2013 Acura ZDX tailgate

Continued
173
uuBefore DrivinguDriving Preparation
Driving
•Store or secure all items on board properly.
uCarrying too much cargo, or improperly storing it, can affect your vehicle’s
handling, stability, stopping distance, and tires, and make it unsafe.
2Maximum Load Limit P. 175
•Do not pile items higher than the seat height.
uThey can block your view and may be thrown forward in the event of sudden
braking.
•Do not place anything in the front seat footwells. Make sure to secure the floor
mat.
uAn object or unsecured floor mat can interfere with your brake and accelerator
pedal operation while driving.
•If you have any animals on board, do not let them move around in the vehicle.
uThey may interfere with driving and a crash could occur.
•Securely close and lock all doors and the tailgate.
2Locking/Unlocking the Doors from the Inside P. 113
•Adjust your seating position properly.
uAdjust the head restraint, too.
2Adjusting the Seats P. 144
2Adjusting the Head Restraints P. 146
•Adjust the mirrors and steering wheel properly for your driving.
uAdjust them while sitting in the proper driving position.
2Adjusting the Mirrors P. 142
2Adjusting the Steering Wheel P. 141
■Interior Checks
1Interior Checks
The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the cargo area or tow a trailer, have
the aiming readjusted at a dealer or by a qualified
technician.

275
Handling the Unexpected
This chapter explains how to handle unexpected troubles.
Tools
Types of Tools .................................. 276
If a Tire Goes Flat
Changing a Flat Tire ......................... 277
Engine Does Not Start
Checking the Engine ........................ 284If the Keyless Access Remote Battery is
Weak ..........................................285Emergency Engine Stop ................... 286
Jump Starting.................................... 287
Shift Lever Does Not Move.............. 289Overheating
How to Handle Overheating............. 290
Indicator, Coming On/Blinking
If the Low Oil Pressure Indicator Comes
On ............................................. 292If the Charging System Indicator Comes
On ................................................. 292
If the Malfunction Indicator Lamp Comes
On or Blinks ................................... 293If the Brake System Indicator (Red)
Comes On .................................. 294
If the Low Tire Pressure/TPMS Indicator
Comes On or Blinks ....................... 294
Fuses
Fuse Locations ................................. 295Circuit Protected and Amps for Each
Fuse............................................ 297Inspecting and Changing Fuses ........ 300
Emergency Towing........................... 301
When You Cannot Unlock the Fuel Fill
Door................................................. 302
When You Cannot Open or Close the
Tailgate............................................ 303

298
uuFusesuCircuit Protected and Amps for Each Fuse
Handling the Unexpected
■Secondary Engine
Compartment
Circuits Protected
Amps.
1
VSA Motor
40 A
2
VSA FSR
20 A
3
−
−
4
−
−
5
SH-AWD
30 A
6
Power Tailgate Motor
40 A
7
Tilt Steering Wheel
20 A
8
Telescopic Steering Wheel
20 A
9
Hazard
15 A
10
Headlight Hi/Lo Solenoid
7.5 A
11
Power Management System
7.5 A
12
Keyless Access System
7.5 A
13
Rear Seat Heaters
20 A
14
Sunshade
20 A
15
Power Tailgate Closer
20 A
16
−
−
17
−
−
18
−
−
19
−
−
20
−
−
21
−
−
22
−
−
■Driver Side Interior
Circuits Protected
Amps.
1
Front Seat Heaters and Seat
Ventilation/Blind Spot
Information
(7.5 A)
2
SH-AWD/Headlight
Adjuster
7.5 A
3
Washer
20 A
4
Wiper
7.5 A
5
OPDS
7.5 A
6
VSA
7.5 A
7
−
−
8
STRLD
7.5 A
9
Fuel Pump
20 A
10
VB Solenoid
10 A
11
SRS
10 A
12
Meter
7.5 A
13
ACG
15 A
14
−
−
15
Daytime Running Lights
7.5 A
16
Climate Control System
7.5 A
17
−
(7.5 A)
18
Accessory
7.5 A
19
Left Power Seat Slide
20 A
20
Panoramic Glass Roof
20 A
21
Left Power Seat Reclining
20 A
22
Rear Left Power Window
20 A
23
Accessory Power Socket
(Console Box)
15 A
24
Left Front Power Window
20 A
25
Left Door Lock
15 A
26
Left Front Fog Light
10 A
27
Left Small Light (Exterior)
10 A
28
Left Daytime Running Light
10 A
29
TPMS
7.5 A
30
Left Headlight
15 A
31
−
−
32
STS
*
7.5 A
Circuits Protected
Amps.
* Not available on all models

302Handling the Unexpected
When You Cannot Unlock the Fuel Fill DoorIf you cannot unlock the fuel fill door, use the following procedure.
1.Open the tailgate and remove the side
storage compartment.
2.Remove the cover and pull the release level
towards you.
uThe release lever unlocks the fuel fill door
when it is pulled.■What to Do When Unable to Unlock the Fuel Fill Door
1What to Do When Unable to Unlock the Fuel Fill Door
After taking these steps, contact a dealer to have the
vehicle checked.
Side storage compartmentCoverRelease Lever

303Handling the Unexpected
When You Cannot Open or Close the TailgateIf you cannot open or close the tailgate, use the following procedure.
1.Use a flat-tip screwdriver and remove the
cover on the back of the tailgate.
2.To open the tailgate, push the tailgate
while pushing the lever to the right.■When You Cannot Open or Close the Tailgate
1When You Cannot Open or Close the Tailgate
What to do-Following up
After taking these steps, contact a dealer to have the
vehicle checked.
When you open the tailgate from inside, make sure
there is enough space around the tailgate, and it
does not hit anyone or any object.
Cover
Lever

317Index
Bulb Specifications................................... 306CCarbon Monoxide Gas............................... 63
Cargo Hooks............................................. 159
Carrying Cargo................................. 173, 175
Certification Label................................... 307
Changing Bulbs........................................ 249
Charging System Indicator................ 67, 292
Child Safety................................................ 49
Childproof Door Locks ............................ 114
Child Seat................................................... 49
Booster Seats ............................................ 62
Child Seat for Infants ................................ 51
Child Seat for Small Children .................... 52
Installing a Child Seat with a Lap/
Shoulder Seat Belt ................................... 57
Larger Children ......................................... 61
Rear-facing Child Seat............................... 51
Selecting a Child Seat ............................... 53
Using a Tether .......................................... 59
Childproof Door Locks............................. 114
Cleaning the Exterior............................... 272
Cleaning the Interior............................... 270
Client Service Information....................... 315
Climate Control System........................... 163
Changing the Mode................................ 163
Defrosting the Windshield and
Windows .............................................. 164
Dust and Pollen Filter .............................. 269Recirculation/Fresh Air Mode ................... 163
Sensor ..................................................... 166
Synchronized Mode ................................. 165
Using Automatic Climate Control ............ 163
Clock.............................................................. 9
Coat Hook................................................. 159
Compact Spare Tire.......................... 277, 306
Console Compartment............................. 155
Controls..................................................... 105
Coolant (Engine)....................................... 243
Adding to the Radiator ............................ 244
Adding to the Reserve Tank ..................... 243
Overheating ............................................ 290
Temperature Gauge .................................. 86
Creeping.................................................... 188
Cruise Control........................................... 193
Indicator .................................................... 75
Cup Holders.............................................. 157
Customized Features.................................. 92
DDaytime Running Lights........................... 134
Dead Battery............................................. 287
Devices that Emit Radio Waves............... 308
Dimming
Headlights ............................................... 132
Rearview Mirror ....................................... 142
Dipstick (Engine Oil)................................. 239
Directional Signals (Turn Signal)............. 132
Door Mirrors............................................. 143Doors......................................................... 106
Auto Door Locking .................................. 115
Auto Door Unlocking .............................. 115
Door and Tailgate Open Indicator ........ 26, 71
Keys ........................................................ 106
Locking/Unlocking the Doors
from the Inside ...................................... 113
Locking/Unlocking the Doors
from the Outside ................................... 108
Lockout Prevention System ...................... 111
DOT Tire Quality Grading........................ 261
Driving...................................................... 171
Automatic Transmission .......................... 188
Braking ................................................... 212
Cruise Control ......................................... 193
Shifting Gear ........................................... 189
Starting the Engine.................................. 185
Driving Position Memory System............ 139
Dust and Pollen Filter............................... 269
EElapsed Time............................................... 90
Electronic Stability Control (ESC)............. 202
Emergency................................................ 301
Emissions Testing (Readiness Codes)....... 310
Engine....................................................... 307
Coolant ................................................... 243
Jump Starting .......................................... 287
Oil ........................................................... 238
Starting ................................................... 185

319Index
ABS (Anti-lock Brake System) .................... 70
BSI (Blind Spot Information) ...................... 76
Charging System............................... 67, 292
CRUISE CONTROL ............................. 75, 194
CRUISE MAIN.................................... 75, 193
Door and Tailgate Open ...................... 26, 71
Fog Light .................................................. 73
Forward Collision Warning (FCW) ............. 77
High-Beam................................................ 73
Immobilizer System ................................... 74
Keyless Access System............................... 75
Lane Departure Warning (LDW) ................ 78
Lights On .................................................. 73
Low Fuel ................................................... 69
Low Oil Pressure ............................... 66, 292
Low Tire Pressure/TPMS ............ 72, 208, 210
Malfunction Indicator Lamp .............. 67, 293
Parking Brake and Brake System ....... 66, 294
Seat Belt Reminder.............................. 28, 69
Security System Alarm............................... 75
SH-AWD®......................................... 76, 204
Shift Position............................................. 68
Side Airbag Off ................................... 47, 74
Supplemental Restraint System ........... 45, 70
System Message ....................................... 72
Transmission ............................................. 68
Turn Signal ............................................... 73
VSA® (Vehicle Stability Assist)
System ............................................ 71, 202
VSA® OFF.......................................... 71, 203
Information.............................................. 305Information Buttons................................... 87
Instant Fuel Economy................................. 90
Instrument Panel........................................ 65
Brightness Control ................................... 137
Interior Lights........................................... 152
Interior Rearview Mirror.......................... 142
JJack (Wheel Nut Wrench)........................ 281
Jump Starting........................................... 287KKey Number Tag....................................... 107
Keyless Access System............................... 109
Keyless Lockout Prevention..................... 111
Keys........................................................... 106
Lockout Prevention .................................. 111
Number Tag ............................................ 107
Rear Door Won’t Open ............................ 114
Remote Transmitter ................................. 108
Types and Functions ................................ 106
Kickdown.................................................. 188
LLane Departure Warning (LDW)............. 199
LATCH (Child Seats).................................... 54
Lights................................................. 132, 249
Automatic ............................................... 133
Bulb Replacement ................................... 249
Daytime Running Lights........................... 134
Fog Lights ............................................... 134
High-Beam Indicator.................................. 73
Interior .................................................... 152
Light Switches ......................................... 132
Lights On Indicator .................................... 73
Turn Signals ............................................ 132
Load Limits................................................ 175
Locking/Unlocking.................................... 106
Auto Door Locking/Unlocking.................. 115
Childproof Door Locks............................. 114
From Inside ............................................. 113
From Outside .......................................... 108
Keys ........................................................ 106
Using a Key ..................................... 109, 111
Lockout Prevention System..................... 111
Low Battery Charge................................. 292
Low Fuel Indicator...................................... 69
Low Oil Pressure Indicator................. 66, 292
Lower Anchors............................................ 54
Luggage (Maximum Load Limit)............. 175

320Index
MMaintenance............................................. 227
Battery..................................................... 267
Brake ....................................................... 246
Cleaning .................................................. 270
Climate Control ....................................... 269
Coolant ................................................... 243
Maintenance Minder
TM............................ 231
Oil ........................................................... 239
Precautions .............................................. 228
Radiator................................................... 244
Remote Transmitter ................................. 268
Replacing Light Bulbs ............................... 249
Safety ...................................................... 229
Service Items............................................ 233
Tires ........................................................ 258
Transmission Fluid.................................... 245
Under the Hood....................................... 235
Malfunction Indicator Lamp.............. 67, 293
Map Lights................................................ 153
Maximum Load Limit................................ 175
Meters, Gauges........................................... 86
Mirrors....................................................... 142
Adjusting ................................................. 142
Door ........................................................ 143
Exterior .................................................... 143
Interior Rearview...................................... 142
Modifications (and Accessories)............... 225
Multi-Information Display.......................... 87
NNumbers (Identification).......................... 307OOdometer................................................... 88
Oil (Engine)............................................... 238
Adding .................................................... 240
Checking................................................. 239
Displaying Oil Life .................................... 231
Low Oil Pressure Indicator ................. 66, 292
Recommended Engine Oil ....................... 238
Viscosity .................................................. 238
Opening/Closing
Hood....................................................... 236
Panoramic Glass Roof .............................. 128
Power Windows ...................................... 125
Tailgate ........................................... 116, 303
Outside Temperature Display.................... 89
Overheating.............................................. 290PPaddle Shifters (Sequential Shift
Mode)...................................................... 191
Panic Mode............................................... 124
Panoramic Glass Roof............................... 128
Parking...................................................... 216
Parking Brake........................................... 212
Parking Brake and Brake System
Indicator............................................ 66, 294Parking Sensor System............................. 217
Passenger Airbag Off Indicator................. 46
Passing Indicators..................................... 132
Power Windows....................................... 125
Precautions While Driving....................... 187
Rain ........................................................ 187
Pregnant Women....................................... 32
Puncture (Tire)......................................... 277
RRadiator.................................................... 244
Range.......................................................... 90
Readiness Codes (Emissions Testing)...... 310
Rear Defogger/Heated Door Mirror
Button..................................................... 138
Rear Seat Heaters..................................... 162
Rear Seats (Folding Down)...................... 150
Rearview Mirror....................................... 142
Rearview Mirror with Rearview Camera
Display.................................................... 220
Refueling.................................................. 221
Fuel Gauge ............................................... 86
Gasoline ......................................... 221, 306
Low Fuel Indicator..................................... 69
Regulations.............................. 210, 261, 308
Remote Transmitter................................. 108
