660
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
23HTR50 AAir conditioning system
24WIP WSH RR30 ARear window wipers and washer
25H-LP CLN30 AHeadlight cleaner
26ST30 ASTARTER MTR
27H-LP HI25 ADIM relay, headlights, daytime run-
ning light system
28ALT-S7. 5 AALT
29TURN & HAZ15 A
Front turn signal light, rear turn signal
light, side turn signal light, meter turn
signal light
30D/L NO.125 ADoor lock motor, glass hatch opener
31ETCS10 AEFI ECU
32FUEL PMP15 AFPC
33TOW I N G30 ATo w i n g
34ALT140 A
Air conditioning system, AIR SUS,
headlight cleaner, towing, folding seat,
STOP, rear window defogger, MIR
HTR, CDS FAN, RR FOG, DEICER,
MG-CLT, RR SEAT HTR, STRG HTR,
J/B, INV, RR WIP, RR WSH
35P/ I - B80 AInjector, ignition, meter, EFI, A/F
heater, horn
FuseAmpereCircuit

When trouble arises5
683
GX460_OM_OM60J63U_(U)
5-1. Essential informationEmergency flashers............... 684
If your vehicle needs to be towed ............................ 685
If you think something is wrong ....................................... 691
Fuel pump shut off system.... 692 5-2. Steps to take in an
emergency
If a warning light turns on or a warning buzzer
sounds..................................... 693
If a warning message is displayed................................ 705
If you have a flat tire................ 726
If the engine will not start ..... 740
If the shift lever cannot be shifted from P ........................ 742
If you lose your keys ............... 743
If the electronic key does not operate properly........... 744
If the vehicle battery is discharged ............................. 746
If your vehicle overheats ...... 749
If the vehicle becomes stuck........................................ 752
If your vehicle has to be stopped in an
emergency ............................ 754

5
When trouble arises
689
5-1. Essential information
GX460_OM_OM60J63U_(U)
■Before emergency towingThe “ENGINE START STOP” switch must be in the ACCESSORY mode
(engine off) or IGNITION ON mode (engine running).
Put the four-wheel drive control switch in H4. (The center differential is
unlocked.)
Put the vehicle height in the N mode and press height control switch to
turn off the rear height control air suspension.
Shift the shift lever in N.
Release the parking brake.
CAUTION
■Caution while towing
●Use extreme caution when towing the vehicle.
Avoid sudden starts or erratic driving maneuvers which place excessive stress on
the emergency towing eyelets and the cables or chains. Always be cautious of the
surroundings and other vehicles while towing.
●Do not turn the “ENGINE START STOP” switch off.
Doing so will lock the steering wheel and prevent operation, possibly causing an
accident and result ing in death or serious injury.
●If the engine is not running, the power assi st for the brakes and steering will not
function, making steering and braking more difficult.
STEP1
STEP2
STEP3
STEP4
STEP5

692
5-1. Essential information
GX460_OM_OM60J63U_(U)
Fuel pump shut off system
Follow the procedure below to restart the engine after the system is acti-
vated.
Turn the “ENGINE START STOP ” switch to ACCESSORY mode
or turn it off.
Restart the engine.
NOTICE
■Before starting the engine
Inspect the ground under the vehicle.
If you find that fuel has leaked on to th e ground, the fuel system has been damaged
and is in need of repair. Do not restart the engine.
To minimize the risk of fuel leakage when the engine stalls or an airbag
inflates upon collision, the fuel pump shut off system stops supplying fuel to
the engine.
STEP1
STEP2

698
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
*1: Open door warning buzzer:
The open door warning buzzer sounds to alert one or more of the doors is not
fully closed (with the vehicle having reached a speed of 3 mph [5 km/h]).
( P. 7 0 9 )
*2: Driver’s and front passenger’s seat belt reminder buzzer:
The driver’s and front passenger’s seat belts reminder buzzer sounds to alert
the driver and front passenger that his/he r seat belt is not fastened. Once the
“ENGINE START STOP” switch is turned to IGNITION ON mode, the buzzer
sounds for 4 to 8 seconds. If the vehi cle reaches a speed of 12 mph (20 km/h),
the buzzer sounds intermittently for 10 seconds. Then, if the seat belt is still
unfastened, the buzzer will sound in a different tone for 20 more seconds.
Warning lightWarning light/DetailsCorrection procedure
Master warning light
A buzzer sounds and the
warning light comes on and
flashes to indicate that the
master warning system has
detected a malfunction.
 P. 7 0 5
Tire pressure warning light
When the light comes on:
Low tire inflation pressure.Adjust the tire inflation pres-
sure.
When the light comes on after
blinking for 1 minute:
Malfunction in the tire pres-
sure warning system.
Have the system checked by
your Lexus dealer.

706
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Have the vehicle inspected by your Lexus dealer immediately.
A buzzer sounds and a warning message is shown on the multi-informa-
tion display. Failure to investigate the cause of the following warnings may
lead to the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by your Lexus dealer immediately.
Wa r n i n g m e s s a g eDetails
Indicates that the automatic transmission fluid tem-
perature is too high
Stop the vehicle in a safe place, shift the shift lever to
P and wait until the message goes off. If the message
goes off, you may start the vehicle again.
Indicates a malfunction in the automatic transmission
system
Indicates a malfunction in the steering lock system

708
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
(Flashes)or
(Flashes)
(If equipped)
Indicates a malfunction in the radar cruise control
system Press the “ON-OFF” button once to deactivate the
system, and then press the button again to reactivate
the system.
(Flashes)
(If equipped)
Indicates a malfunction in the LDA system Stop the vehicle in a safe place. Turn the “ENGINE
START STOP” switch off and then turn it to IGNI-
TION ON mode again to reset the LDA system.
Wa r n i n g m e s s a g eDetails

710
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
*: The graphic is shown on the Rear height control air suspension display.
Indicates that the glass
hatch is not fully closed
*
If the vehicle reaches a
speed of 3 mph
(5 km/h),
flashes and a buzzer
sounds to indicate that
the glass hatch is not yet
fully closed.
Close the glass hatch.
(Flashes)
(If equipped)
Indicates that the moon
roof is not fully closed
(with the “ENGINE
START STOP” switch off,
and the driver’s door
open)
Close the moon roof.
Indicates that the parking
brake is still engaged If the vehicle reaches a
speed of 3 mph
(5 km/h),
flashes and a buzzer
sounds to indicate that
the parking brake is still
engaged.
Release the parking
brake.
Wa r n i n g m e s s a g eDetailsCorrection procedure
