2013 Acura ILX Hybrid engine

351
Continued
Information
Emissions TestingTesting of Readiness CodesYour vehicle uses “readiness codes,” as part of its onboard self diagnostic system.
Some states refer to these codes during testing to see if your vehicle's emissions
components are working properly.
The codes may not be read if you go through the testing just after the battery has
gone dead or been disconnected.
To check if they are set, set the power mode to ON, without starting the engine. The
malfunction indicator lamp will come on for several seconds. If it then goes off, the
readiness codes are set. If it blinks five times, the readiness codes are not set.
If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following:
1.Fill the gas tank to approximately 3/4 full.
2.Park the vehicle and leave the engine off for 6 hours or more.
3.Make sure the ambient temperature is between 40 °F and 95 °F (4 °C and 35 °C).
4.Start the engine without touching the accelerator pedal, and let it idle for 20
seconds.
5.Keep the vehicle in
(P. Increase the engine speed to 2,000 rpm, and hold it there
for about 3 minutes.
6.Let the engine idle with your foot off the accelerator for 20 seconds.
1Testing of Readiness Codes
The readiness codes are erased when the 12 volt
battery is disconnected, and set again only after
several days of driving under a variety of conditions.
If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.
If the testing facility determines the readiness codes
are still not set, see a dealer.

352
uuEmissions TestinguTesting of Readiness Codes
Information
7.Select a nearby, lightly traveled major highway where you can maintain a speed
of 50 to 60 mph (80 to 97 km/h) for at least 20 minutes. Drive on the highway in (D. Do not use cruise control. When traffic allows, drive for 90 seconds without
moving the accelerator pedal. (Vehicle speed may vary slightly; this is okay.) If you
cannot do this for a continuous 90 seconds because of traffic conditions, drive for
at least 30 seconds, then repeat it two more times (for a total of 90 seconds).
8.Drive in city/suburban traffic for at least 10 minutes. When traffic conditions
allow, let the vehicle coast for several seconds without using the accelerator pedal
or the brake pedal.
9.Park the vehicle and leave the engine off for 30 minutes.

Index
357Index
Index
Numbers7-Speed Manual Shift Mode................... 233
7-Speed Manual Shift Mode
Operation............................................... 234AABS (Anti-lock Brake System).................. 247
Accessories and Modifications................ 257
Accessory Power Socket........................... 144
Acura Hybrid System.................................. 10
Additives
Coolant .................................................. 277
Engine Oil ............................................... 274
Washer ................................................... 281
Additives, Engine Oil............................... 272
Adjusting
Armrest .................................................. 140
Front Seats.............................................. 135
Head Restraints ....................................... 138
Mirrors.................................................... 133
Steering Wheel ....................................... 132
Temperature ............................................. 90
Air Conditioning System (Climate Control
System).................................................... 146
Changing the Mode................................ 146
Defrosting the Windshield and
Windows .............................................. 147
Dust and Pollen Filter .............................. 305
Recirculation/Fresh Air Mode................... 146
Sensor .................................................... 149Synchronized Mode ................................. 148
Using Automatic Climate Control ............ 146
Air Pressure............................................... 294
Airbags........................................................ 39
Advanced Airbags ..................................... 45
After a Collision......................................... 43
Airbag Care ............................................... 53
Event Data Recorders................................. 24
Front Airbags (SRS) .................................... 42
Indicator ........................................ 50, 74, 78
Passenger Airbag Off Indicator .................. 51
Sensors...................................................... 45
Side Airbag Cutoff System ......................... 48
Side Airbag Off Indicator ........................... 48
Side Airbags .............................................. 46
Side Curtain Airbags .................................. 49
AM/FM Radio............................................ 161
Anti-lock Brake System (ABS).................. 247
Indicator .................................................... 73
Armrest..................................................... 140
Audio Remote Controls............................ 159
Audio System............................................ 152
Adjusting the Sound ................................ 160
Auxiliary Input Jack .................................. 153
Error Messages ........................................ 180
General Information ................................ 183
iPhone®................................................... 186
iPod®....................................................... 168
MP3/WMA/AAC ...................................... 173
Pandora®................................................. 171
Reactivating............................................. 154Recommended CDs ................................. 184
Recommended Devices............................ 186
Security Code .......................................... 154
Theft Protection ...................................... 154
USB Adapter Cable.................................. 153
USB Flash Drives ...................................... 186
Audio/Information Screen....................... 156
Authorized Manuals................................ 355
Auto Door Locking/Unlocking................. 113
Customize ................................................. 95
Auto Idle Stop.......................................... 250
Auto Idle Stop Indicator............................ 75
Automatic Lighting.................................. 127
Automatic Transmission (CVT)................. 230
Creeping ................................................. 230
Fluid ........................................................ 279
Kickdown ................................................ 230
Operating the Shift Lever......................... 232
Shift Lever Does Not Move ...................... 333
Shifting ................................................... 231
Auxiliary Input Jack.................................. 153
Average Fuel Economy.............................. 91
Average Fuel Economy Records................ 91
Average Speed........................................... 92BBattery...................................................... 303
Charging System Indicator................. 72, 336
Jump Starting .......................................... 331

358Index
Maintenance (Checking the 12 Volt
Battery) .................................................. 303
Maintenance (Replacing).......................... 304
Belts (Seat).................................................. 32
Beverage Holders...................................... 143
Bluetooth® Audio..................................... 176
Bluetooth® HandsFreeLink®..................... 189
Booster Seats (For Children)....................... 65
Brake System............................................. 245
Anti-lock Brake System (ABS) ................... 247
Brake Assist System ................................. 248
Brake System Indicator....................... 71, 338
Fluid ........................................................ 280
Foot Brake ............................................... 246
Indicator ............................................ 71, 338
Parking Brake .......................................... 245
Brightness Control (Instrument Panel).... 131
Bulb Replacement..................................... 282
Back-Up Light Bulbs ................................. 290
Brake Light, Taillight, Rear Turn Signal Light
and Rear Side Marker Light Bulbs ........... 288
Bulb Specifications ................................... 346
Fog Lights ................................................ 284
Front Turn Signal Light Bulbs ................... 286
Headlights ............................................... 282
High-Mount Brake Light .......................... 291
Parking/Side Marker Light Bulbs ............... 287
Rear License Plate Light............................ 291
CCarbon Monoxide Gas............................... 66
Carrying Cargo................................. 221, 223
CD Player................................................... 165
Certification Label.................................... 348
Changing Bulbs........................................ 282
Charge/Assist Gauge.................................. 86
Charging System Indicator................. 72, 336
Child Safety................................................. 54
Childproof Door Locks............................. 112
Emergency Trunk Opener ........................ 117
Child Seat.................................................... 54
Booster Seats ............................................ 65
Child Seat for Infants................................. 56
Child Seat for Small Children ..................... 57
Installing a Child Seat with a Lap/Shoulder Seat
Belt ......................................................... 61
Larger Children ......................................... 64
Rear-facing Child Seat ............................... 56
Selecting a Child Seat ................................ 58
Using a Tether ........................................... 63
Childproof Door Locks............................. 112
Cleaning the Exterior............................... 308
Cleaning the Interior................................ 306
Client Service Information....................... 356
Climate Control System............................ 146
Changing the Mode ................................ 146
Defrosting the Windshield and
Windows ............................................... 147
Dust and Pollen Filter............................... 305
Recirculation/Fresh Air Mode ................... 146Sensors ................................................... 149
Synchronized Mode ................................ 148
Using Automatic Climate Control ............ 146
Clock......................................................... 104
Coat Hook................................................ 144
Compact Spare Tire (Optional)............... 321
Console Compartment............................. 142
Controls.................................................... 103
Coolant (Engine)...................................... 277
Adding to the Radiator ........................... 278
Adding to the Reserve Tank .................... 277
Low Temperature Indicator ....................... 79
Overheating ............................................ 334
Creep Aid System..................................... 228
Creeping................................................... 230
Cruise Control.......................................... 237
Indicator ................................................... 80
Cup Holders.............................................. 143
Customized Features................................. 95
DDaytime Running Lights.......................... 129
Dead Battery............................................ 331
Defrosting the Windshield and
Windows................................................. 147
Devices that Emit Radio Waves............... 349
Dimming
Headlights .............................................. 126
Rearview Mirror ...................................... 133
Dipstick (Engine Oil)................................ 273

359Index
Directional Signals (Turn Signal)............. 126
Doors........................................................ 105
Auto Door Locking.................................. 113
Auto Door Unlocking .............................. 113
Door Open Indicator ........................... 31, 75
Keys........................................................ 105
Locking/Unlocking the Doors from the
Inside .................................................... 111
Locking/Unlocking the Doors from the
Outside ................................................. 107
Lockout prevention system...................... 110
DOT Tire Quality Grading........................ 297
Driving...................................................... 219
Automatic Transmission (CVT)................. 230
Braking ................................................... 245
Cruise Control ........................................ 237
Shifting Speed Position ........................... 231
Starting the Engine ................................. 226
Dust and Pollen Filter.............................. 305EEco Assist System.......................................... 8
ECON Button............................................ 236
ECON Mode Indicator................................ 80
Elapsed Time.............................................. 91
Electric Power Steering (EPS) System
Indicator ........................................... 75, 338
Electronic Stability Control (ESC)............ 240
Emergency................................................ 343
Emergency Trunk Opener....................... 117Emissions Testing (Readiness Codes)....... 351
Engine....................................................... 348
Coolant ................................................... 277
Jump Starting .......................................... 331
Oil ........................................................... 272
Starting ................................................... 226
Switch Buzzer .......................................... 125
Engine Compartment Cover.................... 270
Engine Coolant......................................... 277
Adding to the Radiator ............................ 278
Adding to the Reserve Tank ..................... 277
Low Temperature Indicator ........................ 79
Overheating ............................................ 334
Engine Oil................................................. 272
Adding .................................................... 274
Checking ................................................. 273
Displaying Oil Life .................................... 264
Low Oil Pressure Indicator.................. 75, 336
Recommended Engine Oil........................ 272
ENGINE START/STOP Button.................... 124
EPS (Electric Power Steering)
System............................................... 75, 338
Exhaust Gas Hazard (Carbon
Monoxide)................................................. 66
Expanded View Driver’s Mirror............... 134
Exterior Care (Cleaning)........................... 308
Exterior Mirrors........................................ 134
FFeatures..................................................... 151Filters......................................................... 305
Dust and Pollen ....................................... 305
Oil ........................................................... 275
Flat Tire..................................................... 313
Floor Mats................................................. 307
Fluids
Brake ...................................................... 280
Continuously Variable Transmission
Fluid ...................................................... 279
Engine Coolant ....................................... 277
Windshield Washer ................................. 281
Fog Light Indicator..................................... 77
Foot Brake................................................ 246
Front Airbags (SRS)..................................... 42
Front Seats................................................ 135
Adjusting ................................................ 135
Fuel...................................................... 19, 254
Economy ................................................. 256
Gauge ....................................................... 86
Instant Fuel Economy ................................ 91
Low Fuel Indicator ..................................... 73
Range ....................................................... 91
Recommendation .................................... 254
Refueling................................................. 254
Fuel Economy........................................... 256
Fuel Economy Indicator......................... 9, 90
Fuel Fill Cap........................................ 19, 255
Message.................................................. 337
Fuel Fill Door...................................... 19, 255
Fuses.......................................................... 340
Inspecting and Changing......................... 342

360Index
Locations ......................................... 340, 341GGasoline (Fuel)
Economy ................................................. 256
Gauge ....................................................... 86
Information ............................................. 254
Instant Fuel Economy ................................. 91
Low Fuel Indicator ..................................... 73
Refueling ................................................. 254
Gauges......................................................... 86
Glass (care)................................................ 308
Glove Box.................................................. 142HHalogen Bulbs................................... 282, 283
Handling the Unexpected........................ 311
HandsFreeLink® (HFL)............................... 189
Automatic Import of Cellular Phonebook and
Call History ............................................ 205
Automatic Transferring ............................ 203
Caller’s ID Information ............................. 203
HFL Buttons ............................................. 189
HFL Menus .............................................. 191
HFL Status Display.................................... 190
Making a Call .......................................... 208
Options During a Call .............................. 212
Phone Setup ............................................ 196
Receiving a Call ....................................... 211Speed Dial ............................................... 206
Text Message .................................. 201, 213
To Clear the System ................................ 204
To Create a Security PIN .......................... 202
Hazard Warning Button.............................. 2
Head Restraints........................................ 138
Headlights................................................. 126
Aiming .................................................... 282
Automatic Operation............................... 127
Dimming ......................................... 126, 129
Operating................................................ 126
Heaters (Seat)........................................... 145
HFL (HandsFreeLink®)............................... 189
High-Beam Indicator.................................. 77
Hill Start Assist System............................. 228
HomeLink® Universal Transceiver............ 187
IIdentification Numbers............................ 348
Engine and Transmission ......................... 348
Vehicle Identification ............................... 348
Illumination Control................................. 131
Knob ....................................................... 131
IMA Battery Charge Level Indicator/Power
Flow Monitor............................................ 93
IMA System Indicator................................. 77
Immobilizer System.................................. 118
Indicator.................................................... 78
Indicators.................................................... 70
ABS (Anti-lock Brake System)..................... 73Auto Idle Stop........................................... 75
Brake System ............................................ 71
Charging System............................... 72, 336
CRUISE CONTROL ............................. 80, 238
CRUISE MAIN.................................... 80, 237
Door and Trunk Open ......................... 31, 75
Door Open................................................ 31
ECON Mode ..................................... 80, 236
EPS (Electric Power Steering)
System ............................................ 75, 338
Fog Light .................................................. 77
High-Beam................................................ 77
IMA System .............................................. 77
Immobilizer System ................................... 78
Keyless Access System............................... 79
Lights On .................................................. 77
Low Fuel ................................................... 73
Low Oil Pressure ............................... 75, 336
Low Temperature...................................... 79
Low Tire Pressure/TPMS .................... 76, 242
Maintenance Minder............................... 263
Malfunction Indicator Lamp .............. 71, 337
Parking Brake and Brake System ....... 70, 338
Seat Belt Reminder.............................. 33, 73
Security System Alarm............................... 79
Shift Lever Position.................................... 72
Side Airbag Off ................................... 52, 78
Supplemental Restraint System ........... 50, 74
System Message ....................................... 76
Transmission ............................................. 72
Turn Signal ............................................... 77

362Index
Mirrors....................................................... 133
Adjusting ................................................. 133
Door ........................................................ 134
Exterior .................................................... 134
Interior Rearview...................................... 133
Modifications (and Accessories)............... 257
Moonroof.................................................. 123
MP3.................................................... 165, 173
Multi-Information Display.......................... 87
Multi-View Rear Camera.......................... 253NNumbers (Identification).......................... 348OOdometer.................................................... 89
Oil (Engine)............................................... 272
Adding .................................................... 274
Checking ................................................. 273
Displaying Oil Life .................................... 264
Low Oil Pressure Indicator .................. 75, 336
Recommended Engine Oil ........................ 272
Viscosity .................................................. 272
Opening/Closing
Hood ....................................................... 269
Moonroof ................................................ 123
Power Windows ...................................... 120
Trunk....................................................... 114Operating the Switches Around the Steering
Wheel...................................................... 124
Outside Temperature
Adjusting .................................................. 90
Overheating.............................................. 334
PPaddle Shifters (Sequential Shift Mode)... 18
Pandora®................................................... 171
Panic Mode............................................... 119
Parking...................................................... 249
Parking Brake........................................... 245
Parking Brake and Brake System
Indicator............................................ 70, 338
Passenger Airbag Off Indicator................. 51
Passing Indicators..................................... 126
Power Windows....................................... 120
Precautions While Driving....................... 229
Rain ........................................................ 229
Pregnant Women....................................... 37
Puncture (Tire).................................. 313, 321RRadiator.................................................... 278
Radio (AM/FM)......................................... 161
Radio (XM®).............................................. 163
Radio Data System (RDS)......................... 162
Range.......................................................... 91
RDS (Radio Data System)......................... 162Readiness Code (Emissions Testing)........ 351
Rear Defogger/Heated Door Mirror
Button..................................................... 132
Rearview Mirror....................................... 133
Refueling.................................................. 254
Fuel Gauge ............................................... 86
Gasoline ......................................... 254, 346
Low Fuel Indicator..................................... 73
Regulations.............................. 243, 296, 349
Remote Transmitter................................. 107
Replacement
Battery .................................................... 303
Bulbs ...................................................... 282
Fuses .............................................. 340, 341
Tires........................................................ 300
Wiper Blade Rubber ................................ 292
Reporting Safety Defects......................... 350
Resetting a Trip Meter............................... 89
SSafe Driving................................................ 27
Safety Check............................................... 31
Safety Labels.............................................. 67
Safety Message.......................................... 25
Seat Belts.................................................... 32
Adjusting the Shoulder Anchor ................. 36
Automatic Seat Belt Tensioners ................. 34
Checking .................................................. 38
Fastening .................................................. 35

363Index
Installing a Child Seat with a Lap/Shoulder Seat
Belt ......................................................... 61
Pregnant Women...................................... 37
Reminder .................................................. 33
Warning Indicator ............................... 33, 73
Seat Heaters............................................. 145
Seats.......................................................... 135
Adjusting ................................................ 135
Front Seats.............................................. 135
Seat Heaters ........................................... 145
Security System
Immobilizer System Indicator..................... 78
Security System Alarm Indicator ................ 79
SEL/RESET Button....................................... 87
Select Lever........................................ 18, 231
Operation ......................................... 18, 232
Releasing ................................................ 333
Won’t Move ........................................... 333
Selecting a Child Seat................................ 58
Selector Knob (Audio)............................. 155
Setting the Clock...................................... 104
Shift Lever.......................................... 18, 231
Shift Lever Position Indicator.................... 72
Shift Lever Positions
Automatic Transmission (CVT)................. 231
Shifting..................................................... 231
Shoulder Anchor........................................ 36
Side Airbags............................................... 46
Cutoff System ........................................... 48
Off Indicator ............................................. 48
Side Curtain Airbags.................................. 49SMS Text Message............................ 201, 213
Snow Tires................................................. 302
Spare Tire Kit (Optional).......................... 313
Spark Plugs................................................ 346
Specifications............................................ 346
Specified Fuel.................................... 254, 346
Speedometer.............................................. 86
SRS Airbags (Airbags)................................. 39
Starting the Engine.................................. 226
Does Not Start ......................................... 328
Engine Switch Buzzer .............................. 124
Jump Starting .......................................... 331
Steering Wheel................................. 124, 132
Adjusting................................................. 132
Stopping.................................................... 249
Summer Tires............................................ 302
Supplemental Restraint System (SRS)........ 42
Switches (Around the Steering Wheel)... 2, 3
System Message Indicator.......................... 76
TTachometer................................................. 86
Temperature
High Temperature Indicator ....................... 79
Low Temperature Indicator ........................ 79
Outside Temperature ................................. 90
Temperature Sensor................................... 90
Text Message.................................... 201, 213
Time (Setting)........................................... 104Tire Pressure Monitoring System
(TPMS)..................................................... 242
Indicator............................................ 76, 339
Tire Repair Kit........................................... 313
Tires........................................................... 294
Air Pressure ..................................... 295, 347
Checking and Maintaining ...................... 294
Inspection ............................................... 294
Labeling .................................................. 295
Puncture (Flat Tire) .................................. 313
Regulations ............................................. 297
Rotation .................................................. 301
Spare Tire Kit (Optional) .......................... 313
Summer .................................................. 302
Tire Chains .............................................. 302
Tire Repair Kit.......................................... 313
Wear Indicators ....................................... 299
Winter..................................................... 302
Tools.......................................................... 312
Towing a Trailer....................................... 225
Towing Your Vehicle................................ 225
Emergency .............................................. 343
TPMS (Tire Pressure Monitoring
System).................................................... 242
Indicator............................................ 76, 339
Transmission............................................. 231
Automatic ............................................... 231
Fluid ........................................................ 279
Number................................................... 348
Shift Lever Position Indicator...................... 72
Trip Meter................................................... 89
