Overview
Adaptive cruise control (ACC) allows
you to maintain a set speed and keep
the vehicle ahead of you and your
vehicle at a safe distance without
having to use the accelerator pedal or
the brake pedal.
When the vehicle ahead of you slows
down or speeds up, ACC senses the
change in distance and compensates
by adjusting your vehicle speed
accordingly. The distance between
vehicles is based on your speed: the
faster you go, the longer the distance
will be; the slower you go, the
shorter it will be.If the vehicle ahead of you slows
down suddenly or another vehicle
cuts in front of your vehicle, ACC
alerts you by sounding a beeper and
displaying a message on the multi-
information display.
The ACC radar sensor in the front
grille can detect and monitor the
distance of a vehicle up to 328 feet
(100 meters) ahead of your vehicle.
For more information on the radar
sensor, see page 464.
Important Safety Precautions
As with any system, there are limits
to ACC. Inappropriate use of ACC
can result in a serious accident. Use
the brake pedal whenever necessary,
and always keep a safe distance
between your vehicle and other
vehicles.Do not use ACC under these
conditions:
●In poor visibility.●In heavy traffic.●When you must slow down and
speed up repeatedly.●On winding roads.●When you enter a toll gate,
interchange, service area, parking
area, etc. In these areas, there is
no vehicle ahead of you, but ACC
would still try to accelerate to your
set speed.●In bad weather (rain, fog, snow,
etc.)●On a slippery road (for example a
road covered with ice or snow).
CONTINUED
Adaptive Cruise Control (ACC)
349
Features
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

If the vehicle ahead of you slows
down abruptly, or if another vehicle
cuts in front of you, a beeper sounds
and a message appears on the multi-
information display to warn you.
In this case, decelerate your vehicle
by pressing the brake pedal, and
keep an appropriate distance from
the vehicle ahead.
When a vehicle ahead is within ACC
range and going at a steady speedYour vehicle follows the vehicle
ahead of it, keeping a constant
distance. ACC will not keep your
vehicle at a constant distance if the
vehicle ahead of you goes out of
range of your set speed.
If the vehicle ahead of you slows
down and changes lanes, ACC no
longer tracks it. Your vehicle will
then return to your set speed.
CONTINUED
Adaptive Cruise Control (ACC)
351
Features
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Limitations●ACC does not work below 25 mph
(40 km/h). It cannot bring your
vehicle to a complete stop.●ACC will not sound a beeper or
display a message on the multi-
information display to warn you of
vehicles going slower than 13 mph
(20 km/h) or vehicles that are
parked. In these cases, it is up to
you to maintain a safe distance by
using the brake pedal.●ACC may not recognize
motorcycles or other small
vehicles ahead of your vehicle.
●ACC may react to vehicles beside
you or even a building beside you
by momentarily applying the
brakes or sounding a beeper
under conditions such as a sudden
curve or narrowing of the road, an
abrupt movement of the steering
wheel, or if you are in an unusual
position within your lane.
Adaptive Cruise Control (ACC)35212/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Using the ACC1. Push the MAIN button on the
steering wheel. The ACC indicator
on the instrument panel comes on,
and‘‘ACC’’is shown on the multi-
information display.
2. Accelerate to the desired speed
above 25 mph (40 km/h).
3. Press and release the SET/
DECEL button on the steering
wheel, then release the accelerator
pedal.
If you press the SET/DECEL button
when the vehicle speed is below 25
mph (40 km/h), you will hear a beep
for about 1 second. This means ACC
is not activated, and you cannot set
your speed.
When your speed reaches 25 mph
(40 km/h), ACC goes into wait
mode, and‘‘ACC’’is shown on the
multi-information display.
MAIN BUTTON
SET/DECEL BUTTON
CONTINUED
Adaptive Cruise Control (ACC)
353
Features
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

When the speed is set, it is shown
along with a vehicle icon and
distance bars on the multi-
information display.
Refer to page 357 for how to set and
change the set distance between
your vehicle and the vehicle ahead of
you.
To change the speed unit
measurement from mph to km/h,
see page 98.
If you change the speed unit
measurement from the factory
default setting, the initial speed unit
measurement is shown under the
current unit.Increasing the Set Speed
The set speed can be increased by
using the RES/ACCEL button or the
accelerator pedal.
To increase the set speed with the
RES/ACCEL button, do this:
Press and hold the RES/ACCEL
button. The vehicle will accelerate.
When you reach the speed you want,
release the button.
U.S.
SET VEHICLE
DISTANCE
CANADASET VEHICLE
SPEED
U.S.
INITIAL SPEED UNIT
CANADA
RES/ACCEL BUTTON
Adaptive Cruise Control (ACC)35412/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

To increase your speed in small
amounts, tap the RES/ACCEL button
repeatedly. Each time you do this,
your vehicle will speed up about 1
mph (1 km/h).
While the vehicle accelerates to the
set speed, the set speed on the multi-
information display will flash.
If a vehicle ahead of you is driving at
a slower speed than the speed you
want to set, your vehicle will not
accelerate; it will keep some distance
between your vehicles.
To increase the set speed with the
accelerator pedal, do this:
Press the accelerator pedal to
increase to the speed you want, then
press the SET/DECEL button. The
set speed will be shown on the multi-
information display. If you do not
press the SET/DECEL button, your
vehicle will return to the previously
set speed.The ACC beeper will not sound while
you press the accelerator pedal, no
matter how close you get to the
vehicle ahead of you.Decreasing the Set Speed
The set speed can be decreased
using the SET/DECEL button or the
brake pedal.
To decrease the set speed with the
SET/DECEL button, do this:
Press and hold the SET/DECEL
button. Release the button when you
reach the speed you want.SET/DECEL BUTTON
CONTINUED
Adaptive Cruise Control (ACC)
355
Features
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

To slow down in small amounts, tap
the SET/DECEL button repeatedly.
Each time you do this, your vehicle
slows down about 1 mph (1 km/h).
The set cruising speed will be shown
on the multi-information display.
On a steep downhill, the vehicle
speed may exceed the set cruising
speed.
To decrease the set speed with the
brake pedal, do this:
Tap the brake pedal. When the
vehicle slows down to the speed you
want, press the SET/DECEL button.
The set speed will be shown on the
multi-information display. If you use
the brake pedal to decrease speed,
and then press the RES/ACCEL
button, your vehicle will return to the
previously set speed.Detecting a Vehicle Ahead of You
When the system detects a vehicle
ahead of you, a beeper sounds once
and a solid-line vehicle icon appears
on the multi-information display.
When that vehicle changes lanes or
goes out of ACC range, a beeper
sounds once. If there is no vehicle
ahead of you within ACC range, a
dotted-line vehicle icon will be on the
multi-information display.
To set the ACC beeper on or off, see
page 97.
U.S.
CANADA
U.S.
CANADA
Adaptive Cruise Control (ACC)35612/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Changing Vehicle DistanceWith ACC on, the distance between
your vehicle and the vehicle ahead of
you is controlled and maintained.
You can change this distance to one
of three ranges: long, middle, or
short.To change the range, press the
distance button. Each time you press
the button, the range changes from
Long, to Middle, and then to Short.
The higher your vehicle speed is, the
longer the distance between the
vehicle in front will be set as shown
below.
Speed 50 mph
(80 Km/h)65 mph
(104 Km/h)
Vehicle
Distance
Long 154 feet
47 meters200 feet
61 meters
Middle 111 feet
34 meters173 feet
42 meters
Short 85 feet
26 meters101 feet
31 meters
The distance you select is also shown
on the multi-information display.
DISTANCE BUTTON
U.S.
LONG
RANGE
U.S.
CANADA CANADA
U.S.
CANADA MIDDLE
RANGE
SHORT
RANGE
CONTINUED
Adaptive Cruise Control (ACC)
357
