2013 Citroen DS5 ESP

Storing driving positions
System which stores the electrical settings
of the driver's seat and the head-up display settings. It enables you to store up to two positions using the buttons on the side of the driver's seat.

Storing a position usingbuttons M / 1 / 2

)
Switch on the ignition. )
Adjust your seat and the head-up display.)
Press button M
, then press button 1or 2within four seconds.
An audible signal indicates that the positionhas been stored.
Storing a new position cancels the previous
position.

Recalling a stored position
)Briefly press button 1
or 2to recall the corresponding position.
An audible signal indicates the end of the
adjustment.
You can interrupt the current movementby pressing button M, 1
or 2
or by using one of the seat controls. A stored position cannot be recalled while driving. Recalling stored positions is deactivated 45 seconds after switching off the ignition.

79Comfort








Rear seats
Bench seat with split cushion and backrest (left hand 2/3, right hand 1/3) which can be folded individually to adapt the load space in the boot.
)Move the corresponding front seat forward
if necessary. )Place the head restraints in the low position or remove them. )Remove the seat belt from its guide.
Folding the cushion and
backrest
)
Lift the cushion 1by hand, lifting from therear.

)
Tip the seat cushion 1
fully against the frontseat.
)
Keep the seat belt guide 2
held against the
vehicle.

)
Pull control 3forwards to release the seatback 4.)
Fold the seat backrest 4.

Mirrors
Each fitted with an adjustable mirror glassproviding the lateral rearward vision necessaryfor overtaking or parking. They can also be
folded for parking in confined spaces.
Door mirrors
If the mirrors are folded using control A ,they will not unfold when the vehicle is unlocked.


The folding and unfolding of the door mirrors using the electronic key can bedeactivated by a CITROËN dealer or a qualified workshop.
Fold the mirrors when putting your vehicle through an automatic car wash.
The objects observed are, in reality, closer than they appear.Ta k e this into account in order to correctly judge the distance of vehicles approaching from behind.

Demisting - Defrosting
Ad
justment
)
Turn control A
to the right or to the left toselect the corresponding mirror. )
Move control Ain all four directions toadjust. )
Return control Ato the central position.
Folding



- Automatic: lock the vehicle using the electronic key.


Unfolding



- Automatic: unlock the vehicle using the electronic key.
-
Manual: with the ignition on, turn control Adownwards.

- Manual: with the i
gnition on, turn control Aupwards.
Demisting-defrosting of the door
mirrors operates by switching on
the heated rear screen.
For more information, refer to
the "Rear screen demist-defrost" section.
The rear screen demist - defrostcan only operate when the engine isrunning.

93Comfort
4. Automatic visibilityprogramme


For maximum cooling or heating of thepassenger compar tment, it is possibleto exceed the minimum value 14 or themaximum value 28.)
Turn control 2or 3
to the left until "LO"is displayed or to the right until "HI"
is displayed. See "Front demistin
g - defrosting".


2-3. Driver's-passenger's side
settings
The driver and front passenger can each adjust the temperature to their requirements.
The value indicated on the display corresponds to a level of comfor t and not to a
temperature in degrees Celsius or Fahrenheit.
)Turn control 2or 3to the left or to the right respectively to decrease or increase this
value.

A setting around the value 21 provides
optimum comfort. However, depending on your
requirements, a setting between 18 and 24 isnormal.
You are advised to avoid a left / right settingdifference of more than 3.

Manual operation

If you wish, you can make a different choice from that offered by the system by changing asetting. The "AUTO"
indicator lamps go off; theother functions, except the air conditioning, willstill be controlled automatically.)
Pressing the "AUTO"
button returns the system to completely automatic operation.
With Stop & Star t, when demisting hasbeen activated, the STOP mode is not available.

113Driving











Gear shift indicator * System which reduces fuel consumption by advising the driver to change up on vehicles fitted with a manual gearbox.


Operation
The system intervenes only when driving economically.
Depending on the driving situation and your
vehicle's equipment, the system may advise you to skip one or more gears. You can
follow this instruction without engaging the
intermediate gears.
The gear engagement recommendations mustnot be considered compulsory. In fact, the configuration of the road, the amount of traffic
and safety remain determining factors whenchoosing the best gear. Therefore, the driver
remains responsible for deciding whether or not
to follow the advice given by the system.
This function cannot be deactivated.

*
Accordin
g to engine. -
You are in third gear.
Example:
-
You press the accelerator pedalmoderately.
-
The system may suggest that you engage a higher gear, if appropriate.

The information appears in the instrument
panel in the form of an arrow accompanied b
y
the suggested gear.

In the case of driving which makes
par ticular demands on the performance of the engine (firm pressure on theaccelerator pedal, for example, whenover taking...), the system will not recommend a gear change.
The system never suggests:


- engaging first gear,

- engaging reverse gear,

- engaging a lower gear.

Displays in the instrument panel

When you move the lever in the gate to select aposition, the corresponding indicator comes on in the instrument panel. P Park R Reverse
N Neutral D Drive (automatic driving)SSport
programme 7
Snowprogramme 1 to 6Gear engaged during manual operation-
Invalid value during manual operation
Six speed automatic gearbox which offers a
choice between the comfor t of fully automatic
operation, enhanced by spor t and snow programmes, or manual gear changing.
Four driving modes are offered:-automaticoperation for electronic
management of the gears by the gearbox, -sport
programme for a more dynamic style
of driving,- snowprogramme to improve driving when
traction is poor,
- manualoperation for sequential changing
of the gears by the driver.














Automatic gearbox
1.
Gear lever.2.
Button "S"
(sport) . 3.Button "7"(snow).
Gear lever
Gear selection
gate
P.Park.


- Immobilisation of the vehicle, parking brake on or off.

- Starting the engine.R.
Reverse.


- Reversing manoeuvres, vehicle stationary,engine at idle. N.Neutral.


- Immobilisation of the vehicle, parking brake on.

- Starting the engine.D.Automatic operation.M.+ / -
Manual operation with sequential changing of the six gears. )
Push for wards to change up through the gears.
or ) Pull backwards to change down through
the gears.

6-speed electronic gearbox system
Six-speed electronic gearbox system which
o
ffers a choice between the comfor t of fully automatic operation or the pleasure of manualgear changing.
There are two driving modes: -automaticmode for automatic control of
t
he gears by the gearbox,-manualmode for sequential gear changingby the driver.
For each of these two modes, there is a a Sport
setting, corresponding to a more
dynamic driving style.
In automatic mode, it remains possible to
change gear manually by using the steering mounted control paddles when required, when
over taking, for example.
R. Reverse)
With your foot on the brake, lift the lever
and push forwards.N.Neutral. ) With your foot on the brake, select this
position to start.
A
. Automatic mode. )
Move the lever backwards to select this
mode. M.
Manual mode with sequential gear changing.)
Lift the lever then move it backwards to select this mode, then use the steeringmounted control paddles to change gear.
S. Sport setting. )
Press the button to switch it on or off.


Gear lever
+.
Change up paddle to the right of the steeringwheel.)Press the back of the "+"
steering mounted paddle to change up a gear.-.
Change down paddle to the left of the
steerin
g wheel. )Press the back of the "-"steering mounted paddle to change down a gear.


Steering mounted control paddles


The steering mounted paddles cannotbe used to select neutral or to engageor disengage reverse gear.

125
Driving





Lane departure warning system
System which, using a camera which
recognises solid or broken lines, detects the
involuntary crossing of longitudinal traffic lane markings on the ground.
To provide safe driving, the camera analyses
the image then, if the driver's attention drops,
triggers a warning if the vehicle drifts over
a lane marking (speed higher than 50 mph (80 km/h)).
This system is par ticularly useful on motor waysand main roads.
Activation
)
Press this button, the indicator
lamp comes on.


The lane depar ture warning system
cannot, in any circumstances, replacethe need for vigilance and responsibility on the par t of the driver.
Deactivation
You are warned by the vibration of the driver's seat cushion:
- on the right-hand side, if the marking on theground has been crossed on the right,
- on the left-hand side, if the marking on the ground has been crossed on the left.
No warning is transmitted while the direction indicator is active and for approximately 20 seconds after the direction indicator is switched off.
Detection - alert
Operatin
g fault


The detection may be impeded:


- if the markings on the groundare worn,

- if there is little contrast between themarkings on the ground and the roadsurface.

- if the windscreen is dir ty,

- in certain severe weather conditions: fog, heavy rain, snow, bright sunlight or direct exposure to the sun (low sun, leaving a tunnel, ...) and shade.
)
Press this button again, the
indicator lamp goes off. In the event of a fault, the indicator lamp in the
button flashes.
Contact a CITROËN dealer or a qualified
wor
kshop.
The status of the s
ystem remains in the
memory when the ignition is switched off.
