uuChild SafetyuSafety of Infants and Small Children
Safe Driving
■Using the center anchor
1.Lower the head restraint.
2.Route the tether strap over the head
restraint and seat-back.
Make sure the strap is not twisted.
3.Secure the tether strap hook onto the
anchor.
4.Tighten the tether strap as instructed by the
child seat manufacturer.
Anchor
Tether
Strap
Hook
Center Position

61
uuChild SafetyuSafety of Larger Children
Continued
Safe Driving
Safety of Larger ChildrenThe following pages give instructions on how to check proper seat belt fit, what kind
of booster seat to use if one is needed, and important precautions for a child who
must sit in front.
When a child is too big for a child seat, secure the child in a rear seat using the lap/shoulder
seat belt. Have the child sit upright and all the way back, then answer the following
questions.
■Checklist
•Do the child’s knees bend comfortably over
the edge of the seat?
•Does the shoulder belt cross between the
child’s neck and arm?
•Is the lap part of the seat belt as low as
possible, touching the child’s thighs?
•Will the child be able to stay seated like this
for the whole trip?
If you answer yes to all these questions, the child is ready to wear the lap/shoulder
seat belt correctly. If you answer no to any question, the child needs to ride on a
booster seat until the seat belt fits properly without a booster seat.
■Protecting Larger Children■Checking Seat Belt Fit
1Safety of Larger Children
3
WARNING
Allowing a child age 12 or under to sit in
front can result in injury or death if the
passenger’s front airbag inflates.
If a larger child must ride in front, move the
vehicle seat as far to the rear as possible,
have the child sit up properly and wear the
seat belt properly, using a booster seat if
needed.

uuChild SafetyuSafety of Larger Children
62Safe Driving
If a lap/shoulder seat belt cannot be used
properly, position the child in a booster seat in
a rear seating position. For the child’s safety,
check that the child meets the booster seat
manufacturer’s recommendations.
Your vehicle has a rear seat where children can be properly restrained. If you ever
have to carry a group of children, and a child must ride in front:
•Make sure you read and fully understand the instructions and safety information
in this manual.
•Move the front passenger seat as far back as possible.
•Have the child sit upright and well back in the seat.
•Check that the seat belt is properly positioned so that the child is secure in the
seat.
■Monitoring child passengers
We strongly recommend that you keep an eye on child passengers. Even older, more
mature children sometimes need to be reminded to fasten their seat belts and sit up
properly.■Booster Seats
1Booster Seats
When installing a booster seat, make sure to read the
instructions that came with it, and install the seat
accordingly.
There are high- and low-type booster seats. Choose a
booster seat that allows the child to wear the seat
belt correctly.
Some U.S. states and Canadian provinces and
territories require children to use a booster seat until
they reach a given age or weight (e.g. 6 years or 60
lbs). Be sure to check current laws in the state or
province, or territory where you intend to drive.
■Protecting Larger Children-Final Checks

105
Controls
This chapter explains how to operate the various controls necessary for driving.
Locking and Unlocking the Doors
Key Types and Functions .................. 106
Locking/Unlocking the Doors from the
Outside .......................................... 108Low Keyless Access Remote Signal
Strength ........................................ 112Locking/Unlocking the Doors from the
Inside ............................................. 113
Childproof Door Locks ..................... 114
Auto Door Locking/Unlocking .......... 115
Opening and Closing the Tailgate... 116
Security System................................ 122Opening and Closing the Windows..... 125
Opening and Closing the Panoramic
Glass Roof........................................ 128
Operating the Switches Around the
Steering Wheel
ENGINE START/STOP Button............. 129
Turn Signals ..................................... 132
Light Switches.................................. 132
Fog Lights ........................................ 134
Daytime Running Lights ................... 134
Wipers and Washers ........................ 135
Brightness Control ........................... 137Rear Defogger/Heated Door Mirror
Button........................................ 138Driving Position Memory System ...... 139Adjusting the Steering Wheel .......... 141
Adjusting the Mirrors....................... 142
Adjusting the Seats.......................... 144
Interior Lights/Interior Convenience
Items
Interior Lights .................................. 152
Interior Convenience Items .............. 154
Climate Control System
Using Automatic Climate Control .... 163
Synchronized Mode ......................... 165
Automatic Climate Control Sensors ...... 166

125
Continued
Controls
Opening and Closing the WindowsOpening/Closing the Power WindowsThe power windows can be opened and closed when the power mode is in ON,
using the switches on the doors. The driver side switches can be used to open and
close all of the windows.
The power window lock button on the driver side must be switched off (not pushed
in, indicator off) to open and close the windows from anywhere other than the
driver’s seat.
When the power window lock button is pushed in, the indicator comes on and you
can only operate the driver’s window. Turn the power window lock button on when
children are in the vehicle.
■Automatic operation
To open: Push the switch down firmly.
To close: Pull the switch up firmly.
The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.■Manual operation
To open: Push the switch down lightly.
To close: Pull the switch up lightly.
Release the switch when the window reaches
the desired position.
■Opening/Closing Windows with Auto-Open/Close Function
1Opening/Closing the Power Windows
The power windows can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF.
Opening either front door cancels this function.
Auto Reverse
If a power window senses resistance when closing
automatically, it will stop closing and reverse
direction.
The driver’s window auto reverse function is disabled
when you continuously pull up the switch.
The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.
3
WARNING
Closing a power window on someone’s
hands or fingers can cause serious injury.
Make sure your passengers are away from
the windows before closing them.
ON
OFF
Power Window
Lock Button
Indicator
Driver’s
Window
SwitchFront Passenger’s
Window Switch

Index
316Index
Index
AABS (Anti-lock Brake System)................... 214
Accessories and Modifications................. 225
Accessory Power Sockets.......................... 158
Active Head Restraints............................. 149
Additives
Coolant ................................................... 243
Engine Oil ................................................ 238
Washer .................................................... 248
Additives, Engine Oil................................ 238
Adjusting
Armrest ................................................... 151
Front Seats .............................................. 144
Head Restraints........................................ 146
Mirrors .................................................... 142
Rear Seats................................................ 150
Steering Wheel ........................................ 141
Temperature .............................................. 89
Air Conditioning System (Climate Control
System).................................................... 163
Changing the Mode ................................ 163
Defrosting the Windshield and
Windows ............................................... 164
Dust and Pollen Filter ............................... 269
Recirculation/Fresh Air Mode ................... 163
Sensor ..................................................... 166
Synchronized Mode ................................. 165
Using Automatic Climate Control ............ 163
Air Pressure....................................... 259, 306Airbags........................................................ 34
Advanced Airbags ..................................... 40
After a Collision ........................................ 38
Airbag Care............................................... 48
Event Data Recorder .................................. 18
Front Airbags (SRS) .................................... 37
Indicator........................................ 45, 70, 74
Passenger Airbag Off Indicator .................. 46
Sensors ..................................................... 34
Side Airbag Cutoff System......................... 43
Side Airbag Off Indicator ........................... 47
Side Airbags .............................................. 41
Side Curtain Airbags.................................. 44
Anti-lock Brake System (ABS).................. 214
Indicator.................................................... 70
Armrest..................................................... 151
Audio System............................................ 168
Authorized Manuals................................ 314
Auto Door Locking/Unlocking................. 115
Automatic Lighting.................................. 133
Automatic Transmission........................... 188
Creeping ................................................. 188
Fluid ........................................................ 245
Kickdown ................................................ 188
Operating the Shift Lever........... 12, 190, 192
Sequential Shift Mode ............................. 191
Shift Lever Does Not Move ...................... 289
Shifting ................................................... 189
Average Fuel Economy.............................. 89
Average Speed........................................... 90
BBattery...................................................... 267
Charging System Indicator ................ 67, 292
Jump Starting ......................................... 287
Maintenance (Checking the Battery) ....... 267
Maintenance (Replacing) ......................... 268
Belts (Seat).................................................. 27
Beverage Holders..................................... 157
Blind Spot Information (BSI)................... 205
Booster Seats (For Children)...................... 62
Brake System............................................ 212
Anti-lock Brake System (ABS) .................. 214
Brake Assist System................................. 215
Fluid ....................................................... 246
Foot Brake .............................................. 213
Indicator ........................................... 66, 294
Parking Brake.......................................... 212
Brightness Control (Instrument Panel)... 137
Bulb Replacement.................................... 249
Back-Up Lights ........................................ 254
Daytime Running Light............................ 252
Fog Lights ............................................... 250
Front Side Marker Lights ......................... 251
Front Turn Signal/Parking Lights .............. 251
Headlights .............................................. 249
High-Mount Brake Light.......................... 255
Rear License Plate Light ........................... 255
Side Turn Signal/
Emergency Indicator Lights.................... 252
Stop Light, Taillight, Rear Turn Signal Light and
Rear Side Marker Lights......................... 253

317Index
Bulb Specifications................................... 306CCarbon Monoxide Gas............................... 63
Cargo Hooks............................................. 159
Carrying Cargo................................. 173, 175
Certification Label................................... 307
Changing Bulbs........................................ 249
Charging System Indicator................ 67, 292
Child Safety................................................ 49
Childproof Door Locks ............................ 114
Child Seat................................................... 49
Booster Seats ............................................ 62
Child Seat for Infants ................................ 51
Child Seat for Small Children .................... 52
Installing a Child Seat with a Lap/
Shoulder Seat Belt ................................... 57
Larger Children ......................................... 61
Rear-facing Child Seat............................... 51
Selecting a Child Seat ............................... 53
Using a Tether .......................................... 59
Childproof Door Locks............................. 114
Cleaning the Exterior............................... 272
Cleaning the Interior............................... 270
Client Service Information....................... 315
Climate Control System........................... 163
Changing the Mode................................ 163
Defrosting the Windshield and
Windows .............................................. 164
Dust and Pollen Filter .............................. 269Recirculation/Fresh Air Mode ................... 163
Sensor ..................................................... 166
Synchronized Mode ................................. 165
Using Automatic Climate Control ............ 163
Clock.............................................................. 9
Coat Hook................................................. 159
Compact Spare Tire.......................... 277, 306
Console Compartment............................. 155
Controls..................................................... 105
Coolant (Engine)....................................... 243
Adding to the Radiator ............................ 244
Adding to the Reserve Tank ..................... 243
Overheating ............................................ 290
Temperature Gauge .................................. 86
Creeping.................................................... 188
Cruise Control........................................... 193
Indicator .................................................... 75
Cup Holders.............................................. 157
Customized Features.................................. 92
DDaytime Running Lights........................... 134
Dead Battery............................................. 287
Devices that Emit Radio Waves............... 308
Dimming
Headlights ............................................... 132
Rearview Mirror ....................................... 142
Dipstick (Engine Oil)................................. 239
Directional Signals (Turn Signal)............. 132
Door Mirrors............................................. 143Doors......................................................... 106
Auto Door Locking .................................. 115
Auto Door Unlocking .............................. 115
Door and Tailgate Open Indicator ........ 26, 71
Keys ........................................................ 106
Locking/Unlocking the Doors
from the Inside ...................................... 113
Locking/Unlocking the Doors
from the Outside ................................... 108
Lockout Prevention System ...................... 111
DOT Tire Quality Grading........................ 261
Driving...................................................... 171
Automatic Transmission .......................... 188
Braking ................................................... 212
Cruise Control ......................................... 193
Shifting Gear ........................................... 189
Starting the Engine.................................. 185
Driving Position Memory System............ 139
Dust and Pollen Filter............................... 269
EElapsed Time............................................... 90
Electronic Stability Control (ESC)............. 202
Emergency................................................ 301
Emissions Testing (Readiness Codes)....... 310
Engine....................................................... 307
Coolant ................................................... 243
Jump Starting .......................................... 287
Oil ........................................................... 238
Starting ................................................... 185

319Index
ABS (Anti-lock Brake System) .................... 70
BSI (Blind Spot Information) ...................... 76
Charging System............................... 67, 292
CRUISE CONTROL ............................. 75, 194
CRUISE MAIN.................................... 75, 193
Door and Tailgate Open ...................... 26, 71
Fog Light .................................................. 73
Forward Collision Warning (FCW) ............. 77
High-Beam................................................ 73
Immobilizer System ................................... 74
Keyless Access System............................... 75
Lane Departure Warning (LDW) ................ 78
Lights On .................................................. 73
Low Fuel ................................................... 69
Low Oil Pressure ............................... 66, 292
Low Tire Pressure/TPMS ............ 72, 208, 210
Malfunction Indicator Lamp .............. 67, 293
Parking Brake and Brake System ....... 66, 294
Seat Belt Reminder.............................. 28, 69
Security System Alarm............................... 75
SH-AWD®......................................... 76, 204
Shift Position............................................. 68
Side Airbag Off ................................... 47, 74
Supplemental Restraint System ........... 45, 70
System Message ....................................... 72
Transmission ............................................. 68
Turn Signal ............................................... 73
VSA® (Vehicle Stability Assist)
System ............................................ 71, 202
VSA® OFF.......................................... 71, 203
Information.............................................. 305Information Buttons................................... 87
Instant Fuel Economy................................. 90
Instrument Panel........................................ 65
Brightness Control ................................... 137
Interior Lights........................................... 152
Interior Rearview Mirror.......................... 142
JJack (Wheel Nut Wrench)........................ 281
Jump Starting........................................... 287KKey Number Tag....................................... 107
Keyless Access System............................... 109
Keyless Lockout Prevention..................... 111
Keys........................................................... 106
Lockout Prevention .................................. 111
Number Tag ............................................ 107
Rear Door Won’t Open ............................ 114
Remote Transmitter ................................. 108
Types and Functions ................................ 106
Kickdown.................................................. 188
LLane Departure Warning (LDW)............. 199
LATCH (Child Seats).................................... 54
Lights................................................. 132, 249
Automatic ............................................... 133
Bulb Replacement ................................... 249
Daytime Running Lights........................... 134
Fog Lights ............................................... 134
High-Beam Indicator.................................. 73
Interior .................................................... 152
Light Switches ......................................... 132
Lights On Indicator .................................... 73
Turn Signals ............................................ 132
Load Limits................................................ 175
Locking/Unlocking.................................... 106
Auto Door Locking/Unlocking.................. 115
Childproof Door Locks............................. 114
From Inside ............................................. 113
From Outside .......................................... 108
Keys ........................................................ 106
Using a Key ..................................... 109, 111
Lockout Prevention System..................... 111
Low Battery Charge................................. 292
Low Fuel Indicator...................................... 69
Low Oil Pressure Indicator................. 66, 292
Lower Anchors............................................ 54
Luggage (Maximum Load Limit)............. 175
