If you think you can safely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the
recommended pressure.
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly. If the tire is flat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (seepage).
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is significantly underinflated.
You should stop and check your
tires as soon as possible, and inflate
them to the proper pressure
as indicated on the vehicle’s tire
information placard.
Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see a ‘‘CHECK
TIRE PRESSURE’’ message on the
multi-inf ormation display.
If you cannot make the low tire
pressure/TPMS indicator and
message on the multi-information
display go out after inflating the
tires to the specified values, have
your dealer check the
system as soon as possible. 348
CONT INUED
U.S. models onlyLow Tire Pressure/
TPMS Indicator
Tire Pressure Monitoring System (TPMS)
289
12/07/13 17:13:58 31TM8630_294
Bef ore DrivingTOC
2013 Insight

Driving with varying tire or wheel
sizes may cause the VSA to
malf unction. When replacing tires,
make sure they are of the same size
and type as your original tires (see
page).
If you install winter tires, make sure
they are the same size as those that
were originally supplied with your
vehicle. Exercise the same caution
during winter driving as you
would if your vehicle was not
equipped with VSA. Your vehicle is equipped with a hill
start assist f eature to help prevent
the vehicle f rom rolling on inclines
as you move your f oot f rom the
brake pedal to the accelerator.
To activate hill start assist, you must
come to a complete stop and make
sure the shift lever is in any of D, S
or L (either in D or S on models with
the paddle shifters) when facing
uphill, or reverse when facing
downhill. Release the brake pedal.
The brakes remain engaged briefly
to keep the vehicle from rolling
forward or backward while
you move your foot from the brake
pedal to the accelerator pedal.
Gently apply the accelerator
pedal as in normal driving. Hill start
assist will release brake pressure
gradually as you accelerate.Hillstartassistmaynotpreventyour
vehicle f rom rolling downhill on a
very steep or slippery slope, and will
not operate on small inclines.
Hill start assist is not a replacement
for the parking brake. If parking
your vehicle, ensure that the
transmission is in Park, and the
parking brake is fully applied before
exiting the vehicle. You should also
turn off the engine before
exiting the vehicle.
The VSA system indicator will come
on when there is a problem in the hill
start assist system. With the VSA
system indicator on, the hill start
assist system will not activate.
Hill start assist will still operate even
when VSA is switched off.
342
Vehicle Stability A ssist (VSA), aka Electronic Stability Control (ESC), System
VSA and Tire Sizes
Hill Start Assist System
295
12/07/13 17:14:42 31TM8630_300
Bef ore DrivingTOC
2013 Insight

Using gloves or a large heavy
cloth, turn the radiator cap
counterclockwise, without
pushing down, to the first stop.
After the pressure releases,
push down on the cap, and turn it
until it comes off.If the temperature stays
normal, check the coolant
level in the radiator reserve
tank. If it has gone down,
add coolant to the MAX mark.
Put the cap back on tightly.
Start the engine, and set the
temperature to maximum heat
(climate control to AUTO at
‘‘ ’’). Add coolant to the
radiator up to the base of the f iller
neck. If you do not have the
proper coolant mixture available,
you can add plain water.
Remember to have the cooling
system drained and ref illed with
the proper mixture as soon as
Put the radiator cap back on
tightly. Run the engine, and check
the high temperature indicator. If
it begins to blink or comes on
again, the engine needs repair
(see
on
8. 9.
10. 11.
If theEngineOverheats
Emergency Towing
362
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
12/07/13 17:22:50 31TM8630_367
T aking Care of t he Unexpect edTOC
page 374
).
you can.
2013 Insight

If necessary, add oil to bring the
level back to the full mark on the
dipstick (seepage). The engine running generates the
oil pressure. When the Auto Idle
Stop is activated, the engine
is stopped, the oil pressure
is dropped, and the low oil pressure
indicator does not come
on.
Saf ely pull of f the road, and shut
of f the engine. Turn on the hazard
warning lights.
Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see
page). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
Start the engine and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn of f the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving
(see on
).
This indicator should never
come on when the engine is
running. If it starts f lashing or stays
on, the oil pressure has dropped very
low or lost pressure. Serious engine
damage is possible, and you should
take immediate action.
You will also see a ‘‘CHECK
ENGINE OIL LEVEL’’ message on
the multi-information display when
this indicator comes on.
The indicator notif ies you of low oil
pressure and does not measure the
oil level. Check your vehicle’s oil
level at each ref ueling. 1.
2.
3.
4.
249
310
L ow Oil Pressure Indicator
Emergency T owing
363
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.
12/07/13 17:22:59 31TM8630_368
T aking Care of t he Unexpect edTOC
page 374
2013 Insight

µµ
If the charging system
indicator comes on brightly
when the engine is running, the 12
volt battery is not being charged.
Go to a service station or
garage where you can get
technical assistance. Immediately turn off all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly. You will also see a ‘‘CHECK
CHARGING SYSTEM’’ message on
the multi-information display (see
page ). This indicator may blink af ter you
start the vehicle in the morning
when the temperature is below
20°F ( 30°C). It will stop
blinking when the IMA battery
warms up.
89
12 Volt Battery Charging System Indicator
364
12/07/13 17:23:04 31TM8630_369
T aking Care of t he Unexpect edTOC
2013 Insight

µ
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Please note that the TPMS is not a
substitute for proper tire
maintenance, and it is the driver’s
responsibility to maintain correct tire
pressure, even if under-inf lation has
not reached the level to trigger
illumination of the TPMS low tire
pressure telltale.TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly.
Always check the TPMS
malfunction telltale after
replacing one or more tires or
wheels on your vehicle to ensure
that the replacement or alternate
tires and wheels allow the TPMS
to continue to function properly.
Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is combined
with the low tire pressure telltale.
When the system detects a
malf unction, the telltale will f lash f or
approximately one minute and then
remain continuously illuminated.
This sequence will continue upon
subsequent vehicle start-ups as long
as the malfunction exists.
When the malf unction indicator is
illuminated, the system may not be
able to detect or signal low tire
pressure as intended.
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
386
12/07/13 17:26:00 31TM8630_391
Technical Inf ormationTOC
2013 Insight

CONT INUED
BatteryCharging System ...........................
Indicator .63, 364
............................
Jump Starting .358
..............................
Maintenance .344
............................
Specif ications .381
..............................
Bef ore Driving .243
....................................
Belts,Seat .9,21
...........................
Beverage Holder .154
.......
Bluetooth
HandsFreeLink. 225
Brakes ...........
Anti-lock System (ABS) . 287
.............
Break-in, New Linings . 244
....................
Bulb Replacement .330
...........................................
Fluid .319
...................
Pad Wear Indicator . 286
.......................................
Parking .151
...........
System Indicator . 63, 64, 366
....................................
Accessories .254
ACCESSORY (Ignition Key .....................................
Position) .131
.............
Accessory Power Socket . 155
................
Active Head Restraints . 144
....................
Additives, Engine Oil . 311
.............................
Airbag (SRS) .10, 25
...
Airbags, Additional Information . 25
...
Additional Safety Precautions . 37
..........
AdvancedAirbagSystem . 30
.............................
Airbag Service .36
How the Passenger Airbag Of f ......................
Indicator Works .35
How the Side Airbag Of f ......................
Indicator Works .34
..
How the SRS Indicator Works . 34
How Your Front Airbags .........................................
Work .28
...
How Your Side Airbags Work . 32
How Your Side Curtain Airbags .........................................
Work .33
........................
SRS Components .25
..............
Air Conditioning System . 162
.......................
Air Pressure, Tires .339 ................................
Ambient Meter .72
......................................
Antif reeze .315
Anti-lock Brakes (ABS) ...............................
Indicator .64, 287
...................................
Operation .287
..............
Anti-thef t, Audio System . 219
Anti-thef t Steering Column ............................................
Lock .131
..........................................
Armrest .146
................................
Audio System .168
.......................
Auto Door Locking .109
...................
Auto Door Unlocking . 110
................................
Auto Idle Stop .281
...
Automatic Seat Belt Tensioners . 23
.............
Automatic Speed Control . 222
.
Automatic Transmission (CVT) . 271
..........................
Capacity,Fluid .380
...............
Checking Fluid Level . 318
Paddle Shif ters in the ..............................
D Position .276
Paddle Shif ters in the ...............................
S Position .279
.....
Recommended Shif t Points . 280
.......................................
Shif ting .272
Shif t Lever Position ...............................
Indicators .271 ................
Shif t Lever Positions . 273
....................
Shif t Lock Release . 275
......................
Auxiliary Input Jack .218
I
12/07/23 10:21:22 31TM8630_404
IndexA B C D E F G H I J K L M N O P Q R S T U V W X Y Z
A
B
2013 Insight

.................................................
Fuel .244
......................
Fill Door and Cap .245
...........................................
Gauge .73
................
Octane Requirement . 244
...............................
Oxygenated .244
........................
Reserve Indicator .70
........................
Tank, Filling the .245
.....................
Fuses, Checking the .369
...............
Gas Mileage, Improving . 251
.........................................
Gasoline .244
...............
Fuel Reserve Indicator . 70
...........................................
Gauge .73
................
Octane Requirement . 244
........................
Tank, Filling the .245
................
Gas Station Procedures . 245
Gauges .............................
Charge/Assist .74
...............................................
Fuel .73
............
Gearshif t Lever Positions . 271
..........
Automatic Transmission . 271
......................................
Glove Box .156 .............
Halogen Headlight Bulbs . 321
...........................
HandsFreeLink
. 225
..............................................
Hatch .139
......................................
Opening .139
............................
Open Indicator .68
............
Hazard Warning Flashers . 125
Headlights ........................................
Aiming .321
.........
Daytime Running Lights . 123
..................
High Beam Indicator . 69
......................
Reminder Beeper .121
........
Replacing Halogen Bulbs . 321
.................................
Turning on .121
............................
Head Restraints .142
.............................
Heated Mirrors .148
.............
High Altitude, Starting at . 263
...............
High-Low Beam Switch . 120
...............
Hill Start Assist System . 295
.......................
Hood, Opening the .248
....................................................
Horn .4
...
Identif ication Number, Vehicle . 378Ignition
............................................
Keys .129
.........................................
Switch .131
............
Timing Control System . 388
IMA System Power Flow ........................................
Monitor .84
......................
Immobilizer System .130
.........
Important Safety Precautions . 6
.........
Indicators, Instrument Panel . 62
...
Indicators, Messages (MID) . 62, 89
...............
ABS (Anti-lock Brake) . 64
..............................
Auto Idle Stop .66
Brake (Parking and Brake ............................
System) .63, 366
.............................
Cruise Control .69
.................................
Cruise Main .69
................
Door/Hatch Open . 12, 68
DRL (Daytime Running ....................................
Lights) .123
.
EPS (Electric Power Steering) . 68
................................
ECON Mode .71
...................................
High Beam .69
....
High Temperature (Coolant) . 67
......................
IMA Battery Level .85
.................................
IMA System .66
........
Key (Immobilizer System) . 63
IV
12/07/13 17:27:39 31TM8630_407
IndexA B C D E F G H I J K L M N O P Q R S T U V W X Y Z
G H
I
2013 Insight
