



1.
Unlocking the control.

2.
Adjustment for height and reach.

3.
Locking the control.
SITTING COMFORTABLY

Front seats


Other functions available...
Table position for the front passen-
ger seat (SW).
Storing driving positions (driver's
electric seat).
Heated seats.

Head restraint height

Lumbar

Front armrest




70




11 3




82
For your comfort, the height and longi-
tudinal position of the front armrest can
be adjusted.
It also has a storage compartment. As a safety precaution, these op-
erations must only be carried out
when stationary.

13
FAMILIARISATION
SITTING COMFORTABLY

Door mirrors


Adjustment

Other functions available...
Folding / Unfolding.
Automatic tilting of the mirror in re-
verse gear for parking.



Rear view mirror


Manual day/night model


Front seat belts



1.
Fastening the buckle.

2.
Height adjustment.

A.
Selection of the mirror to be adjusted.

B.
Adjustment of the position of the
mirror in the four directions.

C.
De-selection of the mirror.


82



141



80

1.
Selection of the "day" position of
the mirror.

2.
Adjusting the mirror.

Automatic day/night model


A.
Light sensor.

B.
Adjusting the mirror.



82

14
FAMILIARISATION
SEEING CLEARLY

Lighting


Ring A

Ring B Raise or lower the lighting stalk passing
the point of resistance; the corresponding
direction indicators will fl ash for as long
as the stalk remains in this position.

Direction indicators


Switching on "AUTO"


)
Press the stalk down and release it.


Ring B: rear wiper



99





106

Lighting off.
Automatic illumination of head-
lamps.
Sidelamps.
Dipped / main beam headlamps.
Rear foglamp.
or
Front and rear foglamps. Park.
Intermittent wipe.
Wash-wipe.
Stalk A: windscreen wipers



105



Wipers


Switching off "AUTO"


)
Push the stalk up and return it to
position "0"
.



107




137


"Motorway" function
Press the lighting stalk up or down once,
without passing the point of resistance;
the corresponding direction indicators
will fl ash three times.
This function can be used at any speed,
but it is particularly useful when chang-
ing lane on high-speed roads.
