2013 NISSAN ROGUE SPECIAL EDITION ignition

provide restraint to the lower body.
The seat belts should be correctly worn and the
driver and passenger seated upright as far as
practical away from the side air bags. Rear seat
passengers should be seated as far away as
practical from the door finishers and side roof
rails. The side air bags and curtain and rollover
air bags inflate quickly in order to help protect
the occupants in the outboard seating positions.
Because of this, the force of the side air bags
and curtain and rollover air bags inflating can
increase the risk of injury if the occupant is too
close to, or is against, these air bag modules
during inflation. In a rollover, the curtain and
rollover air bags on both sides are designed to
inflate. Under both side-impact and rollover
situations, the curtain air bags will remain
inflated for a short period of time.
The side air bags and curtain and rollover
air bags operate only when the ignition
switch is in the ON position.
After turning the ignition switch to the ON
position, the supplemental air bag warning
light illuminates. The supplemental air bag
warning light will turn off after about 7
seconds if the systems are operational.

REPAIR AND REPLACEMENT PRO-
CEDURE
S35-D-110201-893056AA-962B-4966-BF1A-CC8E22C7E775The front air bags, side air bags, curtain and
rollover air bags and pretensioners are designed
to activate on a one-time-only basis. As a
reminder, unless it is damaged, the supplemen-
tal air bag warning light will remain illuminated
after inflation has occurred. Repair and replace-
ment of these systems should be done only by a
NISSAN dealer.
When maintenance work is required on the
vehicle, the front air bags, side air bags, curtain
and rollover air bags and pretensioners and
related parts should be pointed out to the
person performing the maintenance. The ignition
switch should always be in the LOCK position
when working under the hood or inside the
vehicle.

CHECKING BULBSS35-D-110201-509763A1-1CD5-4013-B64B-BA38C7221423With all doors closed, apply the parking brake
and turn the ignition switch to the ON position
without starting the engine. The following lights
will come on:

The seat belt warning light for the front
passenger will illuminate if the seat belt is not
fastened when the front passenger’s seat is
occupied. For about 5 seconds after the ignition
switch is in the ON position, the system does
not activate the warning light for the front
passenger.
See “Seat belts” in the “1. Safety — Seats, seat
belts and supplemental restraint system” section
for precautions on seat belt usage.

CHECKING BULBSS35-D-110201-509763A1-1CD5-4013-B64B-BA38C7221423With all doors closed, apply the parking brake
and turn the ignition switch to the ON position
without starting the engine. The following lights
will come on:

If the windows do not close automaticallyGUID-4366A858-91A3-4739-91C0-DACFB774B6DEIf the power window automatic function (closing
only) does not operate properly, perform the
following procedure to initialize the power
window system.
1. Turn the ignition switch to the ON position.
2. Close the door.
3. Open the window completely by operatingthe power window switch.
4. Pull the power window switch and hold it to close the window, and then hold the switch
more than 3 seconds after the window is
closed completely.
5. Release the power window switch. Operate the window by the automatic function to
confirm the initialization is complete.
If the power window automatic function does
not operate properly after performing the pro-
cedure above, have your vehicle checked by a
NISSAN dealer.
GUID-74BA112D-48AA-4F68-AF07-7C0714B7A644

When you carry the Intelligent Key with you, you
can lock or unlock all doors by pushing the door
handle request switch (driver’s or front passen-
ger’s)
*Aor lift gate request switch*Bwithin
the range of operation.
When you lock or unlock the doors, the hazard
indicator will flash and the horn (or the outside
chime) will sound as a confirmation. For details,
see “Setting hazard indicator and horn mode”
later in this section.
Locking doorsS35-D-110201-8EA6E22F-8395-4193-8EB5-5A139EFC2C101. Turn the ignition switch to the LOCK
position.*1
2. Carry the Intelligent Key with you.
3. Close all the doors.*2
4. Push the door handle request switch (dri- ver’s or front passenger’s)
*Aor the lift
gate request switch
*Bwhile carrying the
Intelligent Key with you.*3
5. All the doors and the lift gate will lock.
6. The hazard indicator flashes twice and the outside chime sounds twice.
*1: Doors will lock with the request switch while
the ignition switch is in the ACC or ON position.
*2: Doors will not lock with the request switch
while any door is open.
*3: Doors will not lock with the request switch when the Intelligent Key is left inside the vehicle.
However, when an Intelligent Key is inside the
vehicle, doors can be locked with another
registered Intelligent Key.
Unlocking doorsS35-D-110201-B5E33822-CFDC-4AA1-AD0F-54BBE3729FBB1. Push the door handle request switch*Aor
the lift gate request switch
*Bwhile
carrying the Intelligent Key with you.
2. The hazard indicator flashes once and out- side chime sounds once. The corresponding
door or the lift gate will unlock.
3. Push the request switch again within 5 seconds.
4. The hazard indicator flashes once and out- side chime sounds once again. All the doors
and the lift gate will unlock.
All doors will be locked automatically unless one
of the following operations is performed within 1
minute after pushing the request switch while
the doors are locked.
. Opening any doors.
. Pushing the ignition switch.
. Inserting the mechanical key into the ignition
switch.
During this 1-minute time period, if the UNLOCK

CONTINUOUSLY VARIABLE TRANS-
MISSION (CVT)
S35-D-110201-7E60201D-5BC1-4A77-B022-2EB741764885The ignition lock is designed so that the ignition
switch cannot be turned to the LOCK position
until the selector lever is moved to the P (Park)
position.
.When turning the ignition switch to the
LOCK position, make sure that the selector
lever is in the P (Park) position.
. When removing the key from the ignition
switch (if it is inserted) , make sure that the
selector lever is in the P (Park) position.
When the ignition switch cannot be turned to
the LOCK position:
1. The SHIFT P warning (if so equipped)
appears on the vehicle information display
and a chime sounds.
2. Move the selector lever to the P (Park) position.
3. Turn the ignition switch slightly in the ON direction.
4. Turn the ignition switch to the LOCK
position.
5. Remove the key, if it is inserted in the ignition switch.
If the ignition switch is turned to the LOCK
position, the selector lever cannot be moved
from the P (Park) position. The selector lever can be moved if the ignition switch is in the ON
position with the foot brake pedal depressed.
The OFF position*1is between the LOCK and
ACC positions, although it is not marked on the
ignition switch.
KEY POSITIONSS35-D-110201-06396A46-A2D1-4669-9D84-BF9FD54D3642
LOCK (0)S35-D-110201-3766F96D-1AD8-4926-9BF6-89EEF00D4EE3
Except for the Intelligent Key equipped
model:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407The key can only be removed from the ignition
switch at this position.
For the Intelligent Key equipped model:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407PUSH OFF -
The ignition switch is locked at this position.
PUSH ON -
The ignition switch will be unlocked while
carrying the Intelligent Key.
OFF (1)S35-D-110201-B63E5331-2F3F-4787-8587-50D4072E5971The power supply is turned off.
ACC (2)S35-D-110201-A6FC5348-7C27-49D0-A408-EB98CE521FDBThe electrical accessory power activates without
the engine turned on.
ON (3)S35-D-110201-9D3A8F96-70AB-4768-80FB-4789116DD6ADThe ignition system and the electrical accessory
power activate without the engine turned on.
START (4)S35-D-110201-79ACFB24-9ADC-4251-AB1C-2447A8767855The engine starter activates and the engine will
start. The ignition switch, when released, will
automatically turn to the ON position.
