2012 VOLVO XC70 bluetooth

05 Infotainment
Getting started
05

* Option/accessory, for more information, see Introduction.209 Steering wheel keypad
Standard steering wheel keypad
Left/right arrow keys: A short press moves
between preset radio stations or tracks on
a disc. Press and hold to search within
tracks or to tune to the next/previous
strong radio station.
Volume
EXIT: Go higher in the menu system, inter-
rupt the current function, reject an incom-
ing phone call or erase any characters
entered in the display. Press and hold to go
to the highest level in the current menu.
From the highest level in the current menu,
press and hold to go to the infotainment
system's main menu view (see page 208).
Thumb wheel, used to scroll in the menus
shown on the display. Press the thumb
wheel to e.g., confirm a menu selection or
to answer an incoming call on a Bluetooth-
connected cell phone.
Mute
Steering wheel keypad with voice control button2
Left/right arrow keys: A short press moves
between preset radio stations or tracks on
a disc. Press and hold to search within
tracks or to tune to the next/previous
strong radio station.
Volume
EXIT: Go higher in the menu system, inter-
rupt the current function, reject an incom-
ing phone call or erase any charactersentered in the display. A long press takes
you to the main menu view (see
page 208).
Thumb wheel, used to scroll in the menus
shown on the display. Press the thumb
wheel to e.g., confirm a menu selection or
to answer an incoming call on a Bluetooth-
connected cell phone.
Voice control (for operating BluetoothŸ-
connected cell phones and the optional
navigation system)
Rear control panel with headphone
sockets*
Headphones with an impedance of
16 – 32 ohm and sensitivity of 102 dB or higher
are recommended for best sound reproduc-
tion.
2Models equipped with the optional navigation system only

05 Infotainment
Getting started
05
210* Option/accessory, for more information, see Introduction.
Volume control (right/left sides)
Scroll/search forward and back
MODE – select: AM, FM1, FM2,HD
Radio3, Sirius1*, Sirius2*, Disc, USB,
iPod, Bluetooth, AUX and ON/OFF.
Headphones sockets (3.5 mm)
Activating/deactivatingThe control panel is activated by pressing
MODE when the audio system is switched on.
It is switched off automatically when the audio
system is switched off or by a long press on
MODE.
Scroll/search forward and backPress briefly on (2) to scroll between CD tracks/
audio files or to search for the next available
radio station.
Limitations
NOTE
•The sound source (AM, FM1, Disc,
etc.) being played through the infotain-
ment system's speakers cannot be con-
trolled from the rear control panel.
•In order to select and play an external
device using MODE, the device must be
connected to the infotainment system.
3U.S. models only.

05 Infotainment
General infotainment functions
05

* Option/accessory, for more information, see Introduction.211 FAV—storing a shortcut
The FAV button can be used to store frequently
used functions, making it possible to start the
stored function by simply pressing FAV. One
favorite (for example,
Equalizer) can be pro-
grammed for each of the following infotainment
system functions:
In RADIO mode
•AM
•FM1/FM2
•SIRIUS1/SIRIUS2*
In MEDIA mode
•DISC
•USB
•iPod
•Bluetooth*
•AUX
Favorites can also be stored for TEL, MY
CAR, CAM* and NAV*. See page 131 for a
description of the menu system.
To program a function on the FAV button:
1.
Select a mode (e.g., RADIO, MEDIA, etc.).
2.
Select a waveband or function (
AM, Disc,
etc.).
3.
Press and hold FAV until the mode/func-
tion's "favorite" menu is displayed.
4.
Turn TUNE to scroll through the list of
alternatives displayed and press OK/
MENU to confirm (store) your choice.
> The next time the infotainment system
mode (RADIO, MEDIA, etc.) is selected,
a short press on FAV will start the
stored function.
A favorite function can also be programmed
using the MY CAR menu system. See page
132 for more information.
INFO—displaying additional
information
In certain cases, more information may be
available (about a radio station, song, artist,
etc.) than is currently displayed on the screen.
Press the INFO button to display all of the
available information.

05 Infotainment
BluetoothŸŸ media
05
230
Streaming audio
IntroductionThe vehicle's media player is equipped with
BluetoothŸ and can play streaming audio files
from a BluetoothŸ device such as a cell phone
or personal digital assistant (PDA). Navigation
and control of the device can be done through
the vehicle's center console control panel or
the steering wheel keypad. On certain external
devices, it is also possible to change tracks
from the device.
In order to listen streaming audio, the vehicle's
media player must first be put in
Bluetoothmode. To do so, Press MEDIA several times
until Bluetooth is displayed. Release the but-
ton and wait several seconds or press OK/
MENU.
Choices can be made in the
Bluetooth menus
from the center console control panel or the
steering wheel keypad. See page 256 for addi-
tional information about navigating the various
menus.
NOTE
Any Bluetooth media players used must
support Audio/Video Remote Control Pro-
file (AVRCP) and Advanced Audio Distribu-
tion Profile (A2DP). The player must use
AVRCP version 1.3 and A2DP 1.2. If older
versions of these standards are used, cer-
tain features (e.g., scan or random) may not
function.
Not all cell phones or media players are fully
compatible with the vehicle's Bluetooth sys-
tem. A list of compatible devices is available
at you Volvo retailer or at www.volvo-
cars.us.
The vehicle's media player can only play audio
files through the BluetoothŸ function.
Overview
Center console control panel
VOL: Volume control
MEDIA button
TUNE: Turn to navigate among menu alter-
natives and folders shown in the display.
OK/MENU: Press to confirm your selec-
tion or access the menus.
EXIT: Press to go back in the menu struc-
ture or cancel a function.
Left/right arrow keys: Short press: change
tracks. Long press: fast forward/reverse
within a track. The arrow keys on the steer-
ing wheel keypad can be used in the same
way.
MEDIA menu selections can be made from the
center console or the steering wheel keypad.

05 Infotainment
BluetoothŸŸ media
05

231
See page 256 for more information about the
infotainment menu system.
Pairing and connecting an external
device
Before an external device can be connected, it
must be paired to the infotainment system. The
procedure for connecting an external device
varies, depending whether or not the device
has previously been paired to the infotainment
system. A maximum of 10 external devices can
be paired and each device only needs to be
paired once. To pair a device:
1.
Press MEDIA several times until
Bluetooth is displayed, release the button
and wait for several seconds or press OK/
MENU.
2.
Press OK/MENU.
>
When
Add device is displayed, press
OK/MENU.
3.
Be sure the external device's Bluetooth
Ÿ
function is turned on and that the device is
"discoverable." See the device's user's
guide if necessary.
4.
Press OK/MENU.
> The infotainment system will search for
external devices that are in range, which
may take several minutes. TheBluetooth
Ÿ-names of the devices found
will appear in the center console dis-
play.
5. Select the device to be paired and press
OK/MENU.
6. Using the external device’s keypad, enter
the digits shown in the audio system’s dis-
play and press the device's button used to
confirm a choice.
The external device will be automatically paired
and connected to the infotainment system.
Audio files can now be selected using the
/ buttons in the center console or on
the steering wheel keypad.
Automatic connection
When the BluetoothŸ function is active and the
most recently paired device is within range, it
is automatically connected. When the infotain-
ment system searches for the most recently
paired device, its name is shown in the display.
To connect another paired device, press
EXIT. See the following section for information
about switching to another device.
Switching to another deviceIt is possible to switch among paired
BluetoothŸ devices that are in the vehicle. To
do so:1.
Press MEDIA several times until
Bluetooth is displayed, release the button
and wait for several seconds or press OK/
MENU.
2.
Be sure the external device's Bluetooth
Ÿ
function is turned on and that the device is
"discoverable." See the devices user's
guide if necessary.
3.
Press OK/MENU.
4.
Turn TUNE to
Change Bluetooth
device and confirm by pressing OK/
MENU.
> After a short time, the external device's
name will appear in the display. If other
devices that have been paired are in
range, their names will also be dis-
played.
5. Select the device to be connected by turn-
ing TUNE and pressing OK/MENU to con-
firm.
> The external device will be connected to
the infotainment system.
Audio files can now be selected using the
/ buttons in the center console or on
the steering wheel keypad.
Removing a paired device1.
In Bluetooth mode, press OK/MENU.

05 Infotainment
BluetoothŸŸ media
05
232
2.
Turn TUNE to Remove Bluetooth
device and press OK/MENU.
3. Select the device to be removed by turning
TUNE and confirm by pressing OK/
MENU.
> A question asking if you would like to
remove the device will be displayed.
4.
Press OK/MENU to confirm or EXIT to
cancel.
Disconnecting an external deviceThe external device is automatically discon-
nected from the audio system if it is moved out
of range.
RandomThis function plays the audio files on the exter-
nal device in random order (shuffle). This func-
tion can be activated/deactivated under:
Bluetooth menu
Random
Press the
/ buttons on the center con-
sole or steering wheel keypad to change
tracks.
Scanning audio files on an external
device
This function plays the first ten seconds of
each audio file. This function can be activated/
deactivated under: Bluetooth menu
Scan.
BluetoothŸ version informationThis feature offers information about the
BluetoothŸ version installed in the vehicle's
infotainment system. This information can be
found under Bluetooth menu
Bluetooth
software version in car.

05 Infotainment
Bluetooth® hands-free connection
05

233 Introduction
System overview
Cell phone
Location of the microphone
Steering wheel keypad
Center console control panel and display
Bluetooth® hands-freeThis feature makes it possible to set up a wire-
less connection between a BluetoothŸ-ena-
bled cell phone and the vehicle’s infotainment
system. This enables the infotainment system
to function as a hands-free connection and
allows you to remote-control a number of the
phone’s functions. The microphone used by
this system is located near the driver's side sun
visor (2). The buttons and other controls on thecell phone can always be used regardless of
whether or not the phone is connected to the
hands-free system.
TEL menu selections can be made from the
center console or the steering wheel keypad.
See page 256 for more information about the
infotainment menu system.
NOTE
Not all cell phones are fully compatible with
the hands-free system. A list of compatible
phones is available at your Volvo retailer or
at www.volvocars.us
WARNING
Never use the hands-free feature or any
other device in your vehicle in a way that
distracts you from the task of driving safely.
Distraction can lead to a serious accident.
Compliance
FCC/IC common sentence
This device complies with Part 15 of FCC Rules
and RSS-Gen of IC Rules. Operation is subject
to the following two conditions: (1) this device
may not cause interference, and (2) this device
must accept any interference, including inter-
ference that may cause undesired operation of
this device.USA: FCC ID A269ZUA130
FCC WARNING
Changes or modifications not expressly
approved by the party responsible for compli-
ance could void the user’s authority to operate
the equipment.
IC RSS-GenThis equipment complies with FCC/IC radia-
tion exposure limits set forth for uncontrolled
equipment and meets the FCC radio frequency
(RF) Exposure Guidelines in Supplement C to
OET65 and RSS-102 of the IC radio frequency
(RF) Exposure rules. This equipment has very
low levels of RF energy that it deemed to com-
ply without maximum permissive exposure
evaluation (MPE). But it is desirable that it
should be installed and operated with at least
8 in. (20 cm) and more between the radiator
and person’s body (excluding extremities:
hands, wrists, feet and ankles).
Canada: IC 700BIAM2101

05 Infotainment
Bluetooth® hands-free connection
05
234
Bluetooth® functions in the center
console control panel
Character keys containing letters and
numbers for dialing numbers, adding
phone book entries, etc.
TEL: Press this button to activate/deacti-
vate the BluetoothŸ function.
TUNE: Turn to navigate among the menu
alternatives in the display.
OK/MENU: Press to answer an incoming
call, confirm your selection or access the
phone menus. Incoming calls can also be
answered by pressing the thumb wheel on
the steering wheel keypad.
EXIT: Press to end or reject calls, erase
characters that have been entered, end an
ongoing function. This function is also
available on the steering wheel keypad.
Getting started
Use the controls on the steering wheel keypad
and in the center console to access, navigate
and make selections in the hands-free sys-
tem’s menus.
Activating/deactivatingA short press on the TEL button in the center
console activates the hands-free system. The
symbol in the display indicates that the
hands-free system is active.
A long press on the TEL button deactivates the
hands-free system and disconnects the cell
phone.
Connecting cell phonesThe procedure for connecting a cell phone var-
ies, depending on the phone itself and on
whether or not the phone has been previously
paired with the infotainment system (see page
231 for instructions on pairing an external
device).
There are two ways of pairing a cell phone to
the hands-free system for the first time:
Method 1: using the vehicle's menus
1.
Activate the cell phone’s Bluetooth
Ÿ func-
tion to make the phone discoverable (refer
to the phone’s owner’s manual if neces-
sary) or go to www.volvocars.com2.
Activate the vehicle’s Bluetooth
Ÿ hands-
free system by briefly pressing the TEL
button. Continue by pressing OK/MENU.
3.
Select
Change phone and press OK/
MENU.
>
Add phone will be displayed. If other
cell phones have already been paired
with the infotainment system, their
names will also be displayed. Press OK/
MENU.
4. With the cell phone in discoverable mode,
press OK/MENU.
> The infotainment system will search for
cell phones that are in range, which
takes approximately 30 seconds. Any
phones detected will be displayed with
their Bluetooth
Ÿ names. The hands-free
system’s BluetoothŸ name will appear in
the cell phone’s display as My Volvo
Car.
5. Select one of the cell phones shown in the
center console display.
6. Using the cell phone’s keypad, enter the
digits shown in the center console display
and press the button on the cell phone
used to confirm a choice.
