2013 INFINITI G CONVERTIBLE trip computer

GUID-2075472C-6623-4D22-B652-4F7655531773
SSI0819
1. Vehicle Dynamic Control (VDC) OFFswitch (P.5-55)
2. Trunk lid release switch (P.3-28)
3. Sonar system OFF switch (if so
equipped) (P.5-50) 4. Instrument brightness control switch
(P.2-37)
5. TRIP/RESET switch for twin trip od- ometer (P.2-7)
6. Headlight, fog light and turn signal switch (P.2-33) 7. Paddle shifter (if so equipped) (P.5-16)
8. Steering-wheel-mounted controls (Left
side)
—ENTER or tuning switch (P.4-76)
— BACK switch (P.4-76)
— TALK switch (P.4-103)/Phone
switch (P.4-79, 4-89)
— Volume control switches (P.4-76)
— Source select switch (P.4-76)
9. Trip computer switch (P.2-25)
10. Windshield wiper and washer switch (P.2-30)
11. Steering-wheel-mounted controls
(Right side)
—Cruise control switches (P.5-21)
— Intelligent Cruise Control (ICC)
switches (if so equipped) (P.5-23)
12. Hood release handle (P.3-17)
13. Intelligent Key port (P.5-9)
14. Electric tilting/telescopic steering
wheel lever (if so equipped) (P.3-34)
15. Manual tilting/telescopic steering
wheel lever (if so equipped) (P.3-34)
16. Steering wheel —Horn (P.2-39)
— Driver supplemental air bag
(P.1-35)
Illustrated table of contents0-7
COCKPIT

2 Instruments and controls
Cockpit...
................................................................ 2-3
Instrument panel ...
................................................. 2-4
Meters and gauges ...
.............................................. 2-6
Speedometer and odometer ...
............................ 2-7
Tachometer ...
...................................................... 2-8
Engine coolant temperature gauge ...
.................. 2-8
Fuel gauge ...
...................................................... 2-9
Warning/indicator lights and
audible reminders ...
............................................. 2-10
Checking bulbs ...
.............................................. 2-10
Warning lights ...
............................................... 2-10
Indicator lights ...
.............................................. 2-15
Audible reminders ...
......................................... 2-16
Dot matrix liquid crystal display ...
........................ 2-17
Indicators for operation ...
................................. 2-19
Indicators for retractable hard top ...
................. 2-22
Indicators for maintenance ...
............................ 2-23
Trip computer ...
................................................ 2-25
Security systems ...
............................................... 2-27
Vehicle Security System ...
................................ 2-27
INFINITI Vehicle Immobilizer System ...
.............. 2-29
Windshield wiper and washer switch ...
................. 2-30
Rain-sensing auto wiper system (if
so equipped) ...
................................................. 2-32 Rear window and outside mirror
defroster switch
...
................................................ 2-33
Headlight and turn signal switch ...
....................... 2-33
Xenon headlights ...
......................................... 2-33
Headlight switch ...
.......................................... 2-34
Turn signal switch ...
........................................ 2-37
Fog light switch ...
........................................... 2-38
Hazard warning flasher switch ...
.......................... 2-38
Horn ...
................................................................. 2-39
Heated seats (if so equipped) ...
........................... 2-39
Climate controlled seats (if so equipped) ...
.......... 2-40
Vehicle Dynamic Control (VDC) OFF switch ...
......... 2-42
Clock ...
................................................................. 2-42
Adjusting the time ...
....................................... 2-42
Power outlets ...
.................................................... 2-43
Cigarette lighter and ashtrays (if so equipped) ...
.... 2-44
Front ...
............................................................ 2-44
Rear ...
............................................................. 2-44
Storage ...
............................................................. 2-45
Cup holders ...
................................................. 2-45
Glove box ...
.................................................... 2-46
Console box ...
................................................. 2-47
Storage box (if so equipped) ...
........................ 2-48
Windows ...
........................................................... 2-48
Power windows ...
............................................ 2-48>

GUID-3D0B5C00-6F2B-4B4E-80B4-0BCB718F22F5
SSI0819
1. Vehicle Dynamic Control (VDC) OFFswitch (P.5-55)
2. Trunk lid release switch (P.3-28)
3. Sonar system OFF switch (if so
equipped) (P.5-50) 4. Instrument brightness control switch
(P.2-37)
5. TRIP/RESET switch for twin trip od- ometer (P.2-7)
6. Headlight, fog light and turn signal switch (P.2-33) 7. Paddle shifter (if so equipped) (P.5-16)
8. Steering-wheel-mounted controls (Left
side)
—ENTER or tuning switch (P.4-76)
— BACK switch (P.4-76)
— TALK switch (P.4-103)/Phone
switch (P.4-79, 4-89)
— Volume control switches (P.4-76)
— Source select switch (P.4-76)
9. Trip computer switch (P.2-25)
10. Windshield wiper and washer switch (P.2-30)
11. Steering-wheel-mounted controls
(Right side)
—Cruise control switches (P.5-21)
— Intelligent Cruise Control (ICC)
switches (if so equipped) (P.5-23)
12. Hood release handle (P.3-17)
13. Intelligent Key port (P.5-9)
14. Electric tilting/telescopic steering
wheel lever (if so equipped) (P.3-34)
15. Manual tilting/telescopic steering
wheel lever (if so equipped) (P.3-34)
16. Steering wheel —Horn (P.2-39)
— Driver supplemental air bag
(P.1-35)
Instruments and controls2-3
COCKPIT

2-20Instruments and controls
8. Engine start operation indicator
(Manual Transmission models)
GUID-DBDAE3A2-CB00-42CF-830F-56CFC89016D9This indicator means that the engine will
start by pushing the ignition switch with
the clutch pedal depressed.
9. Parking brake release warningGUID-A29E560B-AC65-45EF-BD61-D46B01E8D317This warning appears when the vehicle
speed is above 4 MPH (7 km/h) and the
parking brake is applied.
10. Low fuel warningGUID-C398ED0E-471A-4276-8E87-41D8B1B5D7C6This warning appears when the fuel level in
the tank is getting low. Refuel as soon as it
is convenient, preferably before the fuel
gauge reaches the empty (E) position.
There is a small reserve of fuel remaining
in the tank when the fuel gauge reaches
the empty (E) position.
11. Low washer fluid warningGUID-4B511101-A790-47D3-8A2A-05D513567AC2This warning appears when the washer
tank fluid is at a low level. Add washer fluid
as necessary. (See“Window washer fluid”
(P.8-14).)
12. Door/trunk open warning (igni-
tion switch is in the ON position)
GUID-D73931C6-CD04-450C-81A1-47A834D609C5This warning appears if any of the doors and/or the trunk lid are open or not closed
securely. The vehicle icon indicates which
door or the trunk lid is open on the display.
13. Loose fuel cap warningGUID-BFE458ED-BCA7-4335-B8F7-73E37C39ABB7This warning appears when the fuel-filler
cap is not tightened correctly after the
vehicle has been refueled. (See
“Fuel-filler
cap ”(P.3-32).)
14. Check tire pressure warningGUID-4F8F90C9-1D1A-4B19-84DE-FB30ADE966CCThis warning appears when the low tire
pressure warning light in the meter illumi-
nates and low tire pressure is detected. If
this warning appears, stop the vehicle and
adjust the tire pressure to the recom-
mended COLD tire pressure shown on the
Tire and Loading Information label. (See
“Low tire pressure warning light” (P.2-12)
and “Tire Pressure Monitoring System
(TPMS)” (P.5-4).)
15.“Time to rest” indicatorGUID-ED5D6E04-83A9-4A18-A337-1F03BC066E77This indicator appears when the set “time
to rest” indicator activates. You can set the
time for up to 6 hours. (See “Trip
computer” (P.2-25).)
16. Low outside temperature warn-
ing
GUID-780F773F-FB50-4944-8B7B-E69CA36895B2This warning appears if the outside tem-
perature is below 378F (38C). The warning
can be set not to be displayed. (See “Trip
computer” (P.2-25).)
17. Cruise indicatorGUID-3760C120-A3D7-4293-8781-3D4A6A9A5294Cruise main switch indicator:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407The indicator is displayed when the cruise
control main switch is pushed. When the
main switch is pushed again, the indicator
disappears. When the cruise control main
switch indicator is displayed, the cruise
control system is operational.
Cruise set switch indicator:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407The indicator is displayed while the vehicle
speed is controlled by the cruise control
system. If the indicator blinks while the
engine is running, it may indicate that the
cruise control system is not functioning
properly. Have the system checked by an
INFINITI retailer.
See“Cruise control” (P.5-21) for details.

so equipped) is being operated.
SIC3281
INDICATORS FOR MAINTENANCEGUID-565512D1-E2F1-4B0C-A120-2F8CB3809689
1. Engine oil replacement indicatorGUID-86239C07-26F2-4E81-9CCE-85513283903DThis indicator appears when the customer
set time comes for changing the engine oil.
You can set or reset the distance for
changing the engine oil. (See“Trip compu-
ter” (P.2-25).)
2. Oil filter replacement indicatorGUID-8F2935BB-61EE-47E6-9F8F-DCC9266F6803This indicator appears when the customer
set time comes for replacing the oil filter.
You can set or reset the distance for
replacing the oil filter. (See “Trip compu-
ter” (P.2-25).)
3. Tire replacement indicatorGUID-19CAA4EE-F80A-4E99-9D20-F2C2A34C457DThis indicator appears when the customer
set distance comes for replacing tires. You
can set or reset the distance for replacing
tires. (See “Trip computer” (P.2-25).)
WARNING
The tire replacement indicator is not a
substitute for regular tire checks, including
tire pressure checks. See “Changing wheels
and tires” (P.8-37). Many factors including
tire inflation, alignment, driving habits and
Instruments and controls2-23

2-24Instruments and controls
road conditions affect tire wear and when
tires should be replaced. Setting the tire
replacement indicator for a certain driving
distance does not mean your tires will last
that long. Use the tire replacement indicator
as a guide only and always perform regular
tire checks. Failure to perform regular tire
checks, including tire pressure checks could
result in tire failure. Serious vehicle damage
could occur and may lead to a collision,
which could result in serious personal injury
or death.
4.“OTHER” indicatorGUID-605192EA-54A6-4D1C-8DEB-95C9625B4FF1This indicator appears when the customer
set time comes for replacing items other
than the engine oil, oil filter and tires. You
can set or reset the distance for replacing
the items. (See “Trip computer” (P.2-25).)
More maintenance reminders are also
available on the center display. (See
“How to use INFO button” (P.4-9).)
SIC3282

SIC3264
TRIP COMPUTERGUID-E86FA79B-4523-49BD-B7FB-265F7EA8B983Switches for the trip computer are located
on the right side of the combination meter
panel. To operate the trip computer, push
the side or front of the switches as shown
above.
*Aswitch
*Bswitch
When the ignition switch is pushed to the
ON position, modes of the trip computer
can be selected by pushing the
switch
*A.
Each time the
switch*Ais pushed, the
display will change as follows: Current fuel consumption
?Average fuel
consumption and speed ?Elapsed time
and trip odometer ?Distance to empty
(dte) ?Outside air temperature (ICY) ?
Setting ?Warning check
1. Current fuel consumptionGUID-ABC17DA4-87D5-491E-9006-86109C97C09BThe current fuel consumption mode shows
the current fuel consumption.
2. Average fuel consumption (MPG
or l (liter)/100 km) and speed (MPH
or km/h)
GUID-03411336-C2A8-48AF-A1CE-A01E97029F8EFuel consumption:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407The average fuel consumption mode shows
the average fuel consumption since the
last reset. Resetting is done by pushing the
switch*Bfor longer than 1 second.
(The average speed is also reset at the
same time.)
The display is updated every 30 seconds.
At about the first 1/3 mile (500 m) after a
reset, the display shows “——”.
Speed:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407The average speed mode shows the
average vehicle speed since the last reset.
Resetting is done by pushing the
switch*Bfor longer than 1 second. (The average fuel consumption is also reset
at the same time.)
The display is updated every 30 seconds.
The first 30 seconds after a reset, the
display shows
“——”.
3. Elapsed time and trip odometer
(mls or km)
GUID-3CDBC135-59EB-440E-AE5F-83D095F69D8BElapsed time:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407The elapsed time mode shows the time
since the last reset. The displayed time can
be reset by pushing the
switch*Bfor
longer than 1 second. (The trip odometer is
also reset at the same time.)
Trip odometer:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407The trip odometer mode shows the total
distance the vehicle has been driven since
the last reset. Resetting is done by pushing
the
switch*Bfor longer than 1
second. (The elapsed time is also reset at
the same time.)
4. Distance to empty (dte —mls or
km)
GUID-679DBA77-D4B2-48C9-88C8-C64B75AC9DF2The distance to empty (dte) mode provides
you with an estimation of the distance that
can be driven before refueling. The dte is
constantly being calculated, based on the
Instruments and controls2-25

FluidAutomatic transmission fluid (ATF) ...
............... 8-12
Brake and clutch fluid ...
.................................. 8-13
Brake fluid ...
................................................... 8-14
Capacities and
recommended fuel/lubricants ...
........................ 9-2
Engine coolant ...
............................................... 8-8
Engine oil ...
.................................................... 8-10
Power steering fluid ...
..................................... 8-13
Window washer fluid ...
................................... 8-14
FM-AM-SAT radio with Compact Disc
(CD) player ...
........................................................ 4-55
Fog light switch ...
................................................ 2-38
Front passenger air bag and status light ...
........... 1-42
Front power seat adjustment ...
............................... 1-3
Front seat, Front seat adjustment ...
........................ 1-3
Front-seat active head restraints ...
....................... 1-10
Fuel Capacities and
recommended fuel/lubricants ...
........................ 9-2
Fuel economy ...
............................................... 5-46
Fuel economy information (display) ...
.............. 4-11
Fuel octane rating ...
.......................................... 9-4
Fuel recommendation ...
..................................... 9-4
Fuel-filler cap ...
............................................... 3-31
Fuel-filler door ...
............................................. 3-31
Gauge ...
............................................................ 2-9
LOOSE FUEL CAP warning ...
............................. 3-33
Fuses ...
................................................................ 8-22
Fusible links ...
..................................................... 8-23G
Garage door opener
HomeLink®Universal Transceiver ...
................. 2-53
Gas cap ...
............................................................ 3-31
Gauge ...
................................................................. 2-6
Engine coolant temperature gauge ...
................. 2-8
Fuel gauge ...
..................................................... 2-9
Odometer ...
....................................................... 2-7
Speedometer ...
................................................. 2-7
Tachometer ...
.................................................... 2-8
Trip computer ...
.............................................. 2-25
General maintenance ...
................................... 8-2, 8-3
Glove box ...
......................................................... 2-46
H
Hands-free phone system, Bluetooth®
(models with navigation system) ...
....................... 4-79
Hands-free phone system, Bluetooth®
(models without navigation system) ...
.................. 4-89
Hard top If the top does not open or close ...
................. 3-24
Indicators for retractable hard top
(dot matrix) ...
......................................... 2-22, 3-22
Initializing ...
.................................................... 3-25
Operating using the Intelligent Key ...
.............. 3-25
Retractable hard top operation ...
.................... 3-18
Hazard warning flasher switch ...
.......................... 2-38
Head restraints ...
................................................... 1-7
Headlights
Bulb replacement ...
......................................... 8-27 Headlight switch
...
.......................................... 2-34
Xenon headlights ...
......................................... 2-33
Heated seats ...
.................................................... 2-39
Heater
Automatic climate control ...
............................ 4-30
Engine block heater ...
..................................... 5-58
HomeLink
®Universal Transceiver ...
...................... 2-53
Hood release ...
.................................................... 3-17
Horn ...
................................................................. 2-39
I
Ignition switch
(Push-button) ...
................................................. 5-9
Manual transmission models ...
....................... 5-18
Immobilizer system ...
........................................... 2-29
In-cabin microfilter ...
............................................ 4-38
Indicator Dot matrix display ...
....................................... 2-17
Lights ...
.......................................................... 2-15
INFINITI Vehicle Immobilizer System ...
.................. 2-29
INFINITI voice recognition system ...
.................... 4-103
INFO button ...
........................................................ 4-9
Inside mirror ...
..................................................... 3-35
Inspection/maintenance (I/M) test ...
.................... 9-23
Instrument brightness control ...
........................... 2-37
Instrument panel ...
................................................ 2-4
Intelligent cruise control (ICC) system ...
............... 5-23
Preview function ...
.......................................... 5-45
Intelligent Cruise Control (ICC) system
warning light ...
.................................................... 2-12
Intelligent Key ...
..................................................... 3-3
10-3
