08 Maintenance and specifications
Vehicle care
08
344
CAUTION
Volvo does not recommend the use of long-
life or durable paint protection coatings,
some of which may claim to prevent pitting,
fading, oxidation, etc. These coatings have
not been tested by Volvo for compatibility
with your vehicle's clear coat. Some of them
may cause the clear coat to soften, crack,
or cloud. Damage caused by application of
paint protection coatings may not be cov-
ered under your vehicle's paint warranty.
Cleaning the interior
Only use cleaning agents and car care prod-
ucts recommended by Volvo. Clean regularly
and follow the instructions included with the
car care product.
Upholstery care
Fabric
Clean with soapy water or a detergent. For
more difficult spots caused by oil, ice cream,
shoe polish, grease, etc., use a clothing/fabric
stain remover. Consult your Volvo retailer.
AlcanteraTM suede-like materialSuede-like upholstery can be cleaned with a
soft cloth and mild soap solution.
Leather careVolvo's leather upholstery is manufactured
with a protectant to repel soiling. Over time,sunlight, grease and dirt can break down the
protection. Staining, cracking, scuffing, and
fading can result.
Volvo offers an easy-to-use, non-greasy
leather care kit formulated to clean and beau-
tify your vehicle's leather, and to renew the
protective qualities of its finish. The cleaner
removes dirt and oil buildup. The light cream
protectant restores a barrier against soil and
sunlight.
Volvo also offers a special leather softener that
should be applied after the cleaner and pro-
tectant. It leaves leather soft and smooth, and
reduces friction between leather and other fin-
ishes in the vehicle.
Volvo recommends cleaning, protecting and
conditioning your vehicle's leather two to four
times a year. Ask your Volvo retailer about
Leather Care Kit 951 0251 and Leather Soft-
ener 943 7429.
Cleaning leather upholstery1. Pour leather cleaner on a damp sponge
and squeeze it until the cleaner foams.
2. Apply the foam to the stain by moving the
sponge with circular movements.
3. Dampen the stain thoroughly with the
sponge. Let the sponge absorb the stain,
do not rub.4. Dry the stain with soft paper towels or a
towel, and allow the leather to dry com-
pletely.
Protecting leather upholstery1. Put a small amount of protectant cream on
a cloth and apply a thin coating of cream
to the upholstery with light circular move-
ments.
2. Allow the leather to dry for 20 minutes.
This will help the leather resist staining and
protect against sunlight's harmful UV rays.

08 Maintenance and specifications
Vehicle care
08

345
CAUTION
•Under no circumstances should gaso-
line, naphtha or similar cleaning agents
be used on the plastic or the leather
since these can cause damage.
•Take extra care when removing stains
such as ink or lipstick since the coloring
can spread.
•Use solvents sparingly. Too much sol-
vent can damage the seat padding.
•Start from the outside of the stain and
work toward the center.
•Sharp objects (e.g. pencils or pens in a
pocket) or Velcro fasteners on clothing
may damage the textile upholstery.
•Clothing that is not colorfast, such as
new jeans or suede garments, may stain
the upholstery.
Cleaning the seat beltsClean only with lukewarm water and a mild
soap solution.
Cleaning floor matsThe floor mats should be vacuumed or brushed
clean regularly, especially during winter when
they should be taken out for drying. Spots on
textile mats can be removed with a mild deter-gent. For best protection in winter, Volvo rec-
ommends the use of Volvo rubber floor mats.
Consult your Volvo retailer.
Spots on interior plastic, metal, or wood
surfaces
Cleaning interior plastic components should
be done with a cleaning agent specially
designed for this purpose. Consult your Volvo
retailer.
Touching up paintwork
Paint code on the model plate1
Paint damage requires immediate attention to
avoid rusting. Make it a habit to check the finish
regularly, for instance washing the vehicle.
Touch-up if necessary.Paint repairs require special equipment and
skill. Contact your Volvo retailer for any exten-
sive damage.
Minor scratches can be repaired by using
Volvo touch-up paint.
Color codeMake sure you have the right color. The color
code number is stated on the model plate.
Minor stone chips and scratchesMaterial:
•Primer – can
•Paint – touch-up pen
•Brush
•Masking tape
If the stone chip has not gone down to the bare
metal and an undamaged color coat remains,
you can add paint immediately after removing
dirt.
NOTE
When touching up the vehicle, it should be
clean and dry. The surface temperature
should be above 60 °F (15 °C).
1see page 350 for the location of the model plate.

09 Specifications
Specifications 09
356
Engine oil
Engine oil must meet the minimum ILSAC
specification GF-4, API SL, or ACEA A1/B1.
Lower quality oils may not offer the same fuel
economy, engine performance, or engine pro-
tection.
Volvo recommends Castrol.
Depending on your driving habits, premium or
synthetic oils may provide superior fuel econ-
omy and engine protection. Consult your Volvo
retailer for recommendations on premium or
synthetic oils.
Oil additives must not be used.
Synthetic oil is not used when the oil is
changed at the normal maintenance services.
This oil is only used at customer request, at
additional charge. Please consult your Volvo
retailer.
Oil viscosityIncorrect viscosity oil can shorten engine life
under normal use. SAE 5W-30 will providegood fuel economy and engine protection. See
the viscosity chart.
G023491
Viscosity chart
Extreme engine operationSynthetic oils meeting SAE 0W-30 or 0W-40
and complying with oil quality requirements are
recommended for driving in areas of sustained
temperature extremes (hot or cold), when tow-
ing a trailer over long distances, and for pro-
longed driving in mountainous areas.
American Petroleum Institute (API)
symbol
G022917
The API Service Symbol "donut" is divided into
three parts:
•The upper section describes the oil's per-
formance level.
•The center identifies the oil's viscosity.
•The lower section indicates whether the oil
has demonstrated energy-conserving
properties in a standard test in comparison
to a reference oil.

10 Index
10
366
Driver alert............................................... 180
Driver distraction warning.......................... 13
Driving economically................................ 262
Driving in cold weather............................ 264
Driving through water..............................263
E
ECC.................................................144, 145
Economical driving.................................. 262
Electric parking brake.............................. 122
Electronic Climate Control.......142, 144, 145
air distribution table............................ 146
Interior Air Quality System.................. 145
Emergency locking retractor...................... 38
Emergency starting.................................. 114
Emergency towing...........................281, 282
Emission inspection readiness................ 315
Engine
overheating........................................... 79
specifications...................................... 354
starting................................................ 112
switching off....................................... 114
Engine compartment overview................317Engine Drag Control (EDC)......................149
Engine oil
checking............................................. 318
low pressure warning light.............. 77, 78
specifications...................................... 356
volumes.............................................. 357
Environment............................................... 12
Eyelets for anchoring loads..................... 273
F
Federal Clean Air Act............................... 314
Floor mats
cleaning.............................................. 345
placing correctly................................. 112
Fluid specifications.................................. 357
Fog lights
front/rear............................................... 94
rear...................................................... 326
Four C (active chassis system)................151
Front airbags.............................................. 22
disconnecting passenger’s side air-
bag.................................................. 26, 27
Front park assist.............................. 186, 188
Front seats...........................................84, 86Fuel filler cap........................................... 269
Fuel filler door, opening........................... 268
Fuel level warning light.............................. 77
Fuel requirements............................ 266, 267
Fuel tank volume.....................................357
Fuses...............................334, 335, 338, 341
G
Garage door opener
HomeLink® Wireless Control System. 109
Gasoline requirements............................. 267
Gas tank volume...................................... 357
Gauges...................................................... 75
Geartronic................................................ 117
Geartronic automatic transmission.. 116, 117
Generator warning light............................. 78
Glossary of tire terminology..................... 294
Grocery bag holder.................................. 273
Gross vehicle weight...............................295

10 Index
10
371
improving economy............................ 286
inflation pressure................................ 289
inflation pressure table.......................291
load ratings......................................... 290
rotation............................................... 287
snow...................................................298
spare................................................... 299
specifications...................................... 290
speed ratings...................................... 290
storing................................................. 287
studded............................................... 298
tire pressure monitoring system......... 309
tread wear indicator............................ 288
uniform tire quality grading................. 297
Top tether anchors (child restraint sys-
tems).......................................................... 48
Touching up paint.................................... 345
Towing a trailer................................278, 279
trailer hitch.......................................... 279
Towing the vehicle........................... 281, 282
Traction control........................................ 149
Trailer towing...................................278, 279
trailer hitch.......................................... 279Transmission
general description.....................116, 117
oil........................................................ 357
shiftlock override................................ 117
Tread wear indicator................................ 288
Trip computer.......................................... 147
Trip odometers.......................................... 80
Trips, long distance................................. 264
Turn signals............................................... 95
changing bulbs................................... 325
indicator lights...................................... 77
Two-stage booster cushion....................... 49
U
Uniform Tire Quality Grading...................297
Unlocking the tailgate................................ 67
Unlocking the vehicle..........................58, 66
Upholstery care....................................... 344
V
Vanity mirror............................................ 200
changing bulbs................................... 327
Vehicle dimensions.................................. 352
Vehicle Event Data..................................... 11
Vehicle loading................................271, 295
roof loads............................................ 274
Vehicle maintenance................................ 314
performed by the owner.....................315
Vehicle weights........................................ 353
Voice control
cell phones......................................... 241
Volvo and the environment........................ 12
Volvo maintenance.................................. 314
Volvo On Call Roadside Assistance........ 362
Volvo programs.......................................362
Volvo Sensus........................................... 130
W
Warning flashers, hazard........................... 94
Warning lights.......................... 75, 76, 77, 78
Warning symbol......................................... 79
