2012 VOLKSWAGEN JETTA jack

Side view

Fig. 1 Vehicle side overview.
Key to fig. 1:
(1) Fuel filler flap
(2) Roof antenna (if equipped)
(3) Outside door handles
(4) Outside mirror
– Additional turn signal light (if equipped)
(5) Lift points for the jack

WARNING
Not wearing a safety belt or wearing an improperly positioned safety belt increases the risk of severe personal injury or death. Safety belts offer optimum protection only when they are used properly.
x Properly worn safety belts are the single most effective means of reducing the risk of serious injury and death in a collision or other accident. For this reason, always wear your safety belt properly and make sure all passengers wear their safety belts properly as well whenever the vehicle is moving.
x The driver must always make sure that every person in the vehicle is properly seated on a seat of his or her own, properly fastens the safety belts belonging to that seat before the vehicle starts to move, and keeps the belts properly fastened while riding in the vehicle. This applies even when just driving around town. Therefore, always wear your safety belts and make sure that everybody in your vehicle is properly restrained.
x Always secure children in the vehicle with a restraint system appropriate for their age, weight and height, Child safety and child restraints.
x Always fasten safety belts correctly before driving off and make sure that all passengers are properly restrained.
x Never attach the safety belt to the buckle of another seat. Attaching the safety belt to the wrong buckle will reduce safety belt effectiveness and can cause serious personal injury.
x Never let any objects or liquids get into the safety belt latch and prevent it from working properly.
x Never remove a safety belt while the vehicle is moving. Doing so will increase your risk of being injured or killed.
x Never strap more than one person, including small children, into any single safety belt.
x Never let children or babies ride sitting on your lap, and never place a safety belt over a child sitting on your lap.
x Never wear belts over rigid or breakable objects in or on your clothing, such as eyeglass-es, pens, keys, etc., as these may cause injury.
x Several layers of heavy clothing (such as a coat worn over top of a sports jacket) may interfere with proper positioning of the safety belt and reduce the overall effectiveness of the system.
x Never use comfort clips or devices that create slack in the shoulder belt. However, special clips may be required for the correct use of some child restraint systems.
x Safety belts offer optimum protection only when the seat backrest is upright and belts are correctly positioned on the body.

Fig. 100 Inside the front center armrest storage compartment: MDI (MEDIA-IN) jack.

Holders for pen and coins
There are holders for a pen and for coins in the glove compartment cover (2).
Button in the glove compartment
The Tire Pressure Monitoring System (TPMS) SET button is also located in the glove compartment (3).
WARNING
An open glove compartment door can increase the risk of serious injury during sudden braking or driving maneuvers or in a crash.
x Always keep the glove compartment closed while the vehicle is moving.
NOTICE
Vehicles equipped with a Media Device Interface (MDI)/(MEDIA-IN) jack .170, Storage compartment in the front center armrest also have an electrical connection in the glove compartment that connects the MDI to the vehicle electronics. If the cable in the glove compartment is unplugged, the MDI will not work.
NOTICE
In some vehicle models, design considerations have made it necessary to have openings in the glove compartment behind the Owner's Manual slot, for example. Small items may fall through these openings and get behind the instrument panel. This can cause unusual noises and damage the vehicle. Never put any small objects in the glove compartment for this reason.
Applicable only in Canada
Glove compartment

Fig. 104 On the passenger side: Glove compartment.

311
Lift points for the vehicle

Fig. 146 Front lift point for workshop hoist or floor jack.

Fig. 147 Rear lift point for workshop hoist or floor jack.
The vehicle may only be raised at the lift points shown in illustrations ⇒ fig. 146 and ⇒ fig. 147. If the
vehicle is lifted at different points, vehicle damage ⇒  and serious injuries may occur ⇒ .
Workshop hoists that use fluid cushions (receiving platforms) must not be used for lifting the vehicle.
There are many precautions that have to be followed when lifting a vehicle on a workshop hoist or floor jack. Do not try to lift a vehicle on a workshop hoist or floor jack unless you have the training, knowledge, and experience to be able to do so safely.
Information about lifting the vehicle with the vehicle jack, Lifting the vehicle with the vehicle jack.

WARNING
Improperly lifting your vehicle with a workshop hoist or a floor jack can cause the vehicle to fall off and cause serious personal injury.
x Always read and heed the operating instructions from the floor jack manufacturer and legal regulations if necessary before using the floor jack to lift the vehicle.
x Never let anyone stay in the vehicle when it is being lifted or when it is off the ground.
x Always lift your vehicle only at the designated lift points shown in the illustrations
⇒ fig. 146 and ⇒ fig. 147. Not using the designated lift points can cause the vehicle to fall off the floor jack when heavy parts such as the engine or transmission are removed.
x Always make sure that the vehicle's lift points lie as flat as possible and centered on the carrier plates of the floor jack.
x Never start the engine when you have raised the vehicle on the floor jack. The engine vibrations and vehicle movements could knock the vehicle off the floor jack.
x If you must work under a vehicle raised on a floor jack, always make sure that the vehicle is safely supported on safety stands intended for that purpose that are strong enough to support the weight of the vehicle.
x Never use the floor jack as a ladder or step ladder.
x Always make sure that the weight of the vehicle is not heavier than the lifting capacity of the floor jack and safety stands being used.
NOTICE
x To help prevent serious vehicle damage, never lift the vehicle by the engine oil pan, transmission housing, or by the front or rear axles or suspension.
x To help prevent damage to the underbody or chassis, always insert a rubber pad between the hoist and the lifting points. In addition make sure the lifting arms have enough clearance.
x The lifting arms should not touch side sills or other parts of the vehicle.

325
Contents of the vehicle tool kit ⇒ fig. 159
(1) Screwdriver with a hexagonal socket in the handle for removing or inserting previously loosened wheel bolts. The screwdriver blade is reversible. The screwdriver may be stored under the lug wrench.
(2) Screw-in towing eye.
(3) Hubcap puller clip for removing hubcaps, wheel covers, or wheel bolt caps.
(4) Jack. Before putting the jack back in the foam insert, be sure to completely crank the jack down to its original position.
(5) Lug wrench.
(6) Crank.

331
WARNING
Changing a wheel, especially on the side of the road, can be dangerous. To help reduce the risk of serious personal injury:
x Always stop the vehicle as soon as it is safe to do so. Move the vehicle a safe distance off the road where it is safe to change the wheel.
x Always make sure that all passengers, especially children, are in a safe place outside the vehicle and away from the vehicle and traffic (such as behind a guard rail).
x Turn on the emergency flashers and set up another warning device about 25 yards (25 meters) behind the vehicle to warn approaching traffic.
x Change a wheel by yourself only if you are familiar with the necessary steps. Otherwise, get expert assistance.
x Always switch the engine off, firmly apply the parking brake, and shift the transmission into Park (P) (automatic transmission) or any gear (manual only) to help prevent the vehicle from moving suddenly and slipping off the jack.
x Always make sure that the ground is level and firm. If necessary, place the jack on a large and sturdy board or on a similar ground support.
x Always block the wheel diagonally opposite the wheel being changed with chocks or other similar things.
x If you are towing a trailer, always unhitch it from your vehicle before starting to change the wheel. Always apply the trailer brakes firmly and make sure the trailer cannot move unintentionally.
x Always use proper and undamaged tools when changing a wheel.
x Once a wheel is lifted off the ground, having the transmission in Park (P) or in gear will not prevent sudden vehicle movement.
x Always use a jack that has been approved by the manufacturer for your vehicle. Never use other jacks, even if they have been approved for use on other Volkswagen models.
x To reduce the risk of losing control, crashes, and serious personal injuries, never loosen the screws on rims with threaded rim rings.
x After changing a wheel, have the wheel bolt tightening torque checked with an accurate torque wrench.
x After changing a wheel or tire, reset the Tire Pressure Monitoring System, Tire Pressure Monitoring System (TPMS).
Preparations for changing a wheel
