22
Familiarisation
Stop & Start
Going into engine STOP mode
The "ECO" warning lamp comes on in
the instrument panel and the engine
automatically goes into standby:
-with a manual gearbox , at speeds below
12 mph (20 km/h), when you put the
selector lever into neutral, and you release
the clutch pedal,
- with a 6-speed electronic
gearbox, at
speeds below 5 mph (8 km/h), when youpress the brake pedal or when you put the
selector lever in position N.-with an automatic gearbox , with the
vehicle stationary, when you press the
brake pedal or when you put the selector
lever in position N.
In some circumstances, ST
OP mode may not
be available; the " ECO" warning lamp flashes
for few seconds, then goes off.
160

Going into engine START mode
The "ECO" warning lamp goes off
and the engine restarts automatically:
-with a manual gearbox, when you fullydepress the clutch pedal,-with a 6-speed electronic gearbox:


●
selector lever in position Aor M
, when
you release the brake pedal,

●
or selector lever in
position Nand brake
pedal released, when you change to
position Aor M ,

●
or when you engage reverse. -with an automatic gearbox:


●
selector lever in position Dor M
, when you release the brake pedal,

●
or selector lever in position Nand brake
pedal released, when you change to
position Dor M ,

●
or when you engage reverse.

161

Driving safely

.
23
Familiarisation
168, 171, 174
Driving safely


Steering wheel with
integrated controls


Controls for speed limiter / cruisecontrol / active cruise controlOther controls
56
Audio system controls
or



Audio system and telephonecontrols

Audio system, navigation and telephone controls
35, 37
21
9
194
341
341
1.Black panel (black screen).
2
. Control of the display mode of the type 2
in
strument screen.
3. Courtesy lamp on / off.
or
Park Assist

24
Familiarisation

Optimise the use of your gearbox


With a manual gearbox, move off gently and change up without waiting. During acceleration change up early.


With an automatic or electronic gearbox, give preference to automatic mode and avoid pressing the accelerator pedal heavily or suddenly.


Control the use of your electrical
equipment


Before moving off, if the passenger compartment is too warm, ventilate it by opening the windows and air vents before using the air conditioning.
Above 30 mph (50 km/h), close the windows and leave the air ventsopen.
Remember to make use of equipment that can help keep the temperature in the passenger compar tment down (sunroof and windowblinds...).
Switch off the air conditioning, unless it has automatic digital regulation,as soon as the desired temperature is attained.
Switch off the demisting and defrosting controls, if not automatic.
Switch off the heated seat as soon as possible.


Switch off the headlamps and front foglamps when the level of lightdoes not require their use.


Avoid running the engine before moving off, par ticularly in winter; your vehicle will warm up much faster while driving.


As a passenger, if you avoid connecting your multimedia devices (film, music, video game...), you will contribute towards limiting the
consumption of electrical energy, and so of fuel.
Disconnect your por table devices before leaving the vehicle.

















































Eco-driving

Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.


Drive smoothly


Maintain a safe distance between vehicles, use engine braking rather than the brake pedal, and press the accelerator progressively. These practices contribute towards a reduction in fuel consumption and CO2emissions and also helps reduce the background traffic noise.


If your vehicle has cruise control, make use of the system at speedsabove 25 mph (40 km/h) when the traffic is flowing well.



The gear shift indicator invites you to change up: as soon as theindication to change up is displayed in the instrument panel, follow it straight away.
With an electronic or automatic gearbox, this indicator appears only in manual mode.

34
Monitoring
This instrument panel is presented in the form of a 12-inch panoramic HD screen.
It can be personalised. Depending on the display mode selected, some information can be hidden (see "Personalisation of the instrument panel").





Type 2 instrument panel
1.
Rev counter (x 1000 tr/min or rpm) ("DIALS" mode).2.
Gear shift indicator, position of the selector lever and the gear on an electronic or automatic gearbox.3.Digital speedometer (mph or km/h).4.
Cruise control or speed limiter setting. A
.Recall servicing information.
Reset the function selected to zero (service
indicator or trip recorder).



Control button Dials and screens
5.Fuel gauge.
6. Total distance recorder (miles or km).
7.Trip distance recorder (miles or km).8. Repeat of the air conditioning settings. 9.Repeat of the current media or telephone
information.
10. Repeat of the navigation information.

1
37
Monitoring

- "DRIVING": used for the display of the
inter-vehicle time and information related tothe active cruise control.
The recommended speed is displayed in
the central part.
The driver remains responsible fo
r
observing the driving regulations. To m o d i
fy the display mode of the instrument panel:) turn the wheel on the left of the steering
wheel to display and run through the
different modes in the right hand part of the
instrument panel,
) once the selected display mode appearsin the central window, press the wheel to confirm your choice. )
The new mode is applied immediately.

38
Monitoring
Indicator and warning lamps
Cer tain warning lamps may come on inone of two modes: fixed (continuous) or flashing.
Only by relating the type of illuminationto the operation of the vehicle can it be determined whether the situation isnormal or a fault has occurred. In the event of a fault, the illumination of the warning lamp may be accompanied bya message.
Refer to the tables on the following pages for more information. Visual indicators informin
g the driver that a system is in operation, switched off or has a
fault.
When the ignition is switched on
Certain warning lamps come on for a fewseconds in the instrument panel when the
vehicle's ignition is switched on.
When the en
gine is started, these same
warning lamps should go off.
If they remain on, before moving off, refer to the
information on the warning lamp concerned.


Associated warnings

The switching on of cer tain warning lamps may be accompanied by an audible signal and a
message.
The warning lamps may come on continuously (fixed) or flash.


The position of the warning lamps in the type 2 instrument panel depends on thecolour scheme selected.
