266TECHNICAL SPECIFICATIONS
WHEELS
RIMS AND TYRES
Pressed steel or alloy rims. Tubeless radial carcass tyres.
All approved tyres are listed in the Vehicle Registration
Document.
IMPORTANT In the event of discrepancies between the
information provided in this “Owner’s handbook” and
the “Registration Document”, consider the specifications
shown in the log book only.
For safe driving, the car must be fitted with tyres of the
same make and type on all wheels.
IMPORTANT Do not use inner tubes with Tubeless tyres.
SPACE-SAVER WHEEL
Pressed steel wheel. Tubeless tyre.
WHEEL GEOMETRY
Total front toe in: –1
±1 mm
Total rear toe in: 2
±2 mm
The figures refer to the car in running order.UNDERSTANDING TYRE MARKING fig. 5
Example: 195/55 R 16 91 V
195 = Nominal width (S, distance in mm between
sidewalls).
55 = Height/width ratio (H/S) as a percentage.
R = Radial tyre.
16 = Rim diameter in inches (Ø).
91 = Load rating (capacity).
V = Maximum speed index.
fig. 5L0E0120m
