2013 Acura MDX child seat

2. Attach the tether strap hook to the
anchor, making sure the tether
strap is not twisted.
3. Tighten the strap according to the
seat maker's instructions.
If the tether strap is too long and
cannot be tightened firmly, find a
route where the strap can be
tightened securely.
Third Row InstallationEach third row seat has a tether
anchorage point on the tailgate sill.
1. Select the anchor point you want to
use. Then open the anchor cover
with a small flat-tip screwdriver.
2. Secure the child seat in the
desired position (see page 53).
3. Remove the head restraint, then
attach the tether strap hook to the
anchor, making sure the strap is
not twisted.
Make sure the removed head
restraint is secured in a safe place.
4. Tighten the strap according to the
seat maker's instructions.
If the tether strap is too long and
cannot be tightened firmly, find a
route where the strap can be
tightened securely.
Installing a Child Seat5612/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

When a child reaches the
recommended weight or height limit
for a forward-facing child seat, the
child should sit in a back seat on a
booster seat and wear the lap/
shoulder belt.
The following pages give instructions
on how to check proper seat belt fit,
what kind of booster seat to use if
one is needed, and important
precautions for a child who must sit
in front.
Allowing a child age 12 or under
to sit in front can result in injury
or death if the passenger's front
airbag inflates.
If a child must ride in front,
move the vehicle seat as far
back as possible, use a booster
seat if needed, have the child
sit up properly and wear the
seat belt properly.Checking Seat Belt Fit
To determine if a lap/shoulder belt
properly fits a child, have the child
put on the seat belt, then ask
yourself:
1. Does the child sit all the way back
against the seat?
2. Do the child's knees bend
comfortably over the edge of the
seat?
CONTINUED
Protecting Larger Children
57
Driver and Passenger Safety
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

3. Does the shoulder belt cross
between the child's neck and arm?
4. Is the lap part of the belt as low as
possible, touching the child's
thighs?
5. Will the child be able to stay
seated like this for the whole trip?
If you answer yes to all these
questions, the child is ready to wear
the lap/shoulder belt correctly. If
you answer no to any question, the
child needs to ride on a booster seat.Using a Booster Seat
A child who has outgrown a forward-
facing child seat should ride in a
back seat and use a booster seat until
the lap/shoulder belt fits them
properly without the booster.Some states, Canadian provinces and
territories also require children to
use a booster seat until they reach a
given age or weight (e.g., 6 years or
60 lbs). Be sure to check current
laws in the states, provinces or
territories where you intend to drive.
Booster seats can be high-back or
low-back. Whichever style you select,
make sure the booster seat meets
federal safety standards (see page
48) and that you follow the booster
seat maker's instructions.
Protecting Larger Children5812/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

If a child who uses a booster seat
must ride in front, move the vehicle
seat as far back as possible and be
sure the child is wearing the seat belt
properly.
A child may continue using a booster
seat until the tops of their ears are
even with the top of the vehicle's or
booster's seat-back. A child of this
height should be tall enough to use
the lap/shoulder belt without a
booster seat.When Can a Larger Child Sit in
Front
The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
age 12 and under be properly
restrained in a back seat.
If the passenger's front airbag
inflates in a moderate to severe
frontal collision, the airbag can cause
serious injuries to a child who is
unrestrained, improperly restrained,
sitting too close to the airbag, or out
of position.
A side airbag also poses risks. If any
part of a larger child's body is in the
path of a deploying side airbag, the
child could receive possibly serious
injuries.Of course, children vary widely. And
while age may be one indicator of
when a child can safely ride in front,
there are other important factors you
should consider.
Physical SizePhysically, a child must be large
enough for the lap/shoulder belt to
properly fit (see pages 16 and 57). If
the seat belt does not fit properly,
with or without the child sitting on a
booster seat, the child should not sit
in front.MaturityTo safely ride in front, a child must
be able to follow the rules, including
sitting properly, and wearing the seat
belt properly throughout a ride.
CONTINUED
Protecting Larger Children
59
Driver and Passenger Safety
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

If you decide that a child can safely
ride up front, be sure to:●Carefully read the owner's manual,
and make sure you understand all
seat belt instructions and all safety
information.●Move the vehicle seat to the rear-
most position.●Have the child sit up straight, back
against the seat, and feet on or
near the floor.●Check that the child's seat belt is
properly and securely positioned.●Supervise the child. Even mature
children sometimes need to be
reminded to fasten the seat belts
or sit properly.Additional Safety Precautions
●Do not let a child wear a seat belt
across the neck.
This could result
in serious neck injuries during a
crash.
●Do not let a child put the shoulder
part of a seat belt behind the back
or under the arm.
This could cause
very serious injuries during a
crash. It also increases the chance
that the child will slide under the
belt in a crash and be injured.
●Two children should never use the
same seat belt.
If they do, they
could be very seriously injured in a
crash.
●Do not put any accessories on a
seat belt.
Devices intended to
improve a child's comfort or
reposition the shoulder part of a
seat belt can make the belt less
effective and increase the chance
of serious injury in a crash.
Protecting Larger Children6012/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

This section gives information about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach.Control Locations
..........................
66
Instrument Panel
..........................
67
Instrument Panel Indicators
..........
68
Gauges
..........................................
78
Multi-Information Display
.............
79
Controls Near the Steering
Wheel
.....................................
125
Windshield Wipers and
Washers
..............................
126
Rear Window Wiper and
Washer
...............................
127
Turn Signal and Headlights
........
128
Hazard Warning Button
..............
132
Rear Window Defogger
...............
132
Instrument Panel Brightness
......
133
Steering Wheel Adjustments
.......
134
Keys and Locks
...........................
136
Immobilizer System
....................
138
Ignition Switch
............................
139
Door Locks
.................................
140
Childproof Door Locks
............
141
Tailgate
.......................................
141
Power Tailgate
........................
142
Remote Transmitter
....................
145Seats
...........................................
149
Detachable Anchor
.................
155
Seat Heaters
................................
157
Seat Heaters and Seat
Ventilation
...............................
158
Power Windows
..........................
160
Moonroof
....................................
163
Parking Brake
.............................
164
Mirrors
.......................................
165
Driving Position Memory
System
....................................
168
Interior Lights
.............................
170
Interior Convenience Items
.........
173
Beverage Holders
...................
174
Console Compartment
............
175
Storage Compartment
.............
175
Glove Box
...............................
175
Sunglasses Holder
..................
176
Sun Visor
................................
176
Vanity Mirror
..........................
177
Accessory Power Sockets
.......
177
AC Power Outlet
.....................
178
Instruments and Controls
65
Instruments and Controls
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Lockout PreventionWith any door and the tailgate open
and the key in the ignition, both
master door lock switches are
disabled. They are not disabled if all
the doors and the tailgate are closed.
If you try to lock an open driver's
door by pulling the lock tab rearward
the lock tab on the driver's door pops
out.Childproof Door Locks
The childproof door locks are
designed to prevent children seated
in the rear from accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position (lever is
down), the door cannot be opened
from the inside regardless of the
position of the lock tab. To open the
door, push the lock tab forward and
use the outside door handle.Tailgate
To open the tailgate, push up inside
the handle, then lift up. To close the
tailgate, use the inner handle to pull
it down, then press down on the back
edge.
Keep the tailgate closed at all times
while driving to avoid damaging the
tailgate and to prevent exhaust gas
from getting into the interior. See
Carbon Monoxide Hazardon page
61.
LOCK
Door Locks, Tailgate
141
Instruments and Controls
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Brakes
Anti-lock Brakes (ABS)
...........
461
Break-in, New Linings
.............
422
Fluid
.......................................
525
Parking
...................................
164
System Design
........................
461
System Indicator
...............
69, 564
Wear Indicators
.......................
461
Braking System
..........................
460
Break-in, New Vehicle
................
422
Brightness Control,
Instruments
............................
133
Bulb Replacement
Back-up Lights
................
531, 532
Front Parking Lights
...............
529
Front Side Marker Lights
........
529
Headlights
..............................
527
High-mount Brake Light
.........
533
Rear Bulbs
..............................
531
Rear License Plate Lights
........
533
Specifications
..........................
579
Taillights
.................................
531
Bulbs, Halogen
..........................
527C
Capacities Chart
.........................
578
Carbon Monoxide Hazard
............
61
Cargo
.........................................
433
Cargo Hooks
..............................
437
Cargo, How to Carry
..................
433
Carrying Cargo
..........................
433
CAUTION, Explanation of
.............
iv
CD Care
.....................................
247
CD Error Messages
...................
246
CD Player
..................................
235
Certification Label
......................
576
Chains, Tires
..............................
546
Changing a Flat Tire
..................
551
Changing Oil
How to
....................................
518
When to
..................................
507
Charging System
Indicator
...........................
69, 562
Checklist, Before Driving
...........
441
Childproof Door Locks
...............
141
Child Safety
..................................
40
Booster Seats
...........................
58
Child Seats
....................
45, 46, 48Important Safety Reminders
.....
44
Infants
......................................
45
Larger Children
.......................
57
LATCH
.....................................
50
Risks with Airbags
...................
41
Small Children
.........................
46
Tethers
....................................
54
Warning Labels
........................
42
Where Should a Child Sit?
........
41
Child Seats
.............................
40, 48
LATCH Anchorage Points
........
50
Tether Anchorage Points
.........
54
Cleaning the Seat Belts
..............
534
Client Service Information
..........
594
Climate Control System
.............
182
Clock
..........................................
309
Code, Audio System
...................
308
CO in the Exhaust
................
61, 587
Cold Weather, Starting in
...........
442
Collision Mitigation Braking
System™(CMBS™)
...............
463
Compact Spare Tire
....................
550
Compass Operation
....................
342
Console Compartment
...............
175
Consumer Information
...............
594
Controls, Instruments and
............
65
IndexII12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu
