2012 YAMAHA XJ6-S check engine

PERIODIC MAINTENANCE AND ADJUSTMENT
6-42
6Engine overheating
WARNING
EWA10400
●
Do not remove the radiator cap when the engine and
radiator are hot. Scalding hot fluid and steam may be
blown out under pressure, which could cause serious injury. Be sure to wait until the engine has cooled.
●
After removing the radiator cap retaining bolt, place a thick rag, like a towel, over the radiator cap, and then
slowly rotate the cap counterclockwise to the detent to allow any residual pressure to escape. When the hissing
sound has stopped, press down on the cap while turning it counterclockwise, and then remove the cap.
TIPIf coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant
as soon as possible.
Wait until the
engine has cooled.
Check the coolant level in the
reservoir and radiator.
The coolant level
is OK.The coolant level is low.
Check the cooling system
for leakage.
Have a Yamaha dealer checkand repair the cooling system.Add coolant. (See TIP.)
Start the engine. If the engine overheats again,
have a
Yamaha dealer check
and repair the cooling system.
There is
leakage.
There is
no leakage.
U1PWEAE0.book Page 42 Tuesday, February 7, 2012 4:21 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-43
6
EAU52180
Checking the engine guards
and rear guards Check the guards for damage and the
mounting bolts for looseness. If the
guards are significantly bent or de-
formed, replace them.1. Engine guard
2. Rear guard21
U1PWEAE0.book Page 43 Tuesday, February 7, 2012 4:21 PM

MOTORCYCLE CARE AND STORAGE
7-4
7
2. Fill up the fuel tank and add fuel
stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
3. Perform the following steps to pro- tect the cylinders, piston rings, etc.
from corrosion.a. Remove the spark plug caps and spark plugs.
b. Pour a teaspoonful of engine oil into each spark plug bore.
c. Install the spark plug caps onto the spark plugs, and then place
the spark plugs on the cylinder
head so that the electrodes are
grounded. (This will limit spark-
ing during the next step.)
d. Turn the engine over several times with the starter. (This will
coat the cylinder walls with oil.)
WARNING! To prevent dam- age or injury from sparking,
make sure to ground the
spark plug electrodes while
turning the engine over.
[EWA10951]
e. Remove the spark plug caps from the spark plugs, and then
install the spark plugs and the
spark plug caps.
4. Lubricate all control cables and the pivoting points of all levers and
pedals as well as of the side-
stand/centerstand.
5. Check and, if necessary, correct the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
6. Cover the muffler outlet with a plastic bag to prevent moisture
from entering it.
7. Remove the battery and fully charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place [less
than 0 °C (30 °F) or more than 30
°C (90 °F)]. For more information
on storing the battery, see page
6-34.
TIPMake any necessary repairs before
storing the motorcycle.
U1PWEAE0.book Page 4 Tuesda y, February 7, 2012 4:21 PM

INDEXAABS ....................................................... 3-15
ABS warning light.................................... 3-7
Air filter element, replacing ................... 6-18
Anti-theft alarm (optional)...................... 3-11
Auxiliary light bulb ................................. 6-40BBattery................................................... 6-34
Brake and clutch levers, checking and lubricating ..................... 6-31
Brake and shift pedals, checking and lubricating ..................... 6-30
Brake fluid, changing ............................ 6-27
Brake fluid level, checking .................... 6-26
Brake lever ............................................ 3-14
Brake lever free play, checking ............. 6-24
Brake light switches .............................. 6-25
Brake pedal ........................................... 3-14CCables, checking and lubricating .......... 6-29
Care ........................................................ 7-1
Carrier ................................................... 3-22
Catalytic converter ................................ 3-18
Centerstand and sidestand, checking and lubricating ..................... 6-31
Clutch lever ........................................... 3-13
Clutch lever free play, adjusting ............ 6-23
Coolant.................................................. 6-14
Coolant temperature warning light .......... 3-4
Cowlings and panels, removing and installing ......................... 6-8DDimmer switch ...................................... 3-12
Drive chain, cleaning and lubricating .... 6-29 Drive chain slack .................................. 6-27
EEngine break-in ...................................... 5-3
Engine guards and
rear guards,
checking ............................................. 6-43
Engine idling speed .............................. 6-19
Engine oil and oil filter cartridge ........... 6-11
Engine stop switch................................ 3-12
Engine trouble warning light ................... 3-7FFront and rear brake pads, checking .... 6-25
Front fork, checking .............................. 6-32
Fuel....................................................... 3-16
Fuel consumption, tips for reducing........ 5-3
Fuel tank breather hose and
overflow hose ..................................... 3-17
Fuel tank cap ........................................ 3-16
Fuses, replacing ................................... 6-35HHandlebar switches .............................. 3-12
Hazard switch ....................................... 3-13
Headlight bulb, replacing ...................... 6-37
High beam indicator light ........................ 3-4
Horn switch ........................................... 3-12IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ................ 3-23
Immobilizer system ................................. 3-1
Immobilizer system indicator light........... 3-7
Indicator lights and warning lights .......... 3-4LLicense plate light bulb, replacing ........ 6-39MMain switch/steering lock........................ 3-2 Maintenance and lubrication, periodic..... 6-4
Maintenance, emission control system ... 6-3
Matte color, caution ................................. 7-1
Model label .............................................. 9-1
Multi-function meter unit .......................... 3-8
NNeutral indicator light .............................. 3-4OOil level warning light .............................. 3-4PParking .................................................... 5-4
Part locations .......................................... 2-1
Pass switch ........................................... 3-12
Patrol switch .......................................... 3-13RRear view mirrors .................................. 3-19SSafety information ................................... 1-1
Seat ....................................................... 3-18
Shifting .................................................... 5-2
Shift pedal ............................................. 3-14
Shock absorber assembly, adjusting .... 3-21
Sidecases.............................................. 3-20
Sidestand .............................................. 3-22
Siren switch ........................................... 3-13
Spark plugs, checking ........................... 6-10
Specifications .......................................... 8-1
Starting the engine .................................. 5-1
Start switch............................................ 3-12
Steering, checking................................. 6-33
Storage.................................................... 7-3
Swingarm pivots, lubricating ................. 6-32TTail/brake light bulb, replacing .............. 6-38
