GS450h_U (OM30D01U)
3-5. Opening, closing the windows and moon roof
Power windows .............................164
Moon roof ....................................... 167
4-1. Before driving Driving the vehicle ...................... 172
Cargo and luggage.................... 183
Vehicle load limits ....................... 186
Trailer towing ................................. 187
Dinghy towing .............................. 188
4-2. Driving procedures Power (ignition) switch ............. 189
EV drive mode ..............................196
Hybrid transmission ................... 199
Turn signal lever .......................... 205
Parking brake .............................. 207
Brake Hold .................................... 210
Horn ..................................................212
4-3. Operating the lights and wipers
Headlight switch ..........................213
Fog light switch ............................ 218
Windshield wipers and washer ..................................219
Headlight cleaner switch........ 226 4-4. Refueling
Opening the fuel tank cap ......227
4-5. Using the driving support systems
Cruise control ............................. 232
Dynamic radar cruise control............................ 236
LKA (Lane-Keeping Assist) ............251
Intuitive parking assist ................ 261
Rear view monitor system ....... 274
Driving mode select switch ... 286
Driving assist systems .............. 289
PCS (Pre-Collision System) ......... 296
BSM (Blind Spot Monitor) .............305
Lexus night view ............................ 311
4-6. Driving tips Hybrid vehicle driving tips ....... 317
Winter driving tips .......................319
4Driving
Page 171 of 860
171
GS450h_U (OM30D01U)
4Driving
4-1. Before driving Driving the vehicle .......................172
Cargo and luggage .................... 183
Vehicle load limits ....................... 186
Trailer towing ................................. 187
Dinghy towing...............................188
4-2. Driving procedures Power (ignition) switch.............. 189
EV drive mode ............................. 196
Hybrid transmission ................... 199
Turn signal lever ......................... 205
Parking brake ............................... 207
Brake Hold ..................................... 210
Horn.................................................. 212
4-3. Operating the lights and wipers
Headlight switch .......................... 213
Fog light switch............................. 218
Windshield wipers and washer .................................. 219
Headlight cleaner switch ........ 226 4-4. Refueling
Opening the fuel tank cap ..... 227
4-5. Using the driving support systems
Cruise control ............................. 232
Dynamic radar cruise control ............................ 236
LKA (Lane-Keeping Assist) ........... 251
Intuitive parking assist ................ 261
Rear view monitor system ....... 274
Driving mode select switch ... 286
Driving assist systems............... 289
PCS (Pre-Collision System).......... 296
BSM (Blind Spot Moni tor)..............305
Lexus night view ............................ 311
4-6. Driving tips Hybrid vehicle driving tips........317
Winter driving tips ...................... 319
Page 189 of 860
189
GS450h_U (OM30D01U)4-2. Driving procedures
4
Driving
Power (ignition) switch
Check that the parking brake is set.
Check that the shift lever is set in P.
Firmly depress the brake pedal.
will be displayed on the multi-information display.
If it is not displayed, the hybrid system cannot be started.
Press the power switch.
Continue depressing the brake pedal
until the hybrid system is completely
started.
The hybrid system can be started from
any power switch mode.
Check that the “READY” indicator is on.
The vehicle will not move when the “READY” indicator is off.
Performing the following operations when carrying the electronic key
on your person starts the hybrid system or changes power switch
modes.
Starting the hybrid system
1
2
3
4
5
Page 228 of 860
228
GS450h_U (OM30D01U)
4-4. Refueling
CAUTION
■When refueling the vehicle
Observe the following precautions while refueling the vehicle. Failure to do so may
result in death or serious injury.
●After exiting the vehicle and before opening the fuel door, touch an unpainted
metal surface to discharge any static electricity. It is important to discharge static
electricity before refueling because sparks resulting from static electricity can
cause fuel vapors to ignite while refueling.
●Always hold the grips on the fuel tank cap and turn it slowly to remove it.
A whooshing sound may be heard when the fuel tank cap is loosened. Wait until
the sound cannot be heard before fully removing the cap. In hot weather, pressur-
ized fuel may spray out the filler neck and cause injury.
●Do not allow anyone that has not discharged static electricity from their body to
come close to an open fuel tank.
●Do not inhale vaporized fuel.
Fuel contains substances that are harmful if inhaled.
●Do not smoke while refueling the vehicle.
Doing so may cause the fuel to ignite and cause a fire.
●Do not return to the vehicle or touch any person or object that is statically
charged.
This may cause static electricity to build up, resulting in a possible ignition hazard.
■When refueling
Observe the following precautions to prevent fuel overflowing from the fuel tank:
●Securely insert the fuel nozzle into the fuel filler neck.
●Stop filling the tank after the fuel nozzle automatically clicks off.
●Do not top off the fuel tank.
NOTICE
■Refueling
Do not spill fuel during refueling.
Doing so may damage the vehicle, such as causing the emission control system to
operate abnormally or damaging fuel syst em components or the vehicle’s painted
surface.
Page 787 of 860
GS450h_U (OM30D01U)
7878-1. Specifications
8
Vehicle specifications
Cooling system
Capacity
Gasoline
engine9.9 qt. (9.4 L, 8.3 Imp.qt.)
Pow e r
control unit3.3 qt. (3.1 L, 2.7 Imp.qt.)
Coolant type
Use either of the following:• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-silicate, non-amine, non- nitrite, and non-borate
coolant with long-life hybrid organic acid tech-
nology
Do not use plain water alone.
Ignition system
Spark plug
MakeDENSO FK20HBR8
Gap0.031 in. (0.8 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.
Page 845 of 860
845Alphabetical index
GS450h_U (OM30D01U)
Energy monitor ........................................ 110
EngineAccessory mode................................. 190
Compartment ......................................637
Engine switch ........................................ 189
Hood ........................................................634
How to start the hy brid system .... 189
Identification number .......................783
Ignition switch (power switch).................................. 189
Overheating ......................................... 774
Power switch......................................... 189
Engine compartment cover ............. 638
Engine coolant....................................... 642 Capacity ................................................. 787
Checking................................................642
Preparing and checking before winter ..................................... 319
Engine coolant temperature gauge ........................................................ 89
Engine oil ................................................. 639 Capacity ................................................ 785
Checking............................................... 639
Oil level warning message ........... 733
Oil pressure warning message ........................... 722
Preparing and checking before winter ..................................... 319 Engine oil maintenance data ............624
Engine switch ...........................................189
EPS
(Electronic Power Steering) ........ 289Function .................................................. 289
Warning light ......................................... 712
Warning message............................. 726
EV drive mode ........................................ 196
Event data recorder (EDR).....................11
First-aid kit storage net ........................581
Flat tire ....................................................... 749
Floor mats................................................... 28
Fluid Brake........................................................ 789
Hybrid transmission .........................788
Washer ................................................... 646
Fog lights.................................................... 218 Replacing light bulbs ...................... 689
Switch ........................................................218
Wattage ................................................... 791
Footwell light ............................................ 571
Front passenger occupant classification system ............................49
Front personal lights ............................572
F
Page 847 of 860
847Alphabetical index
GS450h_U (OM30D01U)
HeatersAir conditioning system ..................364
Heated steering wheel ...................588
Seat heaters ......................................... 590
Outside rear view mirrors ............ 384
High-voltage components ...................74
Hood .......................................................... 634 Open ........................................................634
Warning message .............................728
Hooks Cargo hooks ......................................... 581
Coat hooks ...........................................597
Luggage hook ...................................... 581
Retaining hooks (floor mat) ............. 28
Utility hook ........................................... 599
Horn ............................................................. 212
Hybrid battery (traction battery) .......74
Hybrid battery (traction battery) air vents .................................................... 75
Hybrid system ........................................... 70 Emergency shut off system.............. 75
Energy monitor/consumption screen ...................... 109
EV drive mode..................................... 196
High voltage components ............... 74
Hybrid System Indicator ................... 92
Hybrid system precautions.............. 74
Hybrid vehicle driving tips...............317
If the hybrid system will not start........................................ 762
Overheating ......................................... 774
Power (ignition) switch .................... 189
Starting the hybrid system .............. 189
Vehicle proximity notification system ....................................................... 71 Hybrid System Indicator .......................92
Hybrid transmission .............................. 199
If the shift lever cannot be shifted from P ............ 764
Paddle shift switches..........................201
S mode.................................................... 202
I/M test ..................................................... 630
Identification Engine ..................................................... 783
Vehicle .................................................... 783
Ignition switch (power switch) ..........189
Illuminated entry system ....................573
Immobilizer system ................................. 79
Indicators .....................................................87
Initialization Maintenance ........................................ 624
Moon roof ...............................................169
Power windows....................................165
Tire pressure warning system ...............................653
Initiators (tire pressure warning system) ................................ 659
Inside door handle lights ..................... 571
Inside rear view mirror......................... 159
Instrument panel light control .............. 91
Interior lights ............................................ 571
Intuitive parking assist .......................... 261 Function .................................................... 261
Warning message..................723, 734
I
Page 854 of 860
854Alphabetical index
GS450h_U (OM30D01U)
Spare tire.................................................. 749Inflation pressure ............................... 790
Storage location ................................ 750
Spark plug ............................................... 787
Specifications ......................................... 782
Speedometer ............................................ 89
Sport mode ............................................. 286
Steering lock ............................................192 Column lock release ......................... 193
Steering lock system warning message ........................... 747
Steering wheel ........................................ 158 Adjustment ............................................. 158
Audio switches ................................... 503
Heated steering wheel ...................588
Power easy access system ............ 153
Steering wheel position memory.............................. 150
Stop lights Replacing light bulbs ........................697
Storage feature ..................................... 574
Stuck If the vehicle becomes stuck ........ 778
Sun shade Rear.......................................................... 594
Rear door.............................................. 595
Roof............................................................ 168
Sun visors .................................................583 Switches
AFS OFF switch ................................... 215
Audio remote control switches ..............................................503
Brake hold switch................................210
BSM (Blind spot monitor) switch ...................................................305
Cruise control switch .......... 232, 236
“DISP” button.......................................... 95
Door lock switches ............................. 137
Driving mode select switch .......... 286
Driving position memory switches ............................................... 150
Emergency flashers switch ........... 702
EV drive mode switch ......................196
Fog light switch .....................................218
Garage door opener switches ............................................. 600
Headlight cleaner switch ............... 226
Heated steering wheel switch .................................................. 588
HUD (Head-up display) switches ................................................102
Ignition switch....................................... 189
Intuitive parking assist........................ 261
Lexus night view switch......................311
Light switch............................................. 213
LKA (Lane-Keeping Assist) switch ................................................... 253
Moon roof switches ........................... 167
Outside rear view mirror switches ................................................. 161
