2012 VOLKSWAGEN JETTA Bulb

Replacing light bulbs in the front bumper

Fig. 173 In front right bumper: Removing the light assembly.

Fig. 174 Replacing a light bulb in the fog light.

349
Please carry out each step only in the order specified:
10. Slip the headlight into the mounts (small arrows) and fold rearward.
11. Screw the fastening screw ⇒ fig. 173 (1) tightly with the screwdriver.
12. Insert the cover into the bumper .
Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
Replacing taillight bulbs in the luggage compartment lid

Fig. 175 In the luggage compartment lid. A: Removing the taillight cover. B: Removing the taillight assembly.

Fig. 176 Taillight assembly. A: Removing the bulb holder. B: Removing the light bulbs.

Please carry out each step only in the order specified:
3. Using the flat blade of the screwdriver from the vehicle tool kit carefully pry the cover
off the slot ⇒ fig. 175 A (1).
4. Unscrew the fastening screws B (3) with your hand and carefully remove the taillight assembly from the luggage compartment lid.
5. Press together the release tabs for the connector plug B (2) in the direction of the arrow and pull the connector plug off.
6. Unlock the bulb holder by pressing the locking tabs in direction of the arrow ⇒ fig. 176 A and remove the bulb holder from the taillight assembly.
7. Replace the burned out light bulb with a new bulb of the same type B.
8. Reinsert the bulb holder in the taillight assembly. The locking tabs must latch with an audible “click”.
9. Attach the connector plug ⇒ fig. 175 B (2) to the bulb holder.
10. Carefully reinsert the taillight assembly into the opening in the luggage compartment lid. Hold the rear light assembly with one hand in the installation position and with the other hand, tighten the fastening screws B (3).
11. Check the taillight assembly for proper installation and secure fit.
12. Attach the cover. The cover must latch tightly and securely into place.
13. Close the luggage compartment lid
LEDs in the taillights in the luggage compartment lid
Changing LEDs is not possible without dismantling vehicle components. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
Replacing taillight bulbs in the vehicle body

Fig. 177 In the side of luggage compartment: A: Open cover of the rear side panel. B: Removing the taillight assembly.

351

Fig. 178 Taillights: A: Removing the bulb holder. B: Removing the taillight bulbs.

LEDs in the rear lights of the body
Changing LEDs is not possible without dismantling vehicle components. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
Replacing license plate light bulbs
