2013 HONDA INSIGHT tow

If this happens, pull to the side of the
road when it is safe, check which tire
has lost pressure, and determine the
cause. If it is because of a f lat tire,
replace the flat tire with the compact
spare (seepage), and have the
f lat tire repaired as soon as possible.
If two or more tires are underinf lated,
call a prof essional towing service.
Refer to page for more
inf ormation.
If this indicator begins to flash,
there is a problem with the tire
pressure monitoring system
(TPMS). You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-information
display. The indicator continues to
flash for a while (approximately 1
minute), then stays on. If this
happens, have your dealer check
the system as soon as possible.
For more information, see .
This indicator normally comes on
for a few seconds when you turn
the ignition switch to the ON (II)
position. If it comes on at any
other time, it indicates a
problem in the integrated motor
assist (IMA) system. With the IMA
indicator on, the vehicle may not
accelerate as it normally does. Have
the vehicle checked by the dealer
as soon as possible.
You will also see a ‘‘CHECK IMA
SYSTEM’’ message on the multi-
inf ormation display.
See pages and .
You will also see a ‘‘CHECK TIRE
PRESSURE’’ message on the multi-
inf ormation display (see
page ).
If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
This indicator has two f unctions: This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
1.
2.
281 283 289349
374
U.S. models only
Instrument Panel Indicators
Low Tire Pressure/
TPMS Indicator
IMA System Indicator
A uto Idle Stop Indicator
66
12/07/13 16:45:34 31TM8630_071
Inst rument s and Cont rolsTOC
page 290
2013 Insight

µ
µ µ
µ µ
µ
µ
µ µ
Push the right lever up or down to
select a position.
The wipers run at high
speed until you release the lever.
The wipers are not activated. The wipers run at low speed.
The wipers run at high speed. Pull the
wiper control lever toward you, and
hold it. The washers spray until you
release the lever. The wipers run at
low speed, then complete one more
sweep after you release the lever.
MIST
OFF
INT Intermittent
LO Low speed
HI High speed
Windshield washers The length of the wipe
interval is varied automatically
according to vehicle’s speed.
Vary the delay by turning the
adjustment ring. If you turn it to the
shortest delay ( position), the
wipers change to low speed
operation when the vehicle speed
exceeds 12 mph (20 km/h). The length of the wiper interval is
varied automatically according to the
vehicle’s speed.
1.
2.
3.
4.
5.
6.
EX models
MIST
OFF LO
HI
Windshield Washer
INT
Windshield Wipers and Washers
119
ADJUSTMENT RING
EX model is shown.
12/07/13 16:52:21 31TM8630_124
Inst rument s and Cont rolsTOC
2013 Insight

Move the steering wheel so it
points toward your chest, not
toward your f ace. Make sure you
can see the instrument panel
gauges and indicators.
Make any steering wheel
adjustments before you start driving.
Pull the lever under the steering
column toward you until it stops.Push the lever f orward f ully to
lock the steering wheel in position.
Make sure you have securely
locked the steering wheel in place
by trying to move it up, down, in,
and out. Make sure the lever is positioned
securely at the bottom of the
steeringcolumnasshown.
1. 3.
4.
2.
Steering Wheel A djustments
128
To adjust To lock LEVERAdjusting the steering wheel
position while driving may
cause you to lose control of the
vehicle and be seriously injured
inacrash.
Adjust the steering wheel only
when the vehicle is stopped.
12/07/13 16:53:20 31TM8630_133
Inst rument s and Cont rolsTOC
2013 Insight

Tousethevanitymirrorontheback
of the sun visor, pull up the cover.
To use the sun visor, pull it down.
You can also use the sun visor at the
side window. Remove the support
rod from the clip and swing the sun
visor toward the side window.
Make sure you put the sun visor
back in place when you are getting
into or out of the vehicle.
Touseacoathook,slideitout
slightly, then pull it down.
Make sure the coat hook is
pulled up when you are not using it.
This hook is not designed for large
or heavy items.
On U.S. EX models
and Canadian models
Vanity Mirror
Sun Visors
Coat Hook
Interior Convenience Items
158
COAT HOOK
EX model is shown.
12/07/13 16:56:40 31TM8630_163
Inst rument s and Cont rolsTOC
2013 Insight

Insert the dipstick all the way back
into its hole. Wipe of f the dipstick with a clean
cloth or paper towel. Remove the dipstick (orange loop).
Wait a f ew minutes af ter turning the
engine of f bef ore you check the oil.
To close the hood, lif t it up slightly to
remove the support rod f rom the
hole. Put the support rod back into
its holding clip. Lower the hood to
about a f oot (30 cm) above the
f ender, then let it drop. Make sure it
is securely latched.
Holding the grip, pull the support
rod out of its clip. Insert the
end into the designated hole
in the hood. 2.
3. 1.
3.
CONT INUED
Oil Check
Service Station Procedures
249
SUPPORT ROD
CLIP
GRIP
DIPSTICK
12/07/13 17:08:41 31TM8630_254
Bef ore DrivingTOC
2013 Insight

µ·
µ The resulting f igure equals the
available amount of cargo and
luggage load capacity. For
example, if the ‘‘XXX’’ amount
equals 1,400 lbs. and there will be
f ive 150 lb. passengers in your
vehicle, the amount of available
cargo and luggage load capacity is
650 lbs.
(1,400 750 (5 150) = 650 lbs.)
Determine the combined weight
of luggage and cargo being loaded
on the vehicle. That weight may
not saf ely exceed the available
cargo and luggage load capacity
calculated in Step 4.
If yourvehiclewillbetowinga
trailer, load f rom your trailer will
be transf erred to your vehicle.
Consult this manual to determine
how this reduces the available
cargo and luggage load capacity of
your vehicle.
Subtract the combined weight of
the driver and passengers f rom
XXX kg or XXX lbs. Locate the statement ‘‘The
combined weight of occupants and
cargo should never exceed XXX
kg or XXX lbs.’’ on your vehicle’s
placard.
Steps for Determining
Correct Load Limit
Determine the combined weight
of the driver and passengers that
will be riding in your vehicle.
The maximum load f or your vehicle
is 850 lbs (385 kg).
See Tire And Loading Inf ormation
label attached to the driver’s
doorjamb.
Label Example
This f igure includes the total weight
of all occupants, cargo, and
accessories, and the tongue load if
you are towing a trailer.
(1)
(2)
(3)
(6) (5) (4)
CONT INUED
Load Limits
Carrying Cargo
257
Overloading or improper
loading can affect handling and
stability and cause a crash in
which you can be hurt or killed.
Follow all load limits and other
loading guidelines in this
manual.
12/07/13 17:09:55 31TM8630_262
Bef ore DrivingTOC
2013 Insight

This section gives you tips on
starting the engine under various
conditions, and how to operate the
automatic transmissions (CVT). It
also includes important inf ormation
on parking your vehicle, the braking
system, the vehicle stability assist
(VSA) system, and the tire pressure
monitoring system (TPMS).
........................Preparing to Drive.262
.......................Starting the Engine.263
........................Eco Assist System.264
.Automatic Transmission (CVT) .271
Driving with the Paddle
.......................................Shif ters.276
................................Auto Idle Stop.281
...........................................Parking.284
.............................Braking System.285
...............Anti-lock Brakes (ABS) .287
Tire Pressure Monitoring System
......................................(TPMS).289
Vehicle Stability Assist (VSA),
aka Electronic Stability
....Control (ESC), System .293
...........Hill Start Assist System .295
...........................Towing a Trailer.296
Driving
261
12/07/13 17:10:18 31TM8630_266
Bef ore Driving
2013 Insight

If the vehicle is facing downhill,
turn the front wheels toward
the curb.
Make sure the parking brake is
f ully released bef ore driving away.
Driving with the parking brake
partially set can overheat or
damage the rear brakes.
Set the parking brake bef ore you put
the transmission in Park. This keeps
the vehicle from moving and putting
pressure on the parking mechanism
in the transmission. Always use the parking brake when
you park your vehicle. Make sure
the parking brake is set f irmly, or
your vehicle may roll if it is parked
on an incline.
Place any packages, valuables, etc.
in the cargo area or take them
with you. Turn of f the lights. Make sure the windows are closed.
Lock the doors and the hatch.
If the vehicle is facing uphill,
turn the front wheels away
from the curb. Never park over dry leaves, tall
grass, or other f lammable
materials. The hot three way
catalytic converter could cause
these materials to catch on fire. Check the indicator on the
instrument panel to verif y that the
security system is set.
LX and EX models
Parking T ips
Parking
284
12/07/13 17:13:24 31TM8630_289
Bef ore DrivingTOC
2013 Insight
