PERIODIC MAINTENANCE AND ADJUSTMENT
7-30
72. Install the wheel and the brake cal-
iper bracket by inserting the wheel
axle from the right-hand side.
TIP
Make sure that the slot in the brake
caliper bracket is fit over the retain-
er on the swingarm.
Make sure that there is enough
space between the brake pads be-
fore installing the wheel.
3. Install the washer and axle nut.
4. Lower the rear wheel so that it ison the ground, install the remov-
able sidestand, and then rest the
motorcycle on it. 5. Adjust the drive chain slack. (See
page 7-22.)
6. Tighten the locknuts and the axle nut to their specified torques.
EAU25871
Troubleshooting Although Yamaha motorcycles receive
a thorough inspection before shipment
from the factory, trouble may occur dur-
ing operation. Any problem in the fuel,
compression, or ignition systems, for
example, can cause poor starting and
loss of power.
The following troubleshooting charts
represent quick and easy procedures
for checking these vital systems your-
self. However, should your motorcycle
require any repair, take it to a Yamaha
dealer, whose skilled technicians have
the necessary tools, experience, and
know-how to service the motorcycle
properly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look like
Yamaha parts, but they are often inferi- or, have a shorter service life and can
lead to expensive repair bills.
WARNING
EWA15141
When checking the fuel system, do
not smoke, and make sure there are
no open flames or sparks in the ar-
ea, including pilot lights from water
1. Retainer
2. Slot
2 1
Tightening torque:
Locknut:16 Nm (1.6 m ·kgf, 12 ft· lbf)
Axle nut:
90 Nm (9.0 m ·kgf, 65 ft· lbf)
U1SN80E0.book Page 30 Thursday, June 9, 2011 11:24 AM
SPECIFICATIONS
9-1
9
Dimensions:Overall length:YZ85 1818 mm (71.6 in)
(AUT)(BEL)(CHE)(DEU)(DNK)(ESP)(FIN)
(FRA)(GBR)(GRC)(IRL)(ITA)(NLD)(NOR)
(POL)(PRT)(SVN)(SWE)
YZ85 1821 mm (71.7 in) (ZAF)
YZ85B 1818 mm (71.6 in)
YZ85LW 1903 mm (74.9 in)
YZ85LWB 1903 mm (74.9 in)
Overall width: 758 mm (29.8 in)
Overall height:
YZ85 1161 mm (45.7 in)
YZ85B 1161 mm (45.7 in)
YZ85LW 1205 mm (47.4 in)
YZ85LWB 1205 mm (47.4 in)
Seat height: YZ85 864 mm (34.0 in)
YZ85B 864 mm (34.0 in)
YZ85LW 904 mm (35.6 in)
YZ85LWB 904 mm (35.6 in)
Wheelbase: YZ85 1255 mm (49.4 in)
(AUT)(BEL)(CHE)(DEU)(DNK)(ESP)(FIN)
(FRA)(GBR)(GRC)(IRL)(ITA)(NLD)(NOR)
(POL)(PRT)(SVN)(SWE)
YZ85 1258 mm (49.5 in) (ZAF)
YZ85B 1255 mm (49.4 in)
YZ85LW 1286 mm (50.6 in)
YZ85LWB 1286 mm (50.6 in) Ground clearance:
YZ85 351 mm (13.82 in)
YZ85B 351 mm (13.82 in)
YZ85LW 393 mm (15.47 in)
YZ85LWB 393 mm (15.47 in)
Weight:Curb weight:
YZ85 71 kg (157 lb)
YZ85B 71 kg (157 lb)
YZ85LW 73 kg (161 lb)
YZ85LWB 73 kg (161 lb)Engine:Engine type:Liquid cooled 2-stroke
Cylinder arrangement:
Single cylinder
Displacement: 84 cm ³
Bore × stroke:
47.5 × 47.8 mm (1.87 × 1.88 in)
Compression ratio:
8.20 : 1
Starting system: Kickstarter
Lubrication system: PremixEngine oil:Type:YAMALUBE 2RTransmission oil:Type:
YAMALUBE 4 (10W-40) or SAE 10W-40
Oil change quantity: 0.50 L (0.53 US qt, 0.44 Imp.qt)
Cooling system:Radiator capacity (including all routes):0.54 L (0.57 US qt, 0.48 Imp.qt)Air filter:Air filter element:Wet elementFuel:Recommended fuel:
Premium unleaded gasoline only
Fuel tank capacity: 5.0 L (1.32 US gal, 1.10 Imp.gal)Carburetor:Type × quantity:
PWK28 x 1Spark plug(s):Manufacturer/model: NGK/BR10EG
Spark plug gap:
0.5 –0.6 mm (0.020 –0.024 in)Clutch:Clutch type:
Wet, multiple-discTransmission:Primary reduction ratio:3.611 (65/18)
Final drive: Chain
