2013 DODGE CHALLENGER SRT windshield wipers

WINDSHIELD WIPERS AND WASHERS ......166
▫ Intermittent Wiper System ...............167
▫ Mist Feature ........................ .167
▫ Windshield Washers ...................167
▫ Headlights On With Wipers (Available With
Automatic Headlights Only) .............168
 TILT/TELESCOPING STEERING COLUMN . . .169

HEATED STEERING WHEEL — IF EQUIPPED . .170
 ELECTRONIC SPEED CONTROL — IF
EQUIPPED .......................... .171
▫ To Activate ......................... .172
▫ To Set A Desired Speed .................173
▫ To Deactivate ....................... .173
▫ To Resume Speed .....................173 ▫
To Vary The Speed Setting ...............173
▫ To Accelerate For Passing ................174
 PARKSENSE® REAR PARK ASSIST — IF
EQUIPPED .......................... .175
▫ ParkSense® Sensors ....................175
▫ ParkSense® Warning Display .............175
▫ ParkSense® Display ....................176
▫ Enabling/Disabling ParkSense® ...........180
▫ Service The ParkSense® Rear Park Assist
System ............................ .180
▫ Cleaning The ParkSense® System ..........181
▫ ParkSense® System Usage Precautions .......181
 OVERHEAD CONSOLE ..................183
▫ Courtesy/Reading Lights ...............183
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103

Interior Light Defeat (OFF)
Rotate the dimmer control to the extreme bottom off
position. The interior lights will remain off when the
doors are open.
Parade Mode (Daytime Brightness Feature)
Rotate the dimmer control upward to the first detent.
This feature brightens all text displays such as the
odometer, Electronic Vehicle Information Center (EVIC),
and radio when the parking lights or headlights are on.
WINDSHIELD WIPERS AND WASHERS
The multifunction lever operates the windshield
wipers and washer when the ignition is placed in
the ON/RUN or ACC position. The multifunction
lever is located on the left side of the steering column. Rotate the end of the multifunction lever to the first
detent past the intermittent settings for low-speed wiper
operation, or to the second detent past the intermittent
settings for high-speed wiper operation.
Windshield Wiper/Washer Lever
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
Turn the windshield wipers off when driving
through an automatic car wash. Damage to the wind-
shield wipers may result if the wiper switch is left in
any position other than off.
Intermittent Wiper System
Use the intermittent wiper when weather conditions
make a single wiping cycle with a variable pause be-
tween cycles desirable. Rotate the end of the multifunc-
tion lever to the first detent position, and then turn the
end of the lever to select the desired delay interval. There
are four delay settings, which allow you to regulate the
wipe interval from a minimum of one cycle every second
to a maximum of approximately 36 seconds between
cycles. The delay intervals will double in duration when
the vehicle speed is 10 mph (16 km/h) or less.
Mist Feature
Rotate the end of the lever downward to the Mist
position to activate a single wipe cycle to clear off road
mist or spray from a passing vehicle. The wipers will
continue to operate until you release the multifunction
lever.
NOTE:The mist feature does not activate the washer
pump; therefore, no washer fluid will be sprayed on the
windshield. The wash function must be used in order to
spray the windshield with washer fluid.
Windshield Washers
To use the washer, push the multifunction lever inward
(toward the steering column) and hold it for as long as
washer spray is desired.
If you activate the washer while the windshield wiper
control is in the delay range, the wipers will operate for
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167

three wipe cycles after releasing the multifunction lever
and then resume the intermittent interval previously
selected.
If you activate the washer while the windshield wiper is
turned off, the wipers will operate for three wipe cycles
and then turn off.
WARNING!
Sudden loss of visibility through the windshield
could lead to a collision. You might not see other
vehicles or other obstacles. To avoid sudden icing of
the windshield during freezing weather, warm the
windshield with the defroster before and during
windshield washer use.
Headlights On With Wipers (Available With
Automatic Headlights Only)
When this feature is active, the headlights will turn on
approximately 10 seconds after the wipers are turned on
if the headlight switch is placed in the A (AUTO)
position. In addition, the headlights will turn off when
the wipers are turned off if they were turned on by this
feature.
The Headlights On with Wipers feature can be enabled or
disabled. Refer to “Electronic Vehicle Information Center
(EVIC)/Personal Settings (Customer-Programmable Fea-
tures)” in “Understanding Your Instrument Panel” for
further information.
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Refrigerant Recovery And Recycling
R-134a Air Conditioning Refrigerant is a hydrofluoro-
carbon (HFC) that is endorsed by the Environmental
Protection Agency and is an ozone-saving product. How-
ever, the manufacturer recommends that air conditioning
service be performed by authorized dealer or other
service facilities using recovery and recycling equipment.
NOTE:Use only manufacturer approved A/C system
sealers, stop leak products, seal conditioners, compressor
oil, and refrigerants.
A/C Air Filter
The filter is located in the fresh air inlet under the hood,
behind a removable panel in the cowl on the passenger
side of the vehicle, next to the windshield wipers. When
installing a new filter, ensure its proper orientation. 1. Remove the access door in the cowl screen by pressing
the retaining clips.
2. Unsnap both ends and lift the filter access cover.
Access Door
424 MAINTAINING YOUR VEHICLE

Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, door hinge pivot points and rollers, liftgate,
tailgate, sliding doors and hood hinges, should be lubri-
cated periodically with a lithium based grease, such as
MOPAR® Spray White Lube to assure quiet, easy opera-
tion and to protect against rust and wear. Prior to the
application of any lubricant, the parts concerned should
be wiped clean to remove dust and grit; after lubricating
excess oil and grease should be removed. Particular
attention should also be given to hood latching compo-
nents to ensure proper function. When performing other
underhood services, the hood latch, release mechanism
and safety catch should be cleaned and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the Fall and Spring. Apply a small
amount of a high quality lubricant, such as MOPAR®
Lock Cylinder Lubricant directly into the lock cylinder.
Windshield Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield periodically with a sponge or soft cloth and a
mild nonabrasive cleaner. This will remove accumula-
tions of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
Avoid using the wiper blades to remove frost or ice from
the windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.
NOTE:Life expectancy of wiper blades varies depend-
ing on geographical area and frequency of use. Poor
performance of blades may be present with chattering,
marks, water lines or wet spots. If any of these conditions
are present, clean the wiper blades or replace as neces-
sary.
426 MAINTAINING YOUR VEHICLE

Coolant Level......................... .430
Disposal of Used Coolant .................434
Drain, Flush, and Refill ...................431
Inspection ........................... .434
Points to Remember .....................435
Pressure Cap ......................... .433
Radiator Cap ......................... .433
Selection of Coolant (Antifreeze) .............431
Corrosion Protection ...................... .442
Cruise Light ............................ .210
Cupholders ............................ .200
Customer Assistance ...................... .489
Data Recorder, Event .......................72
Daytime Brightness, Interior Lights .............166
Daytime Running Lights ....................161
Dealer Service ........................... .416
Deck Lid, Emergency Release .................45
Deck Lid, Power Release .....................43 Defroster, Rear Window
.....................203
Defroster, Windshield .......................97
Delay (Intermittent) Wipers ..................167
Diagnostic System, Onboard .................414
Dimmer Switch, Headlight ...................164
Dipsticks Oil (Engine) .......................... .418
Disabled Vehicle Towing ....................406
Disposal Antifreeze (Engine Coolant) ................434
Door Locks ..............................32
Door Locks, Automatic ......................34
Driving Through Flowing, Rising, or Shallow Standing
Water ............................... .325
Electrical Power Outlets .....................196
Electric Remote Mirrors .....................108
Electronic Brake Control System ...............335
10
INDEX 501

Windshield Defroster.......................97
Windshield Washers ...................... .166
Fluid ............................... .427
Windshield Wiper Blades ....................426
Windshield Wipers ....................... .166
Wiper Blade Replacement ...................426
Wipers, Intermittent ...................... .167
516 INDEX
