2013 FORD TRANSIT CONNECT phone

INSTRUMENT PANEL
1 HEADLAMP CONTROL:
Turns the headlamps off.
Turns on the parking lamps.
Turns on the headlamps.
Turns on the fog lamps* by pulling the control toward you.
Turns on the rear fog lamps* by pulling the control toward you until you feel the second detent.
2 SYNC CONTROLS:
Use the touch-sensitive buttons to access voice, phone and media sources. See the SYNC section in this guide for more details.
3 WINDSHIELD WIPERS AND WASHERS
Move the lever down for a single wipe.
For intermittent wiping, move the control up one position and adjust the rotary control to the desired speed.
For normal operation, move the control up two positions.
For high-speed wiping, move the control up three positions.
To activate the windshield washer, push the washer control button on the edge of the stalk.
Rear window wiper and washer*
Pull the lever toward you for intermittent wiping.
Pull further toward you to operate the washer.
4 HEATED FRONT WINDSHIELD*
The heated windshield control is located on the instrument panel.
To switch it on or off, push the button .
NOTE: The heated windshield turns off automatically. It will turn off after a predetermined amount of time, if a low-battery condition is detected or when the engine is turned off.
5 HAZARD FLASHER CONTROL
6 AM/FM STEREO WITH SINGLE CD*
Seek, scan, set and play radio stations and CDs. Refer to the Audio System chapter in your Owner’s Manual for more information.
POWER WINDOWS
Press or pull the window switches located on the center console near the cup holders to open or close a window.
*if equipped
USING SYNC® VOICE COMMANDS – SYNC...SAY THE WORD:
Press the voice button and when prompted, speak your voice command. For a list of voice commands, say “What can I say?"
USING MY PHONE WITH SYNC:
NOTE: You must download your phone book to make phone calls with voice commands by name.
Making a phone call:
Use SYNC to make a phone call to anyone in your phone book by pressing the voice button and when prompted, give a voice command:
For example, you could say, “Call Jake Smith at home”. When the system confirms the number, say “Dial” again to initiate the call.
NOTE: You can also make phone calls by pressing the voice button. When prompted, give the voice command, “Dial,” then verbally say the phone number.
Answering incoming calls:
Whenever you have an incoming call, you will be able to see the name and number of the person calling in your display. Press the phone button to answer an incoming call. You can hang up at any time by pressing and holding the phone button.
Do not disturb mode:
This feature blocks incoming calls and text messages, and saves them for later. You still have access to outgoing calls when this feature is active. Say the voice command “Do not disturb on” to enable and “Do not disturb off” to disable.
USING SYNC TO ACCESS DIGITAL MEDIA:
Use the media hub to plug in your media devices such as phones and MP3 players and use SYNC to play all of your favorite tunes. Since SYNC indexes your music, the more you have stored on your device, the longer it will take SYNC to index.
Using voice commands to play music:
1. Plug your media player into your USB port.
2. Press the voice button. When prompted say “USB”, then follow-up by saying one of the voice commands. For a list of voice commands, say “What can I say?”
3. You will hear the command repeated back to you and the selected item will play.
NOTE: Your SYNC voice-activated communications system with USB does not include: 911 Assist®, Vehicle Health Report (VHR), SYNC Services (TDI: Traffic, Directions & Information) or SYNC AppLink™.
Why You Need a SYNC Owner Account A SYNC owner account is required to receive the latest software updates.
U.S. Customers: visit SyncMyRide.com or call 1-800-392-3673 (select Option 1 or 2 for language, then Option 3 and Option 1). Canadian Customers: visit SyncMyRide.ca or call 1-800-565-3763 (select Option
1 or 2 for language, then Option 3 and Option 1).
SYNC®1
1
3
4
6
GETTING STARTED WITH YOUR SYNC® SYSTEM: SYNC is a hands-free, voice recognition system used for entertainment, information and communication. SYNC…Say the word.
GENERAL TIPS

For more complete information on SYNC, refer to your Owner’s Manual, visit the SYNC website2 or call toll-free number3.
Before you get started:
1. Set up your owner account by visiting your SYNC website2. Register by following the on-screen instructions. After registering, you can see what services you are eligible for.
2. SYNC uses a wireless connection called Bluetooth® to communicate with your phone. Turn Bluetooth mode on in your phone's menu options. This lets your phone find SYNC. For more details on setting up your phone with SYNC, visit SYNC online2 or your phone manufacturer’s website.
Pairing Your Phone with SYNC:
In order to use many of the features of SYNC, you must first pair and connect your phone with SYNC. To pair your phone for the first time:
1. Make sure that your vehicle is in P (Park) and both your ignition and radio are turned on.
2. Press the phone button. When the display indicates no phone is paired, press OK.
3. When the display asks you to add a device, press OK. The display will then show Find SYNC, which means the device is now ready to pair your phone. Press OK.
4. Put your phone into Bluetooth discovery mode. Refer to your phone’s user guide if necessary.
5. When prompted on your phone’s display, enter the six-digit PIN provided by SYNC in the radio display.
6. The display indicates when the pairing is successful.
NOTE: The system may prompt you to:
Set your phone as the primary/favorite (the primary phone will receive messages and voice mails).
Download your phone book (this is required to use the full set of voice commands).
TIPS:
Make sure you accept SYNC’s request to access your phone.
To pair subsequent phones, please refer to Pairing Subsequent Phones in the SYNC chapter of your Owner’s Manual.
If you are experiencing pairing problems, try performing a clean pairing by deleting your phone from SYNC, deleting the SYNC connection from your phone, and then repeating the Pairing Your Phone process. 1 If equipped.2 U.S. Customers: SyncMyRide.com. Canada Customers: SyncMyRide.ca. 3 U.S. Customers: 1-800-392-3673 (select 1 or 2 for language, then Option 3 and Option 1); Canadian Customers: 1-800-565-3673 (select 1 or 2 for language, then Option 3 and Option 1).
