6877-2. Steps to take in an emergency
GS350_U (OM30C34U)
7
When trouble arises
The following warning indicates the possibility of damage to the vehicle
that may lead to an acc ident. Immediately stop th e vehicle in a safe place
and contact your Lexus dealer.
Failure to investigate the cause of th e following warnings may lead to the
system operating abnormally and possib ly cause an accident. Have the
vehicle inspected by your Lexus dealer immediately.
Stop the vehicl e immediately.
Warning lightWarning light/Details
Charging system warning light
Indicates a malfunction in the vehicle’s charging system
Have the vehicle inspected by your Lexus dealer immediately.
Warning lightWarning light/Details
(U.S.A.)
(Canada)
Malfunction indicator lamp Indicates a malfunction in:
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic automatic transmission control system
SRS warning lightIndicates a malfunction in:
• The SRS airbag system;
• The front passenger occupant classification system; or
• The seat belt pretensioner system
(U.S.A.)
(Canada)
ABS warning light Indicates a malfunction in:
•The ABS; or
• The brake assist system
Electric power steering system warning lightIndicates a malfunction in the EPS (Electric Power Steering)
system

6947-2. Steps to take in an emergency
GS350_U (OM30C34U)
CAUTION
■If both the ABS and the brake system warning lights remain on
Stop your vehicle in a safe place immediately and contact your Lexus dealer. The
vehicle will become extremely unstable during braking, and the ABS system may
fail, which could cause an accident resulting in death or serious injury.
■When the electric power steering system warning light comes on
The steering wheel may become extremely heavy.
If the steering wheel becomes heavier than usual when operating, hold firmly and
operate using more force than usual.
■If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could cause a loss of
vehicle control and result in death or serious injury.
●Stop your vehicle in a safe place as soon as possible. Adjust the tire inflation pres-
sure immediately.
●If the tire pressure warning light comes on even after tire inflation pressure adjust-
ment, it is probable that you have a flat tire. Check the tires. If a tire is flat, change
it with the spare tire and have the flat tire repaired by the nearest Lexus dealer.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could
lose control of the steering wheel or the brakes.
■If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.

7027-2. Steps to take in an emergency
GS350_U (OM30C34U)
Indicates a malfunction in the parking brake system
Indicates a malfunction in the EPS (Electric Power
Steering) system
Indicates a malfunction in the VGRS
Indicates a malfunction in the DRS
Wa r n i n g m e s s a g eDetails
(If equipped)
(If equipped)

7087-2. Steps to take in an emergency
GS350_U (OM30C34U)
Indicates that there is a
high possibility of a frontal
collision, or that the pre-
collision braking function
is operatingAt the same time,
will appear
on the head-up dis-
play too (the image
flashes).
Slow the vehicle by
applying the brakes.
Indicates that the LKA
(Lane-Keeping Assist) is
suspended
•The camera sensor temperature is higher
than the operation tem-
perature range.
•The power steering system operation is
restricted.
Restart the LKA after
driving for a while.
Wa r n i n g m e s s a g eDetailsCorrection procedure
(Flashes)
(If equipped)
(If equipped)

772
GS350_U (OM30C34U)
8-1. Specifications
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sureTire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Maximum inflation pres-
sureThe maximum cold inflated pressure to which a tire
may be inflated, shown on the sidewall of the tire
Recommended inflation
pressureCold tire inflation pressure recommended by a man-
ufacturer
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic transmis-
sion, power steering, power brakes, power windows,
power seats, radio and heater, to the extent that these
items are available as factory-installed equipment
(whether installed or not)
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil and
coolant, and if so equipped, air conditioning and
additional weight optional engine
Maximum loaded vehicle
weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant weight150 lb. (68 kg) times the number of occupants speci-
fied in the second column of Table 1
* that follows
Occupant distributionDistribution of occupants in a vehicle as specified in
the third column of Table 1
* below
Production options weight
The combined weight of installed regular production
options weighing over 5 lb. (2.3 kg) in excess of the
standard items which they replace, not previously
considered in curb weight or accessory weight,
including heavy duty brakes, ride levelers, roof rack,
heavy duty battery, and special trim
RimA metal support for a tire or a tire and tube assembly
upon which the tire beads are seated

813Alphabetical index
GS350_U (OM30C34U)
Cup holders ............................................ 555
Curtain shield airbags ........................... 37
Customizable features ........................ 777
Daytime running light system ............193
DefoggerFront windshield .................................352
Outside rear view mirrors ............ 365
Rear window ....................................... 365
Differential Front differential ................................. 758
Rear differential .................................. 758
Dimension ............................................... 752
Dinghy towing..........................................170
Display Dynamic radar cruise control........213
LKA (Lane-Keeping Assist) ......... 232
Multi-information display .................. 82
Remote Touch screen .................... 308
Trip information .....................................83
Warning message .............................697
Do-it-yourself maintenance ............. 609
Door courtesy lights Location ................................................. 548
Wattage ....................................................761
Doors ............................................................ 117 Automatic door locking and unlocking system...................... 119
Door glasses ......................................... 145
Door lock .................................................. 117
Open door warning buzzer.......... 105
Open door warning light.............. 689
Outside rear view mirrors ...............142
Rear door child-protector................ 118 Driver’s seat position memory..........130
Driving ........................................................ 154
Break-in tips ...........................................156
Correct driving posture .................... 28
Driving mode select switch .......... 263
Procedures .............................................154
Winter drive tips ................................ 298
DRS (Dynamic Rear Steering) ........269 Function .................................................. 269
Warning message............................. 702
DVD player ...................................412, 420
Dynamic radar cruise control ........... 213 Function .................................................... 213
Warning message.................700, 707
Dynamic Rear Steering (DRS) ........269 Function .................................................. 269
Warning message............................. 702
Eco drive mode......................................263
Eco Driving Indicator .................... 88, 92
EDR (Event data recorder)................... 10
Electric Power Steering (EPS) ........269 Function .................................................. 269
Warning light ....................................... 687
Warning message............................. 702
Electronic key ........................................... 98 Battery-saving function ....................107
If the electronic key does not operate properly ............................ 740
Replacing the battery ...................... 646
D
E

814Alphabetical index
GS350_U (OM30C34U)
Emergency, in case ofIf the electronic key does not operate properly ........740
If the engine will not start................735
If the parking brake cannot be released........................738
If the shift lever cannot be shifted from P ............ 737
If the vehicle battery is discharged ......................................... 743
If the warning buzzer sounds................................................. 686
If the warning light turns on.......... 686
If the warning message is displayed ........................................697
If you have a flat tire .......................... 722
If you think something is wrong.............................................. 684
If your vehicle becomes stuck ...................................................... 749
If your vehicle has to be stopped in an emergency .......... 677
If your vehicle needs to be towed ...................................... 678
If your vehicle overheats ................ 747
Emergency flashers ............................. 676
Engine Accessory mode.................................. 172
Compartment ....................................... 615
Engine switch .......................................... 171
Hood ......................................................... 612
How to start the engine ..................... 171
Identification number .......................753
If the engine will not start................735
Ignition switch (engine switch) ................................... 171
Overheating ......................................... 747 Engine compartment cover............... 616
Engine coolant ...................................... 620
Capacity ................................................. 756
Checking ............................................... 620
Preparing and checking before winter .................................... 298
Engine coolant temperature gauge ......................................................... 79
Engine immobilizer system ................. 68
Engine oil ................................................... 617 Capacity ................................................. 754
Checking ................................................. 617
Oil level warning message ........... 706
Oil pressure warning message.......................... 698
Preparing and checking before winter .................................... 298
Engine oil maintenance data ........... 602
Engine switch .............................................171
Enhanced VSC ..................................... 268
EPS (Electronic Power Steering) .........269Function .................................................. 269
Warning light ....................................... 687
Warning message............................. 702
Event data recorder (EDR)................... 10

816Alphabetical index
GS350_U (OM30C34U)
Hands-free system (for cellular phone) ........................... 485
HD Radio
® system .............................. 394
Head restraints ........................................136
Headlights ................................................ 190 Adaptive Front-lighting System (AFS) .................................... 192
Discharge headlights precautions ........................................673
Headlight leveling warning message .......................... 700
Light switch ............................................ 190
Replacing light bulbs ..........................671
Wattage ....................................................761
Headlights aim .........................................661
Headlights cleaner............................... 203
Head-up display....................................... 90
Heaters Air conditioning system ..................345
Heated steering wheel ................... 566
Seat heaters ......................................... 568
Outside rear view mirrors ............ 365
Hill-start assist control ........................ 276
Horn ............................................................ 189
Hood ............................................................612 Open ......................................................... 612
Warning message .............................704
Hooks Cargo hooks ....................................... 558
Coat hooks ...........................................576
Retaining hooks (floor mat) ............. 26
Luggage hook .................................... 558
Utility hook ........................................... 578 I/M test ..................................................... 608
Identification
Engine ..................................................... 753
Vehicle .................................................... 753
Ignition switch (engine switch) ...........171
Illuminated entry system ................... 550
Immobilizer system ................................ 68
Indicators ..................................................... 77
Initialization Maintenance ........................................ 602
Moon roof .............................................. 150
Power windows....................................146
Tire pressure warning system .................................631
Initiators (tire pressure warning system) .................................637
Inside door handle lights ................... 548
Inside rear view mirror......................... 140
Instrument panel light control ............ 80
Interior lights .......................................... 548
Intuitive parking assist ........................ 238 Function .................................................. 238
Warning message.................700, 707
Jack Positioning a floor jack......................613
Vehicle-equipped jack ....................723
Jack handle ..................................................723
Jam protection function Moon roof ...............................................149
Power trunk opener and closer ............................................ 123
Power windows....................................146
HI
J
