ES350 300h_OM_OM33A01U_(U)
5-2. Using the air conditioning system and defogger
Control panel
Air conditioning operation
screen
Outside temperature display
Automatic mode button
“OFF” button
Fan speed control button
Air outlet selector button
Windshield defogger button
DUAL mode button Passenger’s side temperature
control buttons
Passenger’s side temperature
display
Outside/recirculated air mode
button
Driver’s side temperature dis-
play
Driver’s side temperature con-
trol buttons1
2
3
4
5
6
7
8
9
10
11
12
13

379
ES350 300h_OM_OM33A01U_(U)
5-3. Using the Lexus Display Audio system
5
Interior features
Using the radio
Press the “RADIO” button or “AUDIO” button on the Lexus Display
Audio controller and then select “AM”, “FM” or “SAT”.
Control panel
Audio control screen
Mute button
Frequency adjustment knob
Seek/preset station selector
button AM/FM/SAT mode buttons
Po w e r
Vo l u m e1
2
3
4
5
6
7

496
ES350 300h_OM_OM33A01U_(U)
5-4. Using the audio system
Using the radio
Ty p e A
AMFM/SAT mode buttons
Scan button
Seek button
Channel category button
Frequency adjustment (AM/FM
mode) and channel (SAT mode)
knob Traffic information button
Preset station buttons
Radio text message button
Po w e r
Vo l u m e1
2
3
4
5
6
7
8
9
10

ES350 300h_OM_OM33A01U_(U)
4975-4. Using the audio system
5
Interior features
Ty p e B
AMFM buttons
Seek button
Channel category button
Frequency adjustment knob Traffic information button
Preset station buttons
Radio text message button
Po w e r
Vo l u m e1
2
3
4
5
6
7
8
9

514
ES350 300h_OM_OM33A01U_(U)
5-4. Using the audio system
Playing MP3 and WMA discs
Ty p e A
Eject button
Load button
Playback button
Search playback button
File selector button
Disc selector button
File selector knobFolder selector buttons
Playback/Pause button
Repeat play button
Random playback button
Text button
Po w e r
Vo l u m e1
2
3
4
5
6
7
8
9
10
11
12
13
14

ES350 300h_OM_OM33A01U_(U)
5155-4. Using the audio system
5
Interior features
Ty p e B
Eject button
Load button
Playback button
File selector button
Disc selector button
File selector knob
Folder selector buttonsPlayback/Pause button
Repeat play button
Random playback button
Text button
Po w e r
Vo l u m e1
2
3
4
5
6
7
8
9
10
11
12
13

532
ES350 300h_OM_OM33A01U_(U)
5-4. Using the audio system
Operating a USB memory
Ty p e A
Connecting a USB memory enables you to enjoy music from the vehi-
cle speakers.
Playback button
Search playback button
File selector button
File selector knob
Folder selector buttonsPlayback/Pause button
Repeat play button
Random playback button
Text button
Po w e r
Vo l u m e1
2
3
4
5
6
7
8
9
10
11

ES350 300h_OM_OM33A01U_(U)
5335-4. Using the audio system
5
Interior features
Ty p e B
Playback button
File selector button
File selector knob
Folder selector buttons
Playback/Pause buttonRepeat play button
Random playback button
Text button
Po w e r
Vo l u m e1
2
3
4
5
6
7
8
9
10
