2013 INFINITI G CONVERTIBLE climate control

SAA2529
Activating Alternate Command
Mode
GUID-2B25F285-CF85-4E62-BCB5-0B31E3C1ACDCWhen the Standard Mode is active, perform
the following steps to switch to the
Alternate Command Mode.
1. Push the SETTING button on the instru-ment panel.
2. Highlight the “Others”key.
3. Highlight the “Voice Recognition” key.
SAA2543
4.Highlight the “Alternate Command
Mode” key.
5. The confirmation message is displayed on the screen. Push the “OK”key to
activate the Alternate Command Mode.
Displaying command listGUID-3C8E4B44-5BF9-4C25-8E08-5958E9F3C249If you are controlling the system by voice
commands for the first time or do not know
the appropriate voice command, perform
the following procedure for displaying the
voice command list (available only in
Alternate Command Mode).
SAA2544
1. Push the INFO button on the instrument
panel.
2. Select the “Others”key.
3. Select the “Voice Recognition” key.
4. Select the “Command List” key.
Monitor, climate, audio, phone and voice recognition systems4-117

4-118Monitor, climate, audio, phone and voice recognition systems
SAA2545
5. Select a category from the list.
SAA2546
6. Select an item.
7. If necessary, scroll the screen using theINFINITI controller to view the entire list.
8. Press the BACK button to return to the previous screen.

SAA2547
Displaying user guideGUID-DE666349-171C-49D1-9557-1B11049F753AYou can confirm how to use voice com-
mands by accessing a simplified User
Guide, which contains basic instructions
and tutorials for several voice commands.
1. Push the INFO button on the instrumentpanel.
2. Select the “Others”key using the
INFINITI controller and push the ENTER
button.
3. Highlight the “Voice Recognition” key
using the INFINITI controller and push
the ENTER button. 4. Highlight the
“User Guide”key using
the INFINITI controller and push the
ENTER button.
5. Highlight an item using the INFINITI controller and push the ENTER button.
Available items:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407. Getting Started
Describe the basics of how to operate
the INFINITI Voice Recognition system.
. Let’s Practice
Mode that allows practicing by follow-
ing the instructions of the system voice.
. Using the Address Book
Refer to Navigation System Owner’s
Manual.
. Finding a Street Address (if so
equipped)
Refer to Navigation System Owner’s
Manual.
. Placing Calls
Tutorial for making a phone call by
voice command operation.
. Help on Speaking
Displays useful tips for how to correctly
speak commands in order for them to
be properly recognized by the system. .
Voice Recognition Settings
Describes the available voice recogni-
tion settings.
. Adapting the System to Your Voice
Tutorial adapting the system to your
voice.USING THE SYSTEMGUID-C7E3CE61-A7AB-4F2C-8CB9-0D65E56C8603
InitializationGUID-8A25D678-EC6E-4AAD-BA5D-DB192E27BC54When the ignition switch is pushed to the
ON position, INFINITI Voice Recognition is
initialized, which may take up to one
minute. When completed, the system is
ready to accept voice commands. If the
TALK
switch is pushed before the
initialization completes the display will
show the message: “System not ready.”
or a beep sounds.
Before startingGUID-20A65AAB-2248-4918-8CF5-2399333FF512To get the best performance from INFINITI
Voice Recognition, observe the following.
. Keep the interior of the vehicle as quiet
as possible. Close the windows to
eliminate the surrounding noises (traf-
fic noises, vibration sounds, etc.),
which may prevent the system from
recognizing the voice commands cor-
rectly.
Monitor, climate, audio, phone and voice recognition systems4-125

4-126Monitor, climate, audio, phone and voice recognition systems
.When the air conditioner is in the AUTO
mode, the fan speed decreases auto-
matically for easy recognition.
. Wait until a tone sounds before speak-
ing a command.
. Speak in a natural voice without paus-
ing between words.
SAA1588
Giving voice commandGUID-C51B1E1D-F35E-413E-A742-F48AA16814381. Push and release the TALKswitch
located on the steering wheel.
SAA2548
2. A list of commands appears on the
screen, and the system announces,
“Please say a command”.
3. After the tone sounds and the icon on the screen changes from
to,
speak a command.
Operating tips:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407. Voice commands cannot be accepted
when the icon is.
. The list displayed can be scrolled by
tilting the menu control switch on the
steering wheel.
. If the command is not recognized, the
system announces, “Please say again”.

Repeat the command in a clear voice.
. Push the BACK button once to return to
the previous screen.
. If you want to cancel the command,
push and hold the TALK
switch for
1 second. The message “Voice can-
celed” will be announced.
. To skip the voice guidance function and
give the command immediately, press
the TALK
switch to interrupt the
system. Remember to speak after the
tone.
. If you want to adjust the volume of the
system feedback, push the volume
control switch (+ or −) on the steering
wheel or use the audio system volume
knob while the system is making an
announcement.
How to speak numbers:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407INFINITI Voice Recognition requires a cer-
tain way to speak numbers when giving
voice commands. Refer to the following
examples.
General rule
Only single digits 0 (zero) to 9 can be used.
(For example, if you would like to say 500,
“five zero zero” can be used, but “five
hundred” cannot. Phone numbers
Speak phone numbers according to the
following examples:
.
1-800-662-6200
— “Dial one eight zero zero six six two six two zero zero.”
Note 1: For the best voice recognition
phone dialing results, say phone numbers
as single digits.
Note 2: You cannot say 555-6000 as “five
five five six thousands” .
Note 3: When speaking a house number,
speak the number “0”as“zero”. If the
letter “o (oh)” is included in the house
number, it will not be recognized as the
number “0 (zero)” even if you speak “oh”
instead of “zero”. Please speak “zero”for
the number “0 (zero)”,“oh”for the letter
“o (oh)”.
Send digits using dial tone:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407. Press the TALKswitch during a
phone call.
. The menu will be launched and you will
be provided with the following gui-
dance: "Please say the digits to dial".
. After guidance, say the digits of the
number you want to send. After this, the digits that have been recognized
will be read out.
. If you press the ENTER button on the
steering wheel or on the INFINITI con-
troller, the selected digits will be sent.
Monitor, climate, audio, phone and voice recognition systems4-127

5-46Starting and driving
GUID-80396E4C-7829-4CC4-B140-AD5C5CA0C471
CAUTION
During the first 1,200 miles (2,000 km),
follow these recommendations to obtain
maximum engine performance and ensure
the future reliability and economy of your
new vehicle.
Failure to follow these recommendations
may result in shortened engine life and
reduced engine performance.
.Avoid driving for long periods at con-
stant speed, either fast or slow. Do not
run the engine over 4,000 rpm.
. Do not accelerate at full throttle in any
gear.
. Avoid quick starts.
. Avoid hard braking as much as possi-
ble.
GUID-A0B243EA-7BDA-4E12-AEC1-2F8D7AC85AA5. Accelerate slowly and smoothly. Main-
tain cruising speeds with a constant
accelerator position.
. Drive at moderate speeds on the high-
way.
. Avoid unnecessary stopping and brak-
ing. Keep a safe distance behind other
vehicles.
. Select a gear range suitable to road
conditions.
. Avoid unnecessary prolonged engine
idling.
. Keep your engine tuned up.
. Follow the recommended periodic main-
tenance schedule.
. Keep the tires inflated at the correct
pressure. Improper tire pressure will
increase wear and waste fuel.
. Make sure the front wheels are properly
aligned. Improper alignment will cause
premature tire wear and lower fuel
economy.
. Climate control operation lowers fuel
economy. Use the air conditioner only
when necessary.
. When cruising at highway speeds, it is
more economical to use the air condi-
tioner and leave the windows closed to
reduce drag.
BREAK-IN SCHEDULE INCREASING FUEL ECONOMY

GUID-4DCAB315-AC66-4A49-A484-5C2927B4F2E4DOT (Department Of Transportation) Qual-
ity Grades: All passenger car tires must
conform to federal safety requirements in
addition to these grades.
Quality grades can be found where applic-
able on the tire sidewall between tread
shoulder and maximum section width. For
example:
Treadwear 200 Traction AA Temperature A
TREADWEARGUID-61A676A7-9B91-4A79-A32F-E8D628C55791The treadwear grade is a comparative
rating based on the wear rate of the tire
when tested under controlled conditions
on a specified government test course. For
example, a tire graded 150 would wear one
and one-half (1 1/2) times as well on the
government course as a tire graded 100.
The relative performance of tires depends
upon actual conditions of their use, how-
ever, and may depart significantly from the
norm due to variations in driving habits,
service practices and differences in road
characteristics and climate.
TRACTION AA, A, B AND CGUID-BA7990B4-C685-4A1D-A234-3E4A1FA8B404The traction grades, from highest to low-
est, are AA, A, B and C. Those grades
represent the tire’s ability to stop on wet
pavement as measured under controlled
conditions on specified government test
surfaces of asphalt and concrete. A tire
marked C may have poor traction perfor-
mance.
WARNING
The traction grade assigned to this tire is
based on straight-ahead braking traction
tests, and does not include acceleration,
cornering, hydroplaning, or peak traction
characteristics.
TEMPERATURE A, B AND CGUID-7A8C8273-BED1-4908-B544-D79557E7C502The temperature grades A (the highest), B,
and C, representing the tire’s resistance to
the generation of heat and its ability to
dissipate heat when tested under con-
trolled conditions on a specified indoor
laboratory test wheel. Sustained high
temperature can cause the material of the
tire to degenerate and reduce tire life, and
excessive temperature can lead to suddentire failure. The grade C corresponds to a
level of performance which all passenger
car tires must meet under the Federal
Motor Vehicle Safety Standard No. 109.
Grades B and A represent higher levels of
performance on the laboratory test wheel
than the minimum required by law.
WARNING
The temperature grade for this tire is
established for a tire that is properly
inflated and not overloaded. Excessive
speed, under-inflation, or excessive loading,
either separately or in combination, can
cause heat build-up and possible tire failure.
Technical and consumer information9-21
UNIFORM TIRE QUALITY GRADING

10 Index
A
ABS (Anti-lock Braking System)...
......................... 5-54
Advanced air bag system ...
.................................. 1-40
Air bag system Advanced air bag system ...
............................. 1-40
Door-mounted curtain side-impact
supplemental air bag system ...
....................... 1-45
Front passenger air bag and status light ...
...... 1-42
Front-seat mounted side-impact
supplemental air bag system ...
....................... 1-45
Air bag warning labels ...
...................................... 1-48
Air bag warning light ...
............................... 1-48, 2-14
Air cleaner housing filter ...
................................... 8-19
Air conditioner
Air conditioner service ...
................................. 4-38
Air conditioner specification label ...
................ 9-13
Air conditioning system refrigerant and
lubricant recommendations ...
................... 4-38, 9-7
Automatic climate control ...
............................ 4-30
In-cabin microfilter ...
....................................... 4-38
Alarm, How to stop alarm (see vehicle
security system) ...
................................................ 2-28
Alcohol, drugs and driving ...
.................................. 5-8
Antenna ...
............................................................ 4-77
Anti-lock Braking System (ABS) ...
......................... 5-54
Anti-lock braking system (ABS) warning light ...
.... 2-10
Appearance care
Exterior appearance care ...
................................ 7-2
Interior appearance care ...
................................ 7-4
Ashtrays (See cigarette lighter and ashtrays) ...
.... 2-44 Audible reminders
...
............................................ 2-16
Audio operation precautions ...
............................. 4-39
Audio system ...
.................................................... 4-39
Steering wheel audio controls ...
...................... 4-76
Auto closure ...
..................................................... 3-29
Autolight system ...
............................................... 2-34
Automatic Automatic adjusting function
(front windows) ...
............................................ 2-50
Automatic climate control ...
.................. 4-32, 4-35
Automatic transmission fluid (ATF) ...
............... 8-12
Climate control ...
............................................ 4-30
Door locks ...
..................................................... 3-6
Drive positioner ...
........................................... 3-38
Driving with automatic transmission ...
............ 5-13
Seat positioner ...
............................................ 3-38
Average fuel consumption and speed ...
................ 2-25
Avoiding collision and rollover ...
............................ 5-7
B
Battery ...
.............................................................. 8-15
Battery saver system ...
................................... 2-36
Intelligent Key ...
.............................................. 8-25
Variable voltage control system ...
................... 8-17
Before starting the engine ...
................................ 5-12
Bluetooth
®hands-free phone system
(models with navigation system) ...
....................... 4-79
Bluetooth
®hands-free phone system
(models without navigation system) ...
.................. 4-89 Bluetooth
®streaming audio
...
............................. 4-68
Brake
Anti-lock Braking System (ABS) ...
.................... 5-54
Brake and clutch fluid ...
.................................. 8-13
Brake fluid ...
................................................... 8-14
Brake system ...
............................................... 5-51
Parking brake operation ...
............................... 5-20
Warning light ...
............................................... 2-11
Break-in schedule ...
............................................. 5-46
Brightness control Display ON/OFF button ...
.................................. 4-9
Instrument panel ...
......................................... 2-37
Bulb check/instrument panel ...
............................ 2-10
Bulb replacement ...
.............................................. 8-27
C
Cabin air filter ...
................................................... 4-38
Capacities and recommended fuel/lubricants ...
...... 9-2
Car phone or CB radio ...
...................................... 4-78
Catalytic converter, Three way catalyst ...
................ 5-4
CD/CF/USB memory care and cleaning ...
............. 4-75
Center multi-function control panel ...
..................... 4-3
Child restraints ...
................................................. 1-19
Child Restraint Lower Anchors ...
...................... 1-21
Precautions on child restraints ...
..................... 1-20
Child safety ...
...................................................... 1-17
Chimes, Audible reminders ...
............................... 2-16
Cigarette lighter and ashtrays ...
........................... 2-44
Circuit breaker, Fusible link ...
............................... 8-23
