Visual Index
4Quick Reference Guide
❙Power Door Lock Master Switch
(P 105)
❙Power Window Switches
(P 115)
❙Rearview Mirror
(P 133)
❙Parking Brake
(P 257)
❙Hood Release Handle
(P 276)
❙Shift Lever Automatic
Transmission
(P 243)
❙Driver's Front Airbag
(P 40)
❙Door Mirror Controls
(P 134)
❙Passenger's Front Airbag (P 40)
❙Fuel Fill Door Release Handle
(P 264)
❙Glove Box
(P 145)
❙Accessory Power Socket (P 148)❙Seat Heater Switches
(P 151)
❙Interior Fuse Box
(P 338)

151
uuInterior Lights/Interior Convenience Items uInterior Convenience Items
Controls
The power mode must be in ON to use the
seat heaters. The HI setting heats the seats
faster than the LO setting.
While in HI, the heater cycles on and off.
u The appropriate indicator will be on
while the seat heater is on. Briefly press
the switch on the opposite side to turn
the heater off. The indicator will be off.
When a comfortable temperature is
reached, select LO to keep the seat
warm.
■
Seat Heaters
1 Seat Heaters
Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.
In the LO setting, the heater runs continuously and
does not automatically turn off.
3
WARNING
Heat induced burns are possible when
using seat heaters.
Persons with a diminish ed ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

338
uuFuses uFuse Locations
Handling the Unexpected
Located under the dashboard.
Fuse locations are shown on the label on
the side panel.
Locate the fuse in question by the fuse
number and label number.■
Circuit protected and fuse rating
■
Interior Fuse BoxFuse Label
Fuse Box
Circuit Protected
Amps
1
−
−
2
ACG
15 A
3
SRS
10 A
4
Fuel Pump
15 A
5
Meter
7.5 A
6
Option
7.5 A
7
VB SOL
10 A
8
Front Right Side
Door Lock Motor (Unlock)
15 A
9
Rear Left Side
Door Lock Motor (Unlock)
15 A
10 Power Lumbar 7.5 A
11
Moonroof
20 A
12 Accessory Power Socket
(Center Console) 15 A
13
Washer Main
15 A
14 Seat Heaters 15 A
15
Driver’s Door Lock Motor (Unlock)
10 A
16 − −
17
−
−
18 − −
19
ACC
7.5 A
20 ACC Key Lock 7.5 A
21
Daytime Running Lights
7.5 A
22 A/C 7.5 A
23
Rear Wiper
10 A
24 ABS/VSA 7.5 A
25
−
−
26 Audio Amp 20 A
27
Accessory Power Socket (Front)
15 A
28 − −
29
ODS
7.5 A
30 Driver’s Door Lock Motor
(Lock) 10 A
Circuit Protected
Amps
31
Smart
10 A
32 Front Right Side
Door Lock Motor (Lock) 15 A
33
Rear Left Side
Door Lock Motor (Lock)
15 A
34 Small Lights 7.5 A
35
Illumination
7.5 A
36 Rear Wiper Main 10 A
37
−
−
38 Left Headlight High Beam 10 A
39
Right Headlight High Beam
10 A
40 TPMS 7.5 A
41
Door Lock
20 A
42 Driver’s Power Window 20 A
43
Rear Right Side Power Window
20 A
44 Front Right Side Power
Window 20 A
45
Rear Left Side Power
Window
20 A
46 Wiper 30 A
Circuit Protected
Amps

358Index
Gear Shift Lever PositionsAutomatic Transmission ........................... 244
Glass (care) ................................................ 316
Glove Box .................................................. 145HHalogen Bulbs ................................... 287, 289
Handling the Unexpected ........................ 317
HandsFreeLink ® (HFL) ............................... 196
Automatic Import of Cellular Phonebook and Call History ............................................ 212
Automatic Transferring ............................ 210
Caller’s ID Information ............................. 210
HFL Buttons ............................................. 196
HFL Menus .............................................. 198
HFL Status Display.................................... 197
Making a Call .......................................... 215
Options During a Call .............................. 219
Phone Setup ............................................ 203
Receiving a Call ....................................... 218
Speed Dial ............................................... 213
Text Message................................... 208, 220
To Clear the System ................................. 211
To Create a Security PIN........................... 209
Hazard Warning Button ............................... 2
Head Restraints ......................................... 138
Headlights ................................................. 122
Aiming .................................................... 287
Automatic Operation ............................... 123
Dimming ......................................... 122, 125 Operating................................................ 122
Heaters (Seat) ........................................... 151
HFL (HandsFreeLink ®)............................... 196
High Beam Indicator .................................. 74
Hill Start Assist System ............................. 241
HomeLink ® Universal Transceiver ............ 194
IIdentification Numbers ............................ 346
Engine and Transmission ......................... 346
Vehicle Identification .............. ................. 346
Illumination Control ................................. 128
Knob ....................................................... 128
Immobilizer System .................................. 113
Indicator.................................................... 75
Indicators .................................................... 68
ABS (Anti-lock Brake System)..................... 71
AWD System ............................................. 72
Brake System............................................. 68
Charging System ............................... 69, 333
CRUISE CONTROL ............................. 76, 249
CRUISE MAIN .................................... 76, 248
Door Open .......................................... 28, 73
EPS (Electric Power Steering) System .. 74, 335
Fog Light ................................................... 75
High Beam ................................................ 74
Immobilizer System ................................... 75
Lights On .................................................. 75
Low Fuel ................................................... 71
Low Oil Pressure ................................ 69, 333 Low Tire Pressure/TPMS ............................ 74
Maintenance Minder............................... 271
Malfunction Indicator Lamp .............. 69, 334
Parking Brake and Brake System ....... 68, 335
Seat Belt Reminder.............................. 30, 71
Security System Alarm............................... 76
Shift Lever Position.................................... 70
Side Airbag Off ................................... 50, 75
Supplemental Restraint System ........... 48, 72
System Message ....................................... 76
Transmission ............................................. 70
Turn Signal ............................................... 74
VSA
® (Vehicle Stability Assist)
System ............................................ 73, 251
VSA ® OFF.......................................... 73, 252
Information .............................................. 343
Instrument Panel ........................................ 67
Brightness Control .................................. 128
Interior Lights ........................................... 143
Interior Rearview Mirror ......................... 133
iPod ®......................................................... 174
JJack (Wheel Nut Wrench) ........................ 322
Jump Starting ........................................... 328

360Index
Power Windows ...................................... 115
Tailgate ................................................... 107
Outside Temperature Display .................... 85
Overheating .............................................. 331PPaddle Shifters
(Sequential Shift Mode) ......................... 246
Pandora ®................................................... 177
Panic Mode ............................................... 114
Parking ...................................................... 261
Parking Brake ............................................ 257
Parking Brake and Brake System Indicator ..................... 68, 335
Passenger Airbag Off Indicator ................. 49
Passing Indicators ..................................... 122
Power Tailgate .......................................... 109
Power Windows ........................................ 115
Precautions While Driving ........................ 242
Driving Guidelines
for Your Utility Vehicle ........................... 242
Rain ......................................................... 242
Pregnant Women ....................................... 35
Puncture (Tire) .......................................... 319RRadiator..................................................... 283
Radio (AM/FM) .......................................... 167
Radio (XM ®) .............................................. 169 Radio Data System (RDS)
......................... 168
Range .......................................................... 86
RDS (Radio Data System) ......................... 168
Readiness Codes (Emissions Testing) ....... 349
Rear Defogger/ Heated Door Mirror Button ................... 129
Rear Seats (Folding Down) ...................... 141
Rearview Camera ..................................... 262
Rearview Mirror ....................................... 133
Refueling .................................................. 263
Fuel Gauge................................................ 82
Gasoline .......................................... 263, 344
Low Fuel Indicator ..................................... 71
Regulations ............................... 255, 304, 347
Remote Transmitter ................................... 99
Replacement
Bulbs ....................................................... 287
Front Wiper Blade Rubber ....................... 297
Fuses ............................................... 337, 338
Rear Wiper Blade Rubber......................... 299
Tires ........................................................ 307
Reporting Safety Defects ......................... 348
Resetting a Trip Meter ............................... 85
SSafe Driving................................................ 23
Safety Check ............................................... 28
Safety Labels ............................................... 65
Safety Message ........................................... 22
Seat Belts .................................................... 29 Adjusting the Shoulder Anchor ................. 33
Automatic Seat Belt Tensioners ................. 31
Checking .................................................. 36
Detachable Anchor ................................... 34
Fastening .................................................. 32
Installing a Child Seat with a Lap/
Shoulder Seat Belt ................................... 59
Pregnant Women...................................... 35
Reminder .................................................. 30
Warning Indicator ............................... 30, 71
Seat Heaters ............................................. 151
Seats .......................................................... 136
Adjusting ................................................ 136
Driver’s Seat Lumbar Support .................. 136
Front Seats.............................................. 136
Rear Seats ............................................... 141
Seat Heaters ........................................... 151
Security System ........................................ 113
Immobilizer System Indicator..................... 75
Security System Alarm Indicator ................ 76
SEL/RESET Button ....................................... 83
Select Lever ........................................ 14, 244
Operation ......................................... 14, 245
Releasing ................................................ 330
Won’t Move ........................................... 330
Selecting a Child Seat ................................ 56
Selector Knob (Audio) ............................. 161
Sequential Shift Mode ............................. 246
Setting the Clock ........................................ 96
Shift Lever .......................................... 14, 244
Shift Lever Position Indicator ............ 70, 245
