2013 INFINITI FX ECO mode

Black plate (43,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
InformationCommand
Action
Fuel Economy Displays fuel economy information.
Trip Computer (if so equipped) Displays trip information.
Maintenance Displays maintenance information.
Where am I? Displays GPS information.
Traffic Information Turns the traffic information system on and off.
Audio Command Action
AM Turns to the AM band, selecting the station last played.
FM Turns to the FM band, selecting the station last played.
XM Turns to the SiriusXM Satellite Radio band, selecting the channel last played.
CD Starts to play a CD.
General Command Action
Go back Corrects the last recognition result to return to the previous screen.
Exit Cancels Voice Recognition.
INFO:
Refer to the vehicle Owner’s Manual for the operations related to phone, information and audio.
2. Getting started
2-35
Condition: Language=NAM_English/

Black plate (47,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
: Direction of the vehicle always
pointing up.
“Setting map orientation”
(page 3-14)
*6Scale indicator:
Indicates the scale of the map. Touch
the icon to display the scale bar.
The map scale can be adjusted using
the scale bar.
“Operating with touch panel op-
eration” (page 3-10)
*7Arrow:
Indicates the distance to the next
guide point and the turning direction
at that guide point.
*8Stored location (orange):
Displays the locations that are stored
in the Address Book. Icons can be
changed according to personal prefer-
ences.
“Storing location” (page 6-2)
*9Avoid Area (green or blue):
Displays the areas to avoid that are
stored in the Address Book with green
or blue icons. During the route search,
the route guidance is performed by
searching for a route that avoids those areas.
“Storing avoid area”
(page 6-7)
*10Street name:
Displays the name of the street the
vehicle is currently driving on.
*11Traffic indicator:
Displays the reception condition of the
traffic information transmitted from
the provider.
Green: Reception condition is good.
Gray: Reception condition is not good.
No mark: Subscription to NavTraffic
service is not detected.
BirdviewTM(3D) MAP
BirdviewTMdisplays the map from an
elevated perspective. In BirdviewTM, it is
easy to recognize an image of the route
because it provides a panoramic view over
a long distance.
IMA0073
INFO:
Note the following items about the BirdviewTM
display.
.“BirdviewTM” is a registered trademark of
Clarion Co., Ltd.
.The map in BirdviewTMalways appears with
the current forward direction facing up.
BUILDING GRAPHICS
In an area where the building graphics are
stored in the map data, the building
graphics are displayed when the map is
zoomed in. On the 2D map display, these
are called “Building footprint graphics”,
and on the Birdview
TMdisplay, these are
called “3D building graphics”.
The method to look at the map is the same
for the 2D and Birdview
TMmaps.
3. Map settings
3-3
Condition: Language=NAM_English/

Black plate (72,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
4. Setting destination
4-6
INFO:
When using a voice command to set a street
name, it is recommended that the complete
street name is stated.
Examples:Correct input –North Elm Street
East Jefferson Boulevard
Incorrect input –Elm Street
East Jefferson
FINDING PLACE
There are 3 methods that can be used to
set the destination to places of interest:
typing the name, choosing a category or
selecting a ZAGAT reviewed location. To
help improve searching, different start
points can be chosen to search from such
as near current location, near the destina-
tion or city center.
Finding nearby place
JND0241X1. Push .
2. Highlight [Places] and push .
IDE01123. Highlight the preferred nearby category
from the list and push .
A list screen is displayed.
INFO:
Highlight [Customize Nearby Places] to
customize the 5 nearby categories to show the categories that you frequently use.
IDE01134.
Highlight the preferred destination
from the list, and push . The
position of the selected location is
displayed in the preview on the right
side of the screen.
INFO:
.A maximum of 100 facilities can be displayed on the list screen.
.To search for facilities along your route, select [Show Along Route].
Condition: Language=NAM_English/

Black plate (92,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
5. Route guidance
5-2
PROCEDURES AFTER SETTING DESTINA-
TION
After performing a route search, the route
guidance can be immediately started. Also,
it is possible to confirm or change a route.
IRG0085Available items after setting destination. [Start]:
Starts route guidance to the selected
destination.
“Starting route guidance”
(page 5-2)
. [More Routes]:
Displays 3 alternative routes.
“Selecting route” (page 5-3)
. [Add/Route Info]:
Displays the route information. A desti-
nation or a waypoint can also be
added.
“Confirming route” (page 5-3)
. [Move Location]:
Displays a map screen. The location of
the destination can be adjusted.
“Moving location of destination”
(page 5-5)
. [Store Location]:
Stores the location in the Address
Book.
“Storing location” (page 5-5)
. [Place Info]:
Displays information about the facility
that has been set as the destination, if
it is included in the map data.
“Viewing information about
searched location” (page 5-6)
INFO:
.
If no operations have been performed on the
system for several seconds, [Start] is auto-
matically selected, and the system starts
route guidance.
.When using waypoints, [More Routes] is
disabled. After the route is started, push
then select [Edit/Add to Route] to
change the route between each waypoint.
.The same screen as when [Move Location] is
selected can be displayed with the following
operations:
—Touching the map screen
—Pushing the directional buttons except
for the up/down button (INFINITI con-
troller with directional buttons)
—Pushing the slide switch except in the
upward/downward direction (INFINITI
controller without directional buttons)
STARTING ROUTE GUIDANCE
IRG00851. Highlight [Start] and push .
Route guidance starts.
Condition: Language=NAM_English/

Black plate (95,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
.If a destination was added, the prior
destination becomes a waypoint.
MOVING LOCATION OF DESTINATION
The location of the destination can be
adjusted by moving the cross pointer
across the map.
IRG00941.Highlight [Move Location] and push
.
INFO:
The screen for adjusting the location also
changes by touching the map screen dis-
played on the right side of the screen.
IRG00952. Adjust the location by moving the cross
pointer across the map and push
. The location of the destination
is modified.
INFO:
.
The map scale can be changed by turning
the center dial or touching the scale icon.
The map scale can also be changed by
pressing / (if so
equipped).
.The same screen as when [Move Location] is
touched can be displayed with the following
operations:
—Touching the map screen.
—Pushing the directional buttons except
up/down buttons (INFINITI controller
with directional buttons).
—Pushing the slide switch except upward/
downward (INFINITI controller without
directional buttons).
STORING LOCATION
A searched location can be stored in the
Address Book. Then it can be easily
retrieved and set as a destination (or
waypoint).
IRG00961. Highlight [Store Location] and push
.
IRG0097
5. Route guidance
5-5
Condition: Language=NAM_English/

Black plate (100,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
5. Route guidance
5-10
Split screen settings
The display setting on the left-hand side
screen shown during route guidance can
be changed.
IRG01041. Pushwhile the current location
map screen is displayed.
2. Highlight [Map View] and push
.
IRG01053.Highlight [View Settings] and push
. 4.
Highlight the preferred screen and
push . The indicator of the
selected screen illuminates.
Intersection:
IRG0101The map screen and the enlarged intersec-
tion view can be displayed at the same
time.
Push

Black plate (101,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
display the fuel economy information,
push

Black plate (108,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
5. Route guidance
5-18
INFO:
.
If the destination is deleted, the final
waypoint of the route becomes the destina-
tion.
.Even if the map screen is touched, the same
map screen as when [Move Dest.] is
selected is displayed.
Changing order of destination and
waypoints
The order of a destination and waypoints
that have already been set can be changed.
IRG01321. Push .
2. Highlight [Edit/Add to Route] and push .
3. Highlight a destination or waypoint that is already set and push .
IRG01334.Highlight [Change Order] and push
. A list of the destination and
waypoints is displayed.
IRG01345.Highlight a preferred destination or
waypoint to replace the previously
selected destination or waypoint and
push .
IRG01356. A message is displayed and the order
of the destination or waypoint is
changed.
IRG01367. By highlighting [Calculate] and pushing, the system will recalculate the
routes. After the route search is com-
plete, the display will automatically
return to the current location map
screen.
