2013 Lexus ES350 maintenance

ES350 300h_OM_OM33A01U_(U)
Pictorial indexSearch by illustration
1For safety
and securityMake sure to read through them
2Instrument clusterHow to read the gauges and meters, the variety of
warning lights and indicators, etc.
3Operation of each
componentOpening and closing the doors and windows,
adjustment before driving, etc.
4DrivingOperations and advices which are necessary for driving
5Interior featuresUsage of the interior features, etc.
6Maintenance
and careCaring for your vehicle and maintenance procedures
7When trouble
arisesWhat to do in case of malfunction or emergency
8Vehicle
specificationsVehicle specifications, customizable features, etc.
9For ownersReporting safety defects for U.S. owners, and seat belt
and SRS airbag instructio ns for Canadian owners
IndexSearch by symptom
Search alphabetically

TABLE OF CONTENTS6
ES350 300h_OM_OM33A01U_(U)6-1. Maintenance and care
Cleaning and protecting the vehicle exterior ................ 650
Cleaning and protecting the vehicle inte rior.................. 654
6-2. Maintenance Maintenance requirements .............................657
General maintenance.............. 660
Emission inspection and maintenance (I/M)
programs .................................... 664
6-3. Do-it-yourself maintenance Do-it-yourself service precautions................................ 665
Hood ............................................... 669
Positioning a floor jack..............670
Engine compartment ................673
12-volt battery (hybrid vehicles) ...................... 690
Tires.................................................. 694
Tire inflation pressure ............... 703
Wheels ........................................... 706
Air conditioning filter ............... 708
Electronic key battery................710
Checking and replacing fuses................................................ 712
Light bulbs ..................................... 724 7-1. Essential information
Emergency flashers ................... 740
If your vehicle has to be stopped in an emergency.......741
7-2. Steps to take in an emergency If your vehicle needs to be towed................................. 743
If you think something is wrong ................. 749
Fuel pump shut off system (gasoline vehicles) .................. 750
If a warning light turns on or a warning buzzer sounds....... 751
If a warning message is displayed ...................................761
If you have a flat tire .................. 784
If the engine will not start (gasoline vehicles) ................... 797
If the hybrid system will not start (hybrid vehicles)............ 799
If the shift lever cannot be shifted from P ...................... 801
If the electronic key does not operate properly .....................802
6Maintenance and care7When trouble arises

7
1
8 7
6
5
4
3
2
ES350 300h_OM_OM33A01U_(U)
9
If the 12-volt battery is discharged (gasoline
vehicles) ......................................805
If the 12-volt battery is discharged (hybrid
vehicles) ......................................809
If your vehicle overheats (gasoline vehicles) ................... 813
If your vehicle overheats (hybrid vehicles) ....................... 816
If the vehicle becomes stuck ............................................. 820
8-1. Specifications Maintenance data (fuel, oil level, etc.) .................. 824
Fuel information.......................... 837
Tire information...........................840
8-2. Customization Customizable features ............ 852
8-3. Items to initialize Items to initialize ......................... 865 Reporting safety defects
for U.S. owners.....................................868
Seat belt instructions for Canadian owners
(in French) .............................................. 869
SRS airbag instructions for Canadian owners
(in French) ................................................ 871
What to do if... (Troubleshooting) ............................... 882
Alphabetical index ............................... 888
8Vehicle specifications
9For owners
Index
For vehicles with a navigation sy stem, refer to the “Navigation System
Owner’s Manual” for information rega rding the equipment listed below.
• Navigation system
• Air conditioning controls
• Windshield wiper de-icer
• Audio/video system
• Rear window and outside rear view mirror defogging
• Lexus Enform with Safety Connect

731-2. Hybrid system
ES350 300h_OM_OM33A01U_(U)
1
For safety and security
■After the 12-volt battery has discharged or has been changed or removed
The gasoline engine may not stop even if the vehicle is running on the hybrid battery
(traction battery). If this continues for a few days, contact your Lexus dealer.
■Sounds and vibrations specific to a hybrid vehicles
There may be no engine sounds or vibration even though the vehicle is able to move.
For safety, apply the parking brake and make sure to shift the shift position to P when
parked.
The following sounds or vibrations may occur when the hybrid system is operating
and are not a malfunction:
●Motor sounds may be heard from the engine compartment.
●Sounds may be heard from the hybrid battery (traction battery) behind the rear
seats when the hybrid system starts or stops.
●Sounds from the hybrid system may be heard when the trunk lid is open.
●Sounds may be heard from the hybrid tran smission when the hybrid system starts
or stops.
●Engine sounds may be heard when accelerating sharply.
●Sounds may be heard due to regenerative braking when the brake pedal is
depressed.
●Vibration may be felt when the gasoline engine starts or stops.
●Cooling fan sounds may be heard from the air intake vent on rear left seat.
■Vehicle proximity notification system
In the following cases, the vehicle proximity notification system may be difficult for
surrounding people to hear.
●In very noisy areas
●In the wind or the rain
Also, as the vehicle proximity notification system is installed on the front of the vehi-
cle, it may be more difficult to hear from the rear of the vehicle compared to the
front.
■Maintenance, repair, recycling, and disposal
Contact your Lexus dealer regarding main tenance, repair, recycling and disposal.
Do not dispose of the vehicle yourself.
■Customization
Settings (e.g. on/off operation of the EV indicator) can be changed.
(Customizable features: P. 8 5 2 )

801-3. Theft deterrent system
ES350 300h_OM_OM33A01U_(U)
Engine immobilizer system (gasoline vehicles)
The indicator light flashes after the
“START STOP ENGINE” switch
has been turned off to indicate that
the system is operating.
The indicator light stops flashing
after the “START STOP ENGINE”
switch has been turned to ACCES-
SORY or IGNITION ON mode to
indicate that the system has been
canceled.
■System maintenance
The vehicle has a maintenance-free type engine immobilizer system.
■Conditions that may cause the system to malfunction
●If the grip portion of the key is in contact with a metallic object
●If the key is in close proximity to or touching a key to the security system (key with a
built-in transponder chip) of another vehicle
The vehicle’s keys have built-in tr ansponder chips that prevent the
engine from starting if a key has not been previously registered in the
vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehicle.

821-3. Theft deterrent system
ES350 300h_OM_OM33A01U_(U)
Immobilizer system (hybrid vehicles)
The indicator light flashes after the
“POWER” switch has been turned
off to indicate that the system is
operating.
The indicator light stops flashing
after the “POWER” switch has been
turned to ACCESSORY or ON
mode to indicate that the system has
been canceled.
■System maintenance
The vehicle has a maintenance-free type immobilizer system.
■Conditions that may cause the system to malfunction
●If the grip portion of the key is in contact with a metallic object
●If the key is in close proximity to or touching a key to the security system (key with a
built-in transponder chip) of another vehicle
The vehicle’s keys have built-in tr ansponder chips that prevent the
hybrid system from starting if a key has not been previously registered
in the vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehicle.

851-3. Theft deterrent system
ES350 300h_OM_OM33A01U_(U)
1
For safety and security
■System maintenance
The vehicle has a maintenance-free type alarm system.
■Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the fol-
lowing:
●Nobody is in the vehicle.
●The windows and moon roof are closed before the alarm is set.
●No valuables or other personal items are left in the vehicle.
■Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
●The 12-volt battery is recharged or replaced when the vehicle is locked. ( P. 8 0 7 )
●A person inside the vehicle opens a door,
the trunk or hood.
Gasoline vehiclesHybrid vehicles

268
ES350 300h_OM_OM33A01U_(U)
4-5. Using the driving support systems
CAUTION
■Before using the LDA system
Do not rely solely on the LDA system. The LDA system does not drive the vehicle
automatically, nor does it reduce the amount of care you need to take. As such, the
driver must always assume full responsibility for understanding his/her surround-
ings, for operating the steering wheel to correct the driving line, and for driving
safely.
Inappropriate or negligent driving could lead to an accident.
■To avoid operating the LDA by mistake
Switch the LDA system off using the “LDA” switch when not in use.
■Situations unsuitable for LDA system
Do not use LDA system in any of the following situations.
Otherwise, the system may not function co rrectly and could result in an accident.
●When driving with tire chains, a spare tire, or similar equipment
●When there are objects or structures along the roadside that might be misinter-
preted as lane markers (such as guardrails, curb, reflector posts, etc.)
●When driving on snowy roads
●When pavement lane markers are difficult to see due to rain, snow, fog, etc.
●When there are visible lines on the pavement from road repairs, or if the remains
of old lane markers are still visible on the road
●When driving on a road with lane closures due to maintenance, or when driving
in a temporary lane
