08 Maintenance and service
Fuses
08

* Option/accessory, for more information, see Introduction.339
Box AFunctionA
Folding head restraint*15
Infotainment control module5
Audio control module*
Digital radio*, TV*10
Audio15
Telematics*, Bluetooth*5
--
Sun roof*, Interior lighting
roof, Climate sensor5
12 V socket, tunnel console15
Seat heating, rear right*15
Seat heating, rear left*15
--
Seat heating (passenger
side)15
Seat heating (driver's side)15
Box AFunctionA
Parking assistance*, Park-
ing camera*, Towbar control
module *
BLIS*5
AWD control module*10
Active chassis Four-C*10
Box BFunctionA
Rear window wiper15
--
Interior lighting, Driver's
door control panel, power
windows, Power seats,
front*, Remote controlled
garage door opener*7.5
Information display (DIM)5
Adaptive cruise control,
ACC*, collision warning sys-
tem*10
Interior lighting, Rain sensor7.5
Steering wheel module7.5
Box BFunctionA
Central locking system, fuel
filler flap10
Rear window washer15
Windscreen washers15
Unlocking, tailgate10
--
Fuel pump20
Climate panel5
Steering lock15
Siren alarm*, Data link con-
nector OBDII5
--
Airbags10
Collision warning system5
Accelerator pedal, PTC ele-
ment air preheater*, Dim-
ming, interior rearview mir-
ror*, Seat heating, rear*7.5
