6-3. Do-it-yourself maintenance
6
Maintenance and care
Engine compartment
Gasoline vehicles (2GR-FE engine)
Washer fluid tank (P. 689)
Engine oil filler cap (P. 6 7 8 )
Engine oil level dipstick (P. 6 76 )
Engine coolant reservoir (P. 6 8 1 ) Brake fluid reservoir
(P. 684)
Fuse box ( P. 712)
12-volt battery ( P. 685)
Electric cooling fans
Condenser ( P. 683)
Radiator ( P. 683)1
2
3
4
5
6
7
8
9
10

674
ES350 300h_OM_OM33A01U_(U)
6-3. Do-it-yourself maintenance
Hybrid vehicles (2AR-FXE engine)
■12-volt battery (hybrid vehicles)
P. 6 9 0
Washer fluid tank ( P. 689)
Fuse boxes ( P. 712)
Power control unit coolant
reservoir ( P. 6 8 1 )
Engine oil level dipstick (P. 6 76 )
Engine oil filler cap (P. 6 7 8 ) Engine coolant reservoir
(P. 6 8 1 )
Brake fluid reservoir (P. 684)
Power control unit coolant
radiator ( P. 683)
Electric cooling fans
Condenser ( P. 683)
Engine coolant radiator (P. 683)1
2
3
4
5
6
7
8
9
10
11

ES350 300h_OM_OM33A01U_(U)
6816-3. Do-it-yourself maintenance
6
Maintenance and care
The coolant level is satisfactory if it is between the “FULL” and “LOW”
lines on the reservoir when the engine is cold.
■Engine coolant reservoir
Reservoir cap
“FULL” line
“LOW” line
If the level is on or below the
“LOW” line, add coolant up to the
“FULL” line. ( P. 8 1 3 , 8 1 6 )
■Power control unit coolant reservoir (hybrid vehicles)
Reservoir cap
“FULL” line
“LOW” line
If the level is on or below the
“LOW” line, add coolant up to the
“FULL” line. ( P. 8 1 6 )
Coolant
1
2
3
1
2
3

682
ES350 300h_OM_OM33A01U_(U)
6-3. Do-it-yourself maintenance
■Coolant selection
Only use “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol
based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life
hybrid organic acid technology.
U.S.A.:
“Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deionized
water. (Minimum temperature: -31 F [-35C])
Canada:
“Toyota Super Long Life Coolant” is a mixture of 55% coolant and 45% deionized
water. (Minimum temperature: -44 F [-42C])
For more details about coolant, contact your Lexus dealer.
■If the coolant level drops within a short time of replenishing
Visually check the radiator, hoses, engine/power control unit coolant reservoir caps,
drain cock and water pump.
If you cannot find a leak, have your Lexus dealer test the cap and check for leaks in
the cooling system.
CAUTION
■When the engine is hot
Do not remove the engine/power control unit coolant reservoir caps.
The cooling system may be under pressure and may spray hot coolant if the cap is
removed, causing serious injuries, such as burns.
NOTICE
■When adding coolant
Coolant is neither plain water nor straight antifreeze. The correct mixture of water
and antifreeze must be used to provide proper lubrication, corrosion protection
and cooling. Be sure to read the antifreeze or coolant label.
■If you spill coolant
Be sure to wash it off with water to prevent it from damaging parts or paint.

813
ES350 300h_OM_OM33A01U_(U)
7
When trouble arises
7-2. Steps to take in an emergency
If your vehicle overheats (gasoline vehicles)
Follow the correction procedure as described below.Stop the vehicle in a safe place and turn off the air conditioning system,
and then stop the engine.
If you see steam:
Carefully lift the hood after the steam subsides.
If you do not see steam:
Carefully lift the hood.
After the engine has cooled
down sufficiently, inspect the
hoses and radiator core (radia-
tor) for any leaks.
If a large amount of coolant leaks,
immediately contact your Lexus
dealer.
The coolant level is satisfactory if
it is between the “FULL” and
“LOW” line on the reservoir.
Reservoir cap
“FULL”
“LOW”
The following may indicate that your vehicle is overheating.
●The needle of the engine coolant temperature gauge ( P. 9 3 )
enters the red zone or a loss of engine power is experienced. (For
example, the vehicle speed does not increase.)
●Steam comes out from under the hood.
1
2
3
4
1
2
3

8177-2. Steps to take in an emergency
ES350 300h_OM_OM33A01U_(U)
7
When trouble arises
The coolant level is satisfactory
if it is between the “FULL” and
“LOW” line on the reservoir.Reservoir cap
“FULL”
“LOW”
Add coolant if necessary.
Water can be used in an emer-
gency if coolant is unavailable.
Start the hybrid system and turn the air conditioning system on to
check that the radiator cooling fan operates and to check for coolant
leaks from the radiator or hoses.
The fan operates when the air conditioning system is turned on immediately
after a cold start. Confirm that the fan is operating by checking the fan sound
and air flow. If it is difficult to check these, turn the air conditioning system on
and off repeatedly.
(The fan may not operate in freezing temperatures.)
If the fan is not operating:
Stop the hybrid system immediately and contact your Lexus dealer.
If the fan is operating:
Have the vehicle inspected at the nearest Lexus dealer.
4
1
2
3
5
6
7

8187-2. Steps to take in an emergency
ES350 300h_OM_OM33A01U_(U)
■If “Hybrid System Overheat” is shown on the multi-information dis-
play
Stop the vehicle in a safe place.
Stop the hybrid system and carefully lift the hood.
After the hybrid system has
cooled down, inspect the
hoses and radiator core (radia-
tor) for any leaks.
The coolant level is satisfactory
if it is between the “FULL” and
“LOW” line on the reservoir.Reservoir cap
“FULL”
“LOW”
Add coolant if necessary.
Water can be used in an emer-
gency if coolant is unavailable.
Start the hybrid system and check fo r the multi-information display.
If the message does not disappear:
Stop the hybrid system and contact your Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the nearest Lexus dealer.
1
2
3
4
1
2
3
5
6
