Citroen C3 2013 2.G Owners Manual 9
Driving
123

Manual operation
�)Select position M
for sequential
changing
of the four gears. �)Push the lever towards the + sign to change up a gear.�)Pull the lever towards the -
sign

9
Driving
123

Manual operation
)Select position M
for sequential
changing
of the four gears. )Push the lever towards the + sign to change up a gear.)Pull the lever towards the -
sign to changedown a gear.
It is onl
y possible to change from one gear to
another if the vehicle speed and engine speedpermit; otherwise, the gearbox will operate
temporarily in automatic mode.
D disappears and the gears
engaged appear in succession in theinstrument panel.
Invalid value during manual
operation
This symbol is displayed if a gear
is not engaged correctly (selector
between two positions).

Stopping the vehicle
Before switching off the engine, you can engageposition Por Nto place the gearbox in neutral. In both cases, apply the parking brake to immobilise the vehicle.

Operating fault
When the ignition is on, the lighting
of this warning lamp, accompaniedby an audible signal and a message in the
multifunction screen, indicates a gearbox fault.
In this case, the gearbox switches to back-up
mode and is locked in 3rd gear. You may feel
a substantial knock when changing from Pto R
and from N
to R
. This will not cause any
damage to the gearbox.
Do not exceed 60 mph (10 0 km/h), local speed
restrictions permitting.
Contact a CITROËN dealer or a qualified
workshop as soon as possible.
To r e d u c e fuel consumption when at a prolonged standstill with the enginerunning (traffic jam...), put the gear lever in the Nposition and apply the parkingbrake.

There is a risk of damage to thegearbox:

- if you press the accelerator and brake pedals at the same time,

- if you force the movement of the gear lever from the Pposition to another position when the battery is flat.
If the lever is not in position P, when the Pdriver's door is opened or approximately 45 seconds after the ignition is switchedoff, a warning message appears in the screen.)Return the lever to position P
; the
message disappears.

If the en
gine speed is too low or too high, the gear selected flashes for a few seconds, then
the actual gear engaged is displayed.
It is possible to change from position D(automatic) to position M
(manual) at any time.
When the vehicle is stationary or moving
very slowly, the gearbox selects gear M1automatically.
The spor t and snow programmes do not
operate in manual mode.
