2013 Acura ILX Hybrid check engine

Contents
Child Safety P. 54 Exhaust Gas Hazard P. 66 Safety Labels P. 67Opening and Closing the Trunk P. 114 Security System P. 118 Opening and Closing the Windows P. 120
Operating the Switches Around the Steering Wheel P. 124 Adjusting the Mirrors P. 133
Climate Control System P. 146Audio Error Messages
* P. 180 General Information on the Audio System P. 183
Bluetooth® HandsFreeLink® P. 189
When Driving P. 226 Braking P. 245 Parking Your Vehicle P. 249
Fuel Economy P. 256 Accessories and Modifications P. 257Maintenance Under the Hood P. 268 Replacing Light Bulbs P. 282
Checking and Maintaining Tires P. 294 12 Volt Battery P. 303 Remote Transmitter Care P. 304
Cleaning P. 306Engine Does Not Start P. 328 Jump Starting P. 331 Shift Lever Does Not Move P. 333
Fuses P. 340 Emergency Towing P. 343Devices that Emit Radio Waves P. 349 Reporting Safety Defects P. 350
Authorized Manuals P. 355 Client Service Information P. 356
Quick Reference Guide
P. 2
Safe Driving
P. 27
Instrument Panel
P. 69
Controls
P. 103
Features
P. 151
Driving
P. 219
Maintenance
P. 259
Handling the Unexpected
P. 311
Information
P. 345
Index
P. 357

12Quick Reference Guide
Safe Driving
(P27)
Airbags
(P39)
●Your vehicle is fitted with airbags to help protect you and
your passengers during a moderate-to-severe collision.
Child Safety
(P54)
●All children 12 and younger should be seated in the rear seat.
●Smaller children should be properly restrained in a forward-facing child seat.
●Infants must be properly restrained in a rear-facing child seat.
Exhaust Gas Hazard
(P66)
●Your vehicle emits dangerous exhaust gases that contain carbon
monoxide. Do not run the engine in confined spaces where carbon
monoxide gas can accumulate.
Before Driving Checklist
(P220)
●Before driving, check that the front seats, head restraints,
steering wheel, and mirrors have been properly adjusted.
Seat Belts
(P32)
●Fasten your seat belt and sit upright well
back in the seat.
●Check that your passengers are wearing
their seat belts correctly.
Fasten your lap belt as
low as possible.

20Quick Reference Guide
Maintenance
(P259)
Under t
he Hoo
d (P268)
●Check engine oil, engine coolant, and windshield washer
fluid. Add when necessary.
●Check brake fluid.
●Check the 12 volt battery condition monthly.
a
Pull the hood release handle under the corner of the
dashboard.
b
Locate the hood latch lever, slide the lever and lift up the
hood.
c
When finished, close the hood and make sure it is firmly
locked in place.
Lights
(P282)
●Inspect all lights regularly.
Wiper Blades
(P292)
●Replace blades if they leave streaks
across the windshield.
Tires
(P294)
●Inspect tires and wheels regularly.
●Check tire pressures regularly.
●Install snow tires for winter driving.

Quick Reference Guide21
Handling the Unexpected
(P311)
Flat Tire
(P313)
●Park in a safe location and repair the flat
tire using the tire repair kit.
Indicators Come On (P336)
●Identify the indicator and consult the
owner's manual.
Engine Won't Start
(P328)
●If the battery is dead, jump start using a
booster battery.
Blown Fuse
(P340)
●Check for a blown fuse if an electrical
device does not operate.
Overheating
(P334)
●Park in a safe location. If you do not see
steam under the hood, open the hood,
and let the engine cool down.
Emergency Towing
(P343)
●Call a professional towing service if you
need to tow your vehicle.

22Quick Reference Guide
What to Do If
The power mode does not
change from VEHICLE OFF
(LOCK) to ACCESSORY.
Why?
●The steering wheel may be locked.●Move the steering wheel left and right after
pressing the ENGINE START/STOP button.
The power mode does not
change from ON to
VEHICLE OFF (LOCK). Why?
The shift lever should be moved to
(P.
Why does the brake pedal
pulsate slightly when
applying the brakes?
This can occur when the ABS activates, and does not indicate a
problem. Apply firm, steady pressure on the brake pedal. Never
pump the brake pedal.
The rear door cannot be
opened from inside the
vehicle. Why?
Check if the childproof lock is in the
LOCK position. If so, open the rear
door with the outside door handle.
To cancel this function, push the lever
to the UNLOCK position.

71
uuIndicatorsu
Continued
Instrument Panel
Indicator
Name
On/Blinking
Explanation
Message
Brake System
Indicator (Amber)
●Comes on for a few seconds when
you set the power mode to ON, then
goes off.●Comes on if there is a problem with
the cooperative control with
regenerative brake.
●Stays on constantly - Have the vehicle
checked by a dealer. Normal braking is not
affected.
Malfunction
Indicator Lamp
●Comes on when you set the power
mode to ON, and goes off either
when the engine starts or after
several seconds if the engine is not
started. If “readiness codes” have
not been set, it blinks five times
before it goes off.●Comes on if there is a problem with
the emissions control system.●Blinks when a misfire in the engine's
cylinders is detected.
●Readiness codes are part of the on board
diagnostics for the emissions control
systems.
2Testing of Readiness Codes P. 351
●Comes on while driving - Have the
vehicle checked by a dealer.●Blinks while driving - Stop in a safe place
where there are no flammable objects. Stop
the engine for 10 minutes or more, and
wait for it to cool down. Then, take the
vehicle to a dealer.
2If the Malfunction Indicator Lamp
Comes On or Blinks P. 337
U.S.Canada(Amber)
U.S.Canada

72
uuIndicatorsu
Instrument Panel
Indicator
Name
On/Blinking
Explanation
Message
12 Volt Battery
Charging System
Indicator
●Comes on when you set the power
mode to ON, and goes off when the
engine starts.●Comes on when the 12 volt battery is
not charging.
●Comes on while driving - Turn off the
climate control system and rear defogger in
order to reduce electricity consumption.
2If the Charging System Indicator
Comes On P. 336
Shift Lever
Position Indicator
●Indicates current shift lever position.
2Shifting P. 231
—
Transmission
Indicator
●Blinks if the transmission system has
a problem.
●Blinks while driving - Avoid sudden starts
and acceleration and have the vehicle
checked by a dealer immediately.
M (7-speed
manual shift
mode) Indicator/
Shift Indicator
●Comes on when the 7-speed manual
shift mode is applied.
27-Speed Manual Shift Mode P. 233
—

75
uuIndicatorsu
Continued
Instrument Panel
Indicator
Name
On/Blinking
Explanation
Message
Low Oil Pressure
Indicator
●Comes on when you set the power
mode to ON, and goes off when the
engine starts.●Comes on when the engine oil
pressure is low.
●Comes on while driving - Immediately
stop in a safe place.
2If the Low Oil Pressure Indicator
Comes On P. 336
Door and Trunk
Open Indicator
●Comes on for a few seconds if you
set the power mode to ON, then
goes off.●Comes on if any door or the trunk is
not completely closed.
●Goes off when all doors and the trunk are
closed.
EPS (Electric
Power Steering)
System Indicator
●Comes on when you set the power
mode to ON, and goes off when the
engine starts.●Comes on if there is a problem with
the EPS (Electric Power Steering)
System.
●Stays on constantly or does not come
on at all - Have the vehicle checked by a
dealer.
2If the EPS System Indicator Comes On
P. 338
Auto Idle Stop
Indicator
●Blinks when Auto Idle Stop is in
operation. The engine automatically
shuts off.
2Auto Idle Stop P. 250
—
