2013 Acura TL navigation system

CONT INUED
To replay and see the stored file,
press the AUDIO button to select
the audio display on the
navigation screen.
Push down the interf ace selector
to display the audio menu. Turn
the interface dial to select Note,
then press ENTER.
This f unction stores the sound
content played on the selected XM
Radio station with the channel,
category, name, and title inf ormation.
To activate this function, press and
hold the button for about 2
seconds while a song or passage
which you want to store is playing.
You can record f or up to 10 seconds.
To stop recording, press the AM/
FM button or button.
Once you store the recorded sound
f ile, you can replay it and conf irm the
inf ormation. The system can store
up to 30 sound f iles. If you continue
tostoremorefiles,theoldestone
will be deleted each time you add a
new f ile.
There may be other geographic
situations that could affect
XM Radio reception.
This device complies with the
appropriate requirements or the
required standards. See page f or
more inf ormation.
628
U.S. models only
Playing the XMRadio (Models with navigation system)
Note Function
Features
305
NOTE ICON
12/07/20 11:08:48 31TK4640_310
2013 TL

´
Turn the selector dial to select a
sound file, then press ENTER. The
display shows the category, name
and title information of the
selected file.
To delete all f iles, push the interf ace
selector to the lef t to select
‘‘DELETE ALL,’’ then press ENTER.
To delete one f ile, select the f ile you
want to delete and push the interf ace
selector to the right, then press
ENTER. If your XM Radio service has expired
or you purchased your vehicle f rom
a previous owner, you can listen to a
sampling of the broadcasts available
on XM Radio. With the power mode
in ACCESSORY or ON, press the
button. A variety of music
types and styles will play.
Your vehicle has the engine start/
stop button instead of an ignition
switch. For more information on how
to select the power mode, see
page . After you have registered with XM
Radio, keep your audio system in the
XM Radio mode while you wait for
activation. This should take about
While waiting for activation, make
sure your vehicle remains in an open
area with good reception. Once your
audio system is activated, CAT
(category) or CH (channel) will
appear in the center display, and
you’ll be able to listen to XM Radio
broadcasts. XM Radio will continue
to send an activation signal to your
vehicle for at least 12 hours from the
activation request. If the service has
not been activated after 36 hours,
contact XM
Radio. In Canada,
contact XM CANADA
.
If you decide to purchase XM radio
service, contact XM Radio at
,orat
1-800-852-9696. In Canada, contact
XM CANADA
at , or
at 1-877-209-0079. You will need to
give them your radio I.D. number
and your credit card number. To get
your radio I.D. number, press the
side of the CATEGORY bar until ‘‘0’’ appears in the display. Your I.D. will
appear in the displays.
184
www.siriusxm.com www.xmradio.ca
Playing the XMRadio (Models with navigation system)
Receiving XM Radio Service
306
SOUND FILE RECORDED DATE
12/07/20 11:08:57 31TK4640_311
Features30 min ute s.
2013 TL

CONT INUED
Playing a Disc (Models with navigation system)
Features
307
INTERFACE DIALSCAN/A.SEL
(SCAN/AUTO SELECT) BAR SKIP BAR NAVIGATION SCREEN
DISC SLOT
EJECT BUTTON
TITLE BUTTON
PRESET BUTTONS
CATEGORY BAR
AUDIO BUTTON VOL/
(VOLUME/POWER)KNOB
DISC BUTTON
CENTER DISPLAY
12/07/20 11:09:03 31TK4640_312
2013 TL

The disc packages or jackets should
have one of these marks.The disc player can also play MP3,
WMA, or AAC format that saved
on CD-R/RW or DVD-R/RW
(see page ).
If a f ile on WMA or AAC disc is
protected by digital rights
management (DRM), the audio
system skips to the next f ile.
DVD-A discs not meeting DVD
verification standards may not be
playable.
Video CDs and DVD-V format discs
will not work in this unit.
Some CD-DA and CD-ROM mixed
discs are not playable.
Your vehicle’s audio system has an
in-dash disc player. To operate the
disc player, the power mode must be
in the ACCESSORY or ON.
Your vehicle has the engine start/
stop button instead of an ignition
switch. For more information on
how to select the power mode, see
page
.
CD (CD-DA, CD-TEXT)
CD-R/CD-RW(MP3,WMA,AAC)
DVD-A
DVD-R/DVD-RW (MP3, WMA,
AAC)
The disc player can play these disc
formats:
184 313
Playing a Disc (Models with navigation system)
308
NOTE:
12/08/08 20:02:36 31TK4640_313
Features
2013 TL

You cannot load and play 3-inch
(8-cm)discsinthissystem.
It is possible to select up to 999 f iles
f or inclusion in CD-Rs and CD-RWs,
and up to 3,500 f iles f or inclusion in
DVD-Rs and DVD-RWs.Insert a disc about half way into the
disc slot. The drive will pull the disc
intherestof thewaytoplayit.You
operate the disc player with the
same controls used f or the radio.
The number of the current track is
showninthedisplay.Whenplayinga
disc in MP3, WMA or AAC, the
numbers of the current f older and
f ile are shown. The system will
continuously play a disc until you
change modes.
For information on how to handle
and protect compact discs, see
page
.
Manuf actured under license under
U.S. Patent’s: 5,451,942; 5,956,674;
5,974,380; 5,978,762; 6,487,535 &
other U.S. and worldwide patents
issued & pending. DTS and DTS
Digital Surround are registered
trademarks and the DTS logos and
Symbol are trademarks of DTS, Inc.
All Rights Reserved. Reverse
engineering or disassembly is
prohibited.
Depending on the sof tware the f iles
were made with, it may not be
possible to play some f iles, or display
some text data.
381
To Load a Disc
Playing a Disc (Models with navigation system)
Features
309
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
12/07/20 11:09:20 31TK4640_314
2013 TL

Select the disc player by pressing the
DISC button. The system will begin
playing the last selected track in the
disc. You will see the current track
position highlighted.
Title inf ormation will be displayed in
a list when the inf ormation is f ound
in the Gracenote
Album Inf o
(Gracenote
Media Database) on the
built-inharddiskdrive.Whenyou
play a CD recorded with text data,
you will see the genre, artist name,
album and track name on the screen.
When you play MP3/WMA/AAC
discs, you will see the genre, artist
name, album name and track name
on the screen. If the disc was not
recorded with this inf ormation, it will
not be displayed. Each time you press the TITLE
button, the center display changes
f rom artist name to album name, to
track name and then to normal
display that shows the track number
and the elapsed time. When playing
a disc in MP3/WMA/AAC, the
display mode changes f rom f older
name,tofilename,toartisttag,to
album tag, to track tag, and then to
normal display.
Each time you press and release the
side of the skip bar, the player
skips forward to the beginning of the
next track. Press and release the side of the skip bar to skip
backward to the beginning of the
current track. Press the side
againtoskiptotheprevioustrack.
To move rapidly within a track, press
andholdeithersideof theskipbar.
When you insert a CD f or the f irst
time, the system automatically starts
recording to the hard disc. For
inf ormation on recording f rom music
CDs, see page .
When you insert a CD f or the f irst
time, a Gracenote notif ication
appears. For more inf ormation, see
page . 322
351
To Play a Disc
To Change Tracks
Playing a Disc (Models with navigation system)
310
12/07/20 11:09:27 31TK4640_315
Features
2013 TL

You can also choose a track directly
from a track list. If there are no track
names, you will see ‘‘No Title’’
displayed. Turn the interf ace dial to
select the desired track, then press
ENTER on the interf ace selector.To replay the current track
continuously, push the interf ace
selector down while playing a disc.
Turn the interf ace dial to select
Repeat on the AUDIO MENU, and
press ENTER on the interf ace
selector. Turn the interf ace dial to
select Repeat icon, and press
ENTER on the interf ace selector.To turn this feature off, turn the
interface dial to select the OFF
icon, and press ENTER on the
interface selector.
To Choose a Track
Track Repeat
Playing a Disc (Models with navigation system)
Features
311
REPEAT OFF ICON
TRACK REPEAT ICON
TRACK LIST TRACK REPEAT INDICATOR
12/07/20 11:09:35 31TK4640_316
2013 TL

This f eature plays the tracks within a
disc in random order. When playing
MP3, WMA or AAC f ormat discs, all
the tracks within the disc are played
in random order, regardless of the
conf iguration of the f older.
Push the interf ace selector down
while playing a disc. Turn the
interf ace dial to select Random on
the AUDIO MENU, and press
ENTER on the interf ace selector.The scan f unction samples all tracks
on the disc in the order they are
recorded on the disc.
To activate scan, press the SCAN
side of the SCAN/A.SEL bar, or
push the interf ace selector down
while playing a disc. Turn the
interf ace dial to select Scan on the
AUDIO MENU, and press ENTER
on the interf ace selector.
To turn this feature off, turn the
interface dial to select the OFF
icon, and press ENTER on the
interface selector. Turn the interface dial to select the
track random icon, and press
ENTER on the interf ace selector.
Random Play
Track Scan
Playing a Disc (Models with navigation system)
312
TRACK RANDOM INDICATOR
SCAN ICON
TRACK RANDOM ICON
RANDOM OFF ICON
12/07/20 11:09:45 31TK4640_317
Features
2013 TL
