02 Locks and alarm
Locks
02

69
can be turned on or off by pressing MY CAR
and going to Car settings
Lock settings
Automatic door locking. See page 133 for
a description of the menu system.
Glove compartment
The glove compartment can only be locked
and unlocked using the detachable key blade
in the remote key. See page 59 for information
on removing the key blade from the remote
key.
Insert the key blade in the glove compart-
ment lock.
Turn the key blade 90 degrees clockwise.
Remove the key blade from the lock.
Opening the trunk manually
The trunk is held closed by an electronic lock-
ing mechanism. To open:
1. Press lightly on the rubberized plate under
the handle to release the lock.
2. Lift the handle to open the trunk lid.
CAUTION
•When pressing the rubberized plate,
only light pressure is necessary to
release the trunk's electronic locking
mechanism.
•When opening the trunk lid, pull it up
using the handle. Too much pressure on
the rubberized plate can damage its
electrical connections.
Locking/unlocking the trunk
Trunk unlock button on the remote key
Unlocking the trunk with the remote key
Press the trunk unlock button on the
remote.
Press once: This unlocks but does not open
the trunk. The trunk can then be opened by
pressing the rubber plate near the trunk lock. If
the trunk is not opened within two minutes it
will automatically relock and the alarm will be
rearmed.
Press twice: This both unlocks the trunk and
pops it open slightly.
NOTE
Any excess weight (snow, etc.) on the trunk
lid may prevent it from opening.

03 Your driving environment
Instruments and controls
03
84
Reminder – doors not closedIf one of the doors, the hood or trunk lid is not
closed properly, the information or warning
symbol comes on together with an explanatory
text message in the instrument panel. Stop the
vehicle in a safe place as soon as possible and
close the door, hood or trunk.
If the vehicle is driven at a speed
lower than approximately 5 mph
(7 km/h), the information symbol comes on.
If the vehicle is driven at a speed
higher than approximately 5 mph
(7 km/h), the warning symbol comes on.
Trip odometers
Trip odometers and reset button
Odometer display
Button for toggling between T1 and T2,
and for resetting the odometer
The trip odometers are used to measure short
distances. A short press the button toggles
between the two trip odometers
T1 and T2. A
long press (more than 2 seconds) resets an
active trip odometer to zero. The distance is
shown in the display.
Clock
Clock and setting control
Display
Control for setting the clockTurn the control clockwise/counterclockwise
to set the time. The set time is shown in the
information display.
The clock may be temporarily replaced by a
symbol in conjunction with a message, see
page 131.
Setting the clock in MY CARIn addition to setting the clock manually as
described above, it can also be set in the MY
CAR menu system. See page 133 for addi-
tional information about these menus.
1.
Go to SettingsSystem options
Time.
2.
The hour box will be selected. Press OK to
activate this box.

04 Comfort and driving pleasure
Volvo Sensus
04
130* Option/accessory, for more information, see Introduction.
Introduction
Center console control panel
Volvo Navigation System (VNS)* – NAV:
see the separate VNS manual for operating
instructions.
Infotainment (RADIO, MEDIA, TEL*): see
the infotainment system overview begin-
ning on page 206.
Vehicle-related settings - MY CAR: see
page 133.
Park assist camera - CAM*: see
page 191.
Climate system: see page 139.
Volvo Sensus is the operating system in your
vehicle providing a coordinated interface for a
number of functions such as the individualized
settings that can be made in the MY CARmenus, the climate and infotainment systems
as well as other options such as the park assist
camera(s), etc.
Volvo Sensus uses the screen in the center
instrument panel to display information and
selections are made using this panel’s controls
and buttons. Certain features can also be con-
trolled using the steering wheel keypad.
Press MY CAR to present all of the available
settings related to driving and/or controlling
the vehicle, such as City Safety, setting the
clock, lock settings, etc.
Press RADIO, MEDIA, TEL, NAV* and CAM*
to change a source and to activated systems
or functions such as AM, FM1, CD, DVD, Blue-
tooth, navigation* and the park assist camera
*.
See the respective sections in this manual for
more detailed information about your vehicle's
various features and functions.

04 Comfort and driving pleasure
The MY CAR menus
04

133 Introduction
The menu system provides access to
menus for operating many of the vehi-
cle's functions, such as setting the
clock, door mirrors, locks, etc.
Navigating in the menus is done using the but-
tons on the center console control panel or with
the right-side steering wheel keypad.
Some of the features mentioned in this section
are optional.
Operation
Center console controls
Center console controls for menu navigation
Press MY CAR to access the My Car
menus.
Press OK/MENU to select a highlighted
selection or to store a certain function in
the system's memory.
Turn to navigate up/down among menu
selections.
EXIT
EXIT functionsEXIT can be used to go back in the menu
structure or to cancel the most recent selec-
tion. The results of pressing EXIT vary,
depending on where you are in the menu struc-
ture.
•Press EXIT briefly to go back one step at a
time in the current menu.
•Press and hold EXIT to go to the main MY
CAR menu.
•From the main MY CAR menu, press and
hold EXIT to go to the infotainment sys-
tem's main view. See page 208 for addi-
tional information.
Steering wheel keypad
The keypad varies according to the vehicle's
equipment
Turn the thumb wheel to go up/down
among menu selections. Press the thumb
wheel to make a selection or store a func-
tion in the system's memory.
EXIT.

05 Infotainment
Bluetooth® hands-free connection
05
234
Method 2: using the cell phone’s menus
1. Activate the hands-free system by briefly
pressing the TEL button in the center con-
sole. If there is a cell phone connected,
disconnect it from the hands-free system.
2. Make the vehicle discoverable via the
Bluetooth
Ÿ function by pressing OK/
MENU and activating the menu selection
Phone settings
Discoverable.
3. Perform a search with the cell phone's
Bluetooth
Ÿ function (see the cell phone's
user's guide if necessary).
4.
Select
My Volvo Car in the list of devices
shown in the cell phone’s display.
5. When prompted, enter a PIN code of your
choice in the cell phone using the cell
phone's keypad. Enter the same PIN code
in the infotainment system using the sys-
tem's keypad in the center console.
6.
Connect to
My Volvo Car from the cell
phone.
The cell phone will be paired (registered) and
will be connected automatically to the infotain-
ment system. For more information on pairing
and connecting a cell phone, see page 236.
Making a call1.
Ensure that is shown at the top of the
center console display and that the hands-
free function is in telephone mode.
2. Dial the desired phone number using the
center console keypad or use the speed
dial function (see page 239). In normal
view (see page 207 for information about
the various display views). It is also possi-
ble to turn TUNE clockwise to access the
phone book and then counter-clockwise
for the call list. See page 236 for more
information about the phone book.
3.
Press OK/MENU
End or reject a call by pressing EXIT.
Disconnecting the cell phoneThe cell phone is automatically disconnected
from the infotainment system if it is moved out
of range.
The cell phone can be manually disconnected
from the hands-free system by pressing and
holding TEL or in phone mode, going to Phone
menu
Disconnect phone. See also page
235 for more information about connections.
The hands-free system is also deactivated
when the ignition is switched off (or if the
driver’s door is opened on vehicles equipped
with the optional keyless drive).When the cell phone is disconnected from the
hands-free system, a call in progress can be
continued using the cell phone’s own speaker
and microphone.
Even if the cell phone has been disconnected
manually, some phones may reconnect auto-
matically to the most recently used hands-free
unit, for example when a new call is initiated.
Handling calls
Incoming calls
Press OK/MENU (or the thumb wheel on
the steering wheel keypad) to answer a
call, even if the infotainment system is cur-
rently in another mode (e.g.,
RADIO orMEDIA).
Press EXIT to reject a call.
Automatic answerThis function means that incoming calls will be
answered automatically. Activate or deactivate
the function in the menu system under Phone
menu
Call optionsAuto answer.
Call settingsWhile a call is in progress, press OK/MENU or
the thumb wheel on the steering wheel keypad
to access the following functions:

05 Infotainment
Bluetooth® hands-free connection
05

235
•Mute: mute the infotainment system’s
microphone.
•Mobile phone: transfer the call from
hands-free to the cell phone. On certain
cell phones, the connection will be broken,
which is normal. The hands-free function
will ask if you would like to reconnect.
•Dial number: dial a third party during an
ongoing call using the number keys (the
current call will be put on hold).
Call listsCall lists are copied to the hands-free function
each time a cell phone is connected and the
lists are updated while the phone is connected.
In normal view, turn TUNE counter-clockwise
to see the
All calls list.
In phone mode, the various call lists can be
displayed in Phone menu
Call lists:
•All calls
•Missed calls
•Answered calls
•Dialed calls (certain cell phones show this
list in reverse order)
•Call duration
If no number has been stored, this menu can
be accessed by pressing and holding 1.
Voice mailIn normal view, a speed dial number for voice
mail can be programmed and accessed by
pressing and holding 1.
The number for voice mail can be changed in
phone mode in Phone menu
Call options
Voicemail numberChange number.
Sound settings
Call volumeCall volume can be only be adjusted during a
call. Use the buttons in the steering wheel key-
pad or the infotainment system’s VOL control.
Infotainment system volumeIf no phone call is in progress, volume for the
infotainment system can be adjusted in the
normal way with the infotainment system's
VOL control or from the steering wheel keypad.
Infotainment system sound can be automati-
cally muted when a phone call is received in
Phone menu
Phone settingsSounds
and volume
Mute radio/media.
Ringing volume
In phone mode, go to Phone menuPhone
settings
Sounds and volumeRingvolume and adjust the volume by turning
VOL. Save the setting by pressing EXIT.
Ringing tonesThe hands-free system’s integrated ringing
tones can be selected in Phone menu
Phone settingsSounds and volume
Ring signalsRing signal 1, etc.
NOTE
The connected cell phone’s ring tone may
not be switched off when one of the hands-
free system's ringing tones is used.
If you prefer to use the connected cell phone’s
ring tone1, go to Phone menuPhone
settings
Sounds and volumeRing
signals
Mobile phone ring signal.
More information about pairing and
connecting cell phones
A maximum of 10 cell phones can be paired
with the hands-free system. Pairing only needs
to be done once for each phone. After pairing,
the cell phone no longer needs to be in sight or
discoverable. Only one cell phone can be
actively connected to hands-free at a time.
1Not supported by all cell phones.

06 During your trip
Refueling
06

257
Opening/closing the fuel cap
Fuel vapor expands in hot weather. Open the
filler cap slowly.
After refueling, close the fuel filler cap by turn-
ing it clockwise until it clicks into place.
CAUTION
•Do not refuel with the engine running2.
Turn the ignition off or to position I. If the
ignition is on, an incorrect reading could
occur in the fuel gauge.
•Avoid overfilling the fuel tank. Do not
press the handle on the filler nozzle
more than one extra time. Too much fuel
in the tank in hot weather conditions can
cause the fuel to overflow. Overfilling
could also cause damage to the emis-
sion control systems.
Emission controls
Three-way catalytic converter
•Keep your engine properly tuned. Certain
engine malfunctions, particularly involving
the electrical, fuel or distributor ignition
systems, may cause unusually high three-
way catalytic converter temperatures. Do
not continue to operate your vehicle if you
detect engine misfire, noticeable loss of
power or other unusual operating condi-
tions, such as engine overheating or back-
firing. A properly tuned engine will helpavoid malfunctions that could damage the
three-way catalytic converter.
•Do not park your vehicle over combustible
materials, such as grass or leaves, which
can come into contact with the hot exhaust
system and cause such materials to ignite
under certain wind and weather condi-
tions.
•Excessive starter cranking (in excess of
one minute), or an intermittently firing or
flooded engine can cause three-way cata-
lytic converter or exhaust system over-
heating.
•Remember that tampering or unauthorized
modifications to the engine, the Engine
Control Module, or the vehicle may be ille-
gal and can cause three-way catalytic con-
verter or exhaust system overheating. This
includes: altering fuel injection settings or
components, altering emission system
components or location or removing com-
ponents, and/or repeated use of leaded
fuel.
NOTE
Unleaded fuel is required for vehicles with
three-way catalytic converters.
2If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's
performance will not be affected. Use only Volvo original or approved fuel filler caps.

10 Index
10
349
Bulbs
headlights...................................306, 308
introduction......................................... 306
license plate lights.............................. 310
specifications...................................... 311
trunk lighting....................................... 311
C
Camera, Park Assist................................ 191
Capacity weight....................................... 279
Catalytic converter................................... 257
Cell phone, hands-free connection......... 232
Cell phone voice control.......................... 240
Central locking system, introduction......... 54
Chains...................................................... 282
Check engine light..................................... 80
Child restraints
recalls and registration......................... 41
Child restraint systems.............................. 42
booster cushions.................................. 48
convertible seats.................................. 46
infant seats........................................... 44
ISOFIX/LATCH anchors........................ 49
top tether anchors................................ 50Child safety................................................ 39
booster cushions.................................. 48
child restraint systems.......................... 42
convertible seats.................................. 46
infant seats........................................... 44
Child safety locks...................................... 51
City Safety™............................................ 168
Climate system........................................ 144
air distribution............................. 140, 146
air vents.............................................. 141
Interior Air Quality System.................. 140
introduction......................................... 139
passenger compartment filter............ 140
refrigerant........................................... 139
Clock, setting............................................. 84
Cold weather driving................................ 252
Collision warning system.................173, 174
Compass in rearview mirror..................... 108
Conserving electrical current................... 251
Controls, center console.......................... 244
Convertible seats....................................... 46
Coolant............................................304, 341
Cooling system, general information....... 251
Corner Traction Control........................... 149
Courtesy lighting................................99, 100Crash event data....................................... 11
Crash mode............................................... 38
Cruise control..................................153, 154
adaptive.............................................. 155
Curb weight............................................. 279
Current, conserving................................. 251D
Defroster.................................................. 144
Detachable key blade..........................59, 62
Disconnecting the front passenger’s air-
bag....................................................... 29, 30
Dome lighting..................................... 99, 100
Door mirrors............................................. 106
Driver alert............................................... 181
Driver distraction warning.......................... 14
Driving economically................................ 250
Driving in cold weather............................ 252
Driving through water..............................251
