2013 Citroen DS3 RHD tow

CHECKS PRACTICAL
INFORMATIONTECHNICAL DATA AUDIO AND
TELEMATICS
191Bonnet
192Running out of fuel (Diesel)
193Petrol engines
194 Diesel engines
195 Checking levels
198Checks
202Temporary puncture repair kit
209Changing a wheel
216 Snow chains
217 Changing a bulb
225 Changing a fuse
232Battery
235 Energy economy mode
236 Changing a wiper blade
237 Towing the vehicle
239To w i ng a trailer
241 Advice on care andmaintenance
242Accessories
246 Petrol engines
248 Petrol weights
250 LPG engines
251 LPG weights
252Diesel engines
253 Diesel weights
254 Dimensions
256 Identifi cation markings
261Emergency or assistance
263eMyWay
317 Audio system
012012013013010010011011

Seeing clearly
Lighting
Ring A
Ring B


Wipers
112


Control stalk A: windscreen
wipers
2. Fast wipe.
1.Normal wipe. Int.Intermittent wipe.
0. Park.
AUTO ÈAutomatic wiping or single wipe.
Screenwash: pull the stalk towards you.
118

Switching on "AUTO" mode
)Push the stalk downwards and release it.


Switching off "AUTO" mode
)Push the stalk upwards and return it toposition "0"
.

Ring B: rear wiper
120
11
9
Lighting off.
Automatic illumination o
f headlamps.

Sidelamps.
Dipped
/ main beam headlamps.
Front and rear
foglamps.
P
ark.
Intermittent wipe.
Wash-wi
pe.

Before moving off, if the passenger compar tment is too warm, ventilate it by opening the windows and air vents before using the air conditioning.
Above 30 mph (50 km/h), close the windows and leave the air vents open.
Remember to make use of equipment that can help keep the temperature in the passenger compar tment down (sunroof and windowblinds...). Switch off the air conditioning, unless it has automatic regulation, as soon as the desired temperature is attained. Switch off the demisting and defrosting controls, if not automatic.
Switch off the heated seat as soon as possible.


Switch off the headlamps and front foglamps when the level of lightdoes not require their use.


Avoid running the engine before moving off, par ticularly in winter; your vehicle will warm up much faster while driving.
















































Eco-driving

Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.


Optimise the use of your gearbox


With a manual gearbox, move off gently and change up without waiting. During acceleration change up early.


With an automatic or electronic gearbox, give preference to automatic mode and avoid pressing the accelerator pedal heavily or suddenly.


The gear efficiency indicator invites you to change up: as soon as the indication to change up is displayed in the instrument panel, follow it straight away.
With an electronic or automatic gearbox, this indicator appears only in manual mode.



Drive smoothly


Maintain a safe distance between vehicles, use engine braking rather than the brake pedal, and press the accelerator progressively. These practices contribute towards a reduction in fuel consumption andCO2emissions and also helps reduce the background traffic noise.


Control the use of your electrical
equipment


If your vehicle has cruise control, make use of the system at speedsabove 25 mph (40 km/h) when the traffic is flowing well.



As a passenger, if you avoid connecting your multimedia devices (film, music, video game...), you will contribute towards limiting theconsumption of electrical energy, and so of fuel.
Disconnect your por table devices before leaving the vehicle.

33Monitoring

Operation indicator lamps

If one of the following indicator lamps comes on, this confirms that the corresponding system has come into operation.
Warning lampis onCauseAction / Observations
Left-hand direction indicatorflashing with buzzer. The lighting stalk is pushed down.
Right-handdirection indicatorflashing with buzzer. The lighting stalk is pushed up.
Sidelampsfixed. The lighting stalk is in the "Sidelamps"
position.
Dipped beam headlampsfixed. The lighting stalk is in the "Dippedbeam headlamps" position.
Main beamheadlampsfixed. The lighting stalk is pulled towards you. Pull the stalk to return to dipped beam headlamps.
Front foglampsfixed. The front foglamps are switched on. Turn the ring on the stalk rear wards twice to switch off
the front foglamps.
Rear foglampsfixed. The rear foglamps are switched on. Turn the ring on the stalk rear wards to switch off the rear foglamps.




Hazard warning lamps
flashing with audiblesignal.The hazard warning lamps switch, located on the dashboard, has been
operated. The le
ft-hand and right-hand direction indicators and
their associated indicator lamps flash simultaneously.

67
Comfort











Recommendations for ventilation and air conditioning


If after an extended stop in sunshine, the interior temperature is veryhigh, first ventilate the passenger compartment for a few moments. Put the air flow control at a setting high enough to quickly change the air in the passenger compartment.
The air conditioning system does notcontain chlorine and does not present any danger to the ozone layer.

In order for these systems to be fully effective, follow the operation and maintenance guidelines below: )
To obtain an even air distribution, take care not to obstruct the exterior air intake grilles located at the base of the windscreen, the nozzles, the vents and the air outlets, as wellas the air extractor located in the boot. )
Do not cover the sunshine sensor, located on the dashboard; this is used for regulation of the air conditioning system. )
Operate the air conditioning system for at least 5 to 10 minutes, once or twice a monthto keep it in perfect working order. )
Ensure that the passenger compar tment filter is in good condition and have the filter elements replaced regularly. We recommend the use of a combined passenger compar tment filter. Thanks to its special active additive, it contributes to the purification of the air breathed by theoccupants and the cleanliness of the passenger compartment (reduction of allergic symptoms, bad odours and greasy deposits).)
To ensure correct operation of the air conditioning system, you are also advised to haveit checked regularly as recommended in the maintenance and warranty guide. )
If the system does not produce cold air, switch it off and contact a CITROËN dealer or a qualified workshop.
When towing the maximum load on a steep gradient in high temperatures, switching off theair conditioning increases the available engine power and so improves the towing ability.

The condensation created by the air conditioning results in a dischargeof water under the vehicle which is perfectly normal.

75
Comfort

6. Air distribution adjustment
Pressing this button several times insuccession enables the air flow to bedirected in turn towards:


- t
he windscreen and the side windows(demisting or defrosting),

- the windscreen, side windows and air
vents,

- the windscreen, the side windows, the air
vents and the footwells,

- the windscreen, the side windows and the
footwells,

- the footwells
,

- the air vents and the footwells,

- the air vents.

Avoid driving for long periods with the air conditioning switched off (risk of misting and reduction of the air quality in the cabin).

Press the "full fan"button toincrease the air flow.
7. Air fl ow adjustment
The air flow symbol, the fan, fills progressively according to the value requested.
Pr
ess the "empty fan"
button todecrease the air flow.


Switching the system off
Press the air flow "empty fan"button 7until the fan symbol
disappears.
Thi
s action switches off all of the functions of
the air conditioning system.
Thermal comfort is no longer controlled. A slight flow of air resulting from the movementof the vehicle, remains perceptible however.
Pressing the air flow "full fan"
button 7 or on "AUTO"reactivates the system with the
values set before it was switched off.

RACING front seats Seat consisting of a seat cushion and backrest which can be adjusted to adapt your position for maximum ease of driving and comfort.
Manual adjustments
Forwards-backwards adjustment
)Lift the control and slide the seat forwardsor backwards.

Height adjustment
)
Pull the handle upwards to raise or push
it downwards to lower, as many times as
necessar
y to obtain the required position.
Backrest angle adjustment
)Push the handle towards the rear and move
the seat backrest forwards or backwards.

85
Comfort
These have one position for use (up) and a stowed position (down).
They can also be removed.
To remove a head restraint: )release the backrest using control 1,)tilt the backrest 2slightly forwards, )pull the head restraint upwards to the stop, )then, press the lug A
.

Rear head restraints

Never drive with the head restraints removed; they must be in place and correctly adjusted.









Steering wheel adjustment
)When stationary, pull the control lever toyrelease the adjustment mechanism.)
Adjust the height and reach to suit your
driving position. ) Push the control lever to lock the
adjustment mechanism.
As a safety precaution, theseoperations should only be carried outwhile the vehicle is stationary.
