Instruments and controls

20















































Eco-driving
Optimise the use of your gearbox
With a manual gearbox, move off gently, change up without waiting and drive by changing up quite soon. If your vehicle has the system, the gear efficiency indicator invites you to change up; it is displayed in theinstrument panel, follow its instructions.
With an automatic or electronic gearbox, stay in Drive "D"or Auto "A"
, according to the type of gearbox, without pressing the accelerator pedalheavily or suddenly.

Drive smoothly
Maintain a safe distance between vehicles, use engine braking rather than the brake pedal, and press the accelerator progressively. Thesepractices contribute towards a reduction in fuel consumption and CO2emissions and also helps reduce the background traffic noise.


If your vehicle has cruise control, make use of the system at speedsabove 25 mph (40 km/h) when the traffic is flowing well.



Control the use of your electrical
equipment


Before moving off, if the passenger compar tment is too warm, ventilate it by opening the windows and air vents before using the air conditioning.
Above 30 mph (50 km/h), close the windows and leave the air ventsopen.
Remember to make use of equipment that can help keep the temperature in the passenger compar tment down (sunroof and windowblinds...).
Switch off the air conditioning, unless it has automatic digital regulation,as soon as the desired temperature is attained. Switch off the demisting and defrosting controls, if not automatic. Switch off the heated seat as soon as possible.


Switch off the headlamps and front foglamps when the level of lightdoes not require their use.


Avoid running the engine before moving off, particularly in winter; your vehicle will warm up much faster while driving.


As a passenger, if you avoid connecting your multimedia devices
(film, music, video game...), you will contribute towards limiting theconsumption of electrical energy, and so of fuel.
Disconnect your por table devices before leaving the vehicle.

Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2emissions.

Monitoring
22

















Petrol - Diesel instrument panel
Panel grouping together the digital indicator, the multifunction screen and the vehicle operation
indicator lamps.
1.Rev counter.Indicates the speed of rotation of the
engine (x 1000 rpm). 2. Rev counter zone indicating that you must change up a gear. 3.Speed limiteror

Cruise control.(mph or km/h)
4.Electric child lock indicator lamp.Indicates, for a few seconds, the activation
of the electric child lock (deactivation of the rear windows and doors).
Tr a n s l u c e n t d igital instrument panel
This screen groups together the warning and
information messages.

Multifunction screen

Indicator lamps display zone
This zone groups together the vehicle operation indicator lamps.


Display zero reset button

This permits resetting of the function selected
to zero (trip distance recorder or ser vice
indicator).

Instrument panel lighting button

This adjusts the brightness of the lighting of theinstruments and controls. 5
.Fuel level. Indicates the quantity of fuel remaining in
the tank.
6.Vehicle speed. Indicates the current speed of the moving
vehicle (mph or km/h).
7.Trip distance recorder. (miles or km) 8. Ser vice indicator.
(miles or km) then, Distance recorder. (miles or km) 9.Engine oil level indicator.


For more information, refer to the paragraph relating to the button or function and its associated display.

Comfort
48








Vent ilat ion
The incoming air follows various routesdepending on the controls selected by thedriver:
- direct arrival in the passenger compartment (air intake),
- passage through a heating circuit (heating),
- passage through a cooling circuit (air conditioning).
The temperature control enables you to obtain
the level of comfor t required by mixing the air of
the various circuits.
The air distribution control enables you to
di
ffuse the air in the passenger compar tment combining several air vents.
The air flow control enables you to increase or reduce the speed of the ventilation fan.
Air intake
The air circulating in the passenger compartment
is filtered and originates either from the outside
via the grille located at the base of the windscreen or from the inside in air recirculation mode.


Control panel

The controls of this system are grouped
together on control panel Aon the centre console. Depending on the model, the functionsoffered are:


- the level of comfor t required,

- air flow
,

- air distribution
,

- demisting and defrosting,

- manual or digital air conditioning controls.



Air distribution
1.
Windscreen demisting or defrosting vents. 2.Front side window demisting or defrostingvents.3.Side adjustable air vents. 4.
Central adjustable air vents.
5. Air outlets to the front footwells.
6.Air outlets to the rear footwells.
S
ystem which creates and maintainscomfortable conditions in the vehicle'spassenger compartment.

3
Comfort
51
Footwells.
Central and side vents.
The air distribution can be adapted by placing the dial in anintermediate position.
2. Air fl ow adjustment
)Turn the dial from position 1to position 5
to obtain a comfortable air flow. Windscreen, side windows and
footwells.
) Turn the dial from blue(cold) to red (hot) to adjust
the temperature to your
requirements.
Windscreen and side windows.

1. Temperature adjustment
The heating / ventilation or air conditioning systems can only operate with the engine running.


3. Air distribution adjustment

Heating / Ventilation Manual air
conditioning
)If you place the air flow controlin position 0(deactivation of thesystem), the temperature is no longer maintained at a comfortablelevel. However, a slight flow of air, due to the movement of the vehicle,can still be felt.

Comfort
52
4. Air intake / Air recirculation
The intake of exterior air prevents the formationof mist on the windscreen and side windows.
The recirculation of interior air isolates the passenger compar tment from exterior odours and smoke. Return to exterior air intake as soon as possible
to prevent deterioration of the the air quality and the formation of mist.
)Press the button to recirculate
the interior air. The indicator
lamp comes on to confirm this.
)Press the button again to permit the intake
of exterior air. The indicator lamp switches
off to confirm this.


5. Air conditioning On / Off
It enables you to:


- lower the temperature, in summer,

- increase the effectiveness of the demistingin winter, above 3 °C.


Switching off
)
Press the "A/C"button again, the button's
indicator lamp goes off.
Switching off may affect comfort levels(humidity, condensation).
The air conditioning is designed to
operate effectively in all seasons,
with the windows closed.

Switching on
)
Press the "A/C"button, the button's
indicator lamp comes on.

The air conditioning does not operate when the
air flow adjustment control 2 is in position " 0". To obtain cooled air more quickly, you can use recirculation of interior air for a few moments.Then return to fresh air intake.

3
Comfort
53
The air conditioning only operates when the engine is running.
The driver and
front passenger can
each adjust the temperature to their
requirements.
)Turn control 2 or 3
to the left or to the right respectively to decrease or increase this value.
A setting around the value 21 provides
optimum comfor t. However, depending on your requirements, a setting between 18 and 24 isnormal.
You are advised to avoid a left / right settingdifference of more than 3.
Automatic operation
)Press the "AUTO"button. The indicator lamp in the button comes on.
2. Driver's side adjustment






Dual-zone digital air conditioning
We recommend the use of this mode: it permitsautomatic and optimised adjustment of all
of the functions, passenger compartment
temperature, air flow, air distribution and air
recirculation, in accordance with the comfort
value that you have chosen.
This system is designed to operate effectively in all seasons, with the windows closed. The value indicated on the displa
y corresponds
to a level of comfor t and not to a temperature in
de
grees Celsius or Fahrenheit.
1. Automatic comfort programme
3. Passen
ger's side adjustment
On entering the vehicle, if the interior temperature is much colder or warmer than the comfort value, there is noneed to change the value displayed in order to obtain the comfort required. The system corrects the difference in temperature automatically and asquickly as possible.
When the engine is cold, to prevent too great a distribution of cold air, the air flow will reach its optimum levelgradually. In cold weather, it favours the distribution of warm air to thewindscreen, side windows and footwells only.
