•Make sure that the coolant expansion bottle overflow
hoses are not kinked or obstructed.
• Keep the front of the radiator clean. If your vehicle is
equipped with air conditioning, keep the front of the
condenser clean.
• Do not change the thermostat for Summer or Winter
operation. If replacement is ever necessary, install
ONLY the correct type thermostat. Other designs may
result in unsatisfactory engine coolant (antifreeze)
performance, poor gas mileage, and increased emis-
sions.
Brake System
In order to assure brake system performance, all brake
system components should be inspected periodically.
Refer to the “Maintenance Schedule” for the proper
maintenance intervals.
WARNING!
Riding the brakes can lead to brake failure and
possibly a collision. Driving with your foot resting or
riding on the brake pedal can result in abnormally
high brake temperatures, excessive lining wear, and
possible brake damage. You would not have your full
braking capacity in an emergency.
Master Cylinder – Brake Fluid Level Check
Check the fluid level in the master cylinder immediately
if the brake system warning light indicates system fail-
ure.
Check the fluid level in the master cylinder when per-
forming underhood services.
Clean the top of the master cylinder area before removing
the cap. Add fluid to bring the level up to the “MAX”
mark on the side of the master cylinder reservoir.
7
MAINTAINING YOUR VEHICLE 469

CAUTION!
Using a transmission fluid other than the manufac-
turer ’s recommended fluid may cause deterioration
in transmission shift quality and/or torque converter
shudder, and will require more frequent fluid and
filter changes. Refer to “Fluids, Lubricants, and
Genuine Parts” in this section for fluid specifica-
tions.
Special Additives
The manufacturer strongly recommends against using
any special additives in the transmission.
Automatic Transmission Fluid (ATF) is an engineered
product and its performance may be impaired by supple-
mental additives. Therefore, do not add any fluid addi-
tives to the transmission. The only exception to this
policy is the use of special dyes for diagnosing fluidleaks. Avoid using transmission sealers as they may
adversely affect seals.
CAUTION!
Do not use chemical flushes in your transmission as
the chemicals can damage your transmission compo-
nents. Such damage is not covered by the New
Vehicle Limited Warranty.
Fluid Level Check
The fluid level is preset at the factory and does not
require adjustment under normal operating conditions.
Routine fluid level checks are not required, therefore the
transmission filler tube is capped and no dipstick is
provided.
Your authorized dealer can check your transmission fluid
level using a special service dipstick. If you notice fluid
7
MAINTAINING YOUR VEHICLE 473

NOTE:Under no circumstances should oil change inter-
vals exceed 10,000 miles (16,000 km) or twelve months,
whichever comes first.
Once A Month Or Before A Long Trip:
• Check engine oil level
• Check windshield washer fluid level
• Check the tire inflation pressures and look for unusual
wear or damage
• Check the fluid levels of the coolant reservoir, brake
master cylinder, power steering and transmission as
needed
• Check function of all interior and exterior lights
Required Maintenance Intervals.
Refer to the maintenance schedules on the following
page for the required maintenance intervals.At Every Oil Change Interval As Indicated By Oil Change Indicator System:
•Change oil and filter
• Rotate the tires. Rotate at the first sign of irregu-
lar wear, even if it occurs before the oil indicator
system turns on.
• Inspect battery and clean and tighten terminals as
required
• Inspect automatic transmission fluid if equipped
with dipstick
• Inspect brake pads, shoes, rotors, drums, hoses
and park brake
• Inspect engine cooling system protection and
hoses
• Inspect exhaust system
• Inspect engine air cleaner if using in dusty or
off-road conditions
8
M
A I
N T
E
N
A
N
C E
S
C
H E
D
U L
E
SMAINTENANCE SCHEDULES 501

Caps, FillerFuel ................................ .383
Oil (Engine) .......................... .451
Radiator (Coolant Pressure) ................466
Carbon Monoxide Warning ...................97
Cargo (Vehicle Loading) ....................386
Car Washes ............................ .476
Cellular Phone .......................... .280
Center High Mounted Stop Light ..............494
Certification Label ........................ .386
Chains, Tire ............................ .366
Changing A Flat Tire ...................... .418
Chart, Tire Sizing ........................ .344
Check
Engine Light (Malfunction Indicator Light). . .445
Checking Your Vehicle For Safety ...............97
Checks, Safety ............................97
Child Restraint ............................74
Clean Air Gasoline ....................... .380Cleaning
Wheels .............................. .477
Climate Control ......................... .280
Clock ................................. .243
Cold Weather Operation ....................300
Compact Disc (CD) Maintenance ..............279
Compact Spare Tire ....................... .361
Compass .............................. .233
Compass Calibration ...................... .234
Compass Variance ........................ .234
Computer, Trip/Travel ..................... .229
Connector UCI................................ .268
Universal Consumer Interface (UCI) ..........268
Conserving Fuel ......................... .229
Console ............................... .203
Console, Floor .......................... .203
Console, Overhead ....................... .184
Contract, Service ......................... .512
522 INDEX

Driving to Achieve Maximum Fuel Economy......229
Electrical Power Outlets .....................198
Electric Remote Mirrors .....................110
Electronic Brake Control System ...............332
Electronic Power Distribution Center (Fuses) ......483
Electronic Speed Control (Cruise Control) ........173
Electronic Stability Control (ESC) ..............337
Electronic Throttle Control Warning Light ........213
Electronic Vehicle Information Center (EVIC) ......224
Emergency Deck Lid Release ..................45
Emergency, In Case of Freeing Vehicle When Stuck ................432
Hazard Warning Flasher ..................406
Jacking .............................. .418
Jump Starting ......................... .427
Overheating .......................... .406
Towing ............................. .435
Emergency Trunk Release ....................45 Emission Control System Maintenance
..........445
Engine ................................ .443
Air Cleaner .......................... .453
Block Heater ......................... .303
Break-In Recommendations .................96
Checking Oil Level ..................... .448
Compartment ......................... .442
Compartment Identification ................442
Coolant (Antifreeze) .....................463
Cooling ............................. .463
Exhaust Gas Caution .....................97
Fails to Start .......................... .301
Flooded, Starting ...................... .301
Fuel Requirements ..................... .378
Jump Starting ......................... .427
Oil................................. .448
Oil Filler Cap ......................... .451
Oil Selection .......................... .450
Oil Synthetic ......................... .452
524 INDEX

Overheating.......................... .406
Starting ............................. .294
Temperature Gauge ..................... .214
Engine Oil Viscosity ...................... .451
Engine Oil Viscosity Chart ...................451
Enhanced Accident Response Feature ............69
Entry System, Illuminated ....................22
Ethanol ............................... .380
Event Data Recorder ........................72
Exhaust Gas Caution ........................97
Exhaust System ...........................97
Exterior Folding Mirrors ....................110
Exterior Lighting ......................... .162
Exterior Lights .......................... .101
Filler Location Fuel ....................... .383
Filters Air Cleaner .......................... .453
Air Conditioning ...................... .287Engine Oil
........................... .452
Engine Oil Disposal .....................452
Flashers Hazard Warning ....................... .406
Turn Signal .......................... .101
Flash-To-Pass ........................... .167
Flooded Engine Starting ....................301
Fluid, Brake ............................ .498
Fluid Capacities ......................... .495
Fluid Leaks ............................ .101
Fluid Level Checks Automatic Transmission ..................473
Brake ............................... .469
Cooling System ........................ .463
Engine Oil ........................... .448
Fluids, Lubricants and Genuine Parts ...........496
Fog Lights ............................. .165
Folding Rear Seat ........................ .158
Freeing A Stuck Vehicle .....................432
10
INDEX 525

Automatic Headlights....................163
Brake Assist Warning ....................341
Brake Warning ........................ .219
Bulb Replacement ...................... .490
Center Mounted Stop ....................494
Courtesy/Reading ..................... .167
Cruise .............................. .212
Daytime Running ...................... .164
Dimmer Switch, Headlight .................166
Electronic Stability Program (ESP) Indicator .....341
Electronic Throttle Control Warning ..........213
Engine Temperature Warning ...............215
Exterior ............................. .101
Fog ................................ .165
Hazard Warning Flasher ..................406
Headlights ........................... .162
Headlights On Reminder ..................165
Headlights On With Wipers ................163
Headlight Switch ...................... .162High Beam
........................... .167
High Beam Indicator .....................217
High Beam/Low Beam Select ...............167
Illuminated Entry ........................22
Instrument Cluster ..................... .162
Intensity Control ....................... .168
Interior ............................. .168
License ............................. .494
Lights On Reminder .....................165
Low Fuel ............................ .223
Malfunction Indicator (Check Engine) .........223
Map Reading ......................... .167
Oil Pressure .......................... .217
Parade Mode (Daytime Brightness) ...........169
Passing ............................. .167
Reading ............................. .167
Seat

Belt Reminder ..................... .217
Security Alarm (Theft Alarm) ...............220
Service .............................. .489
10
INDEX 529

Service Engine Soon (Malfunction Indicator) . . . .223
Theft Alarm (Security Alarm)...............220
Tire Pressure Monitoring (TPMS) ............220
Traction Control ....................... .341
Turn Signal .......................... .101
Vanity Mirror ..........................111
Voltage ............................. .213
Warning (Instrument Cluster Description) ......212
Loading Vehicle ......................... .386
Capacities ........................... .388
Tires ............................... .349
Locks ..................................33
Automatic Door .........................35
Auto Unlock ...........................35
Door .................................33
Power Door ............................34
Low Tire Pressure System ...................368
Lubrication, Body ........................ .458Maintenance Free Battery
....................453
Maintenance Procedures ....................448
Maintenance Schedule ..................... .500
Malfunction Indicator Light (Check Engine) .......223
Manual, Service ......................... .515
Manual Transmission ..................... .304
Fluid Level Check ...................... .472
Map/Reading Lights ...................... .167
Master Cylinder (Brakes) ....................469
Methanol .............................. .380
Mini-Trip Computer ...................... .229
Mirrors ............................... .108
Automatic Dimming .....................108
Electric Powered ........................110
Electric Remote .........................110
Exterior Folding ........................110
Heated ...............................111
Outside ............................. .109
530 INDEX
