2012 TOYOTA SEQUOIA remote control

567
4-3. Do-it-yourself maintenance
4
Maintenance and care
■
If the wireless remote control battery is discharged
The following symptoms may occur.
●The wireless remote control will not function properly.
● The operational range is reduced.
■ Use a CR2032 lithium battery
●Batteries can be purchased at your Toyota dealer, jewelers, or camera
stores.
● Replace only with the same or equivalent type recommended by your
Toyota dealer.
● Dispose of used batteries according to the local laws.
CAUTION
■Removed battery and other parts
Keep away from children. These parts are small and if swallowed by a child
they can cause choking. Failure to do so could result in death or serious
injury.
NOTICE
■For normal operation after replacing the battery
Observe the following precautions to prevent accidents.
●Always work with dry hands.
Moisture may cause the battery to rust.
● Do not touch or move any other components inside the remote control.
● Do not bend either of the battery terminals.

672
6-2. Customization
Customizable features
ItemFunctionDefault settingCustomizedsetting
Wireless
remote con-
trol
(
P. 33) Wireless remote control ON OFF
Unlocking operation
Driver’s door
unlocked in
one step, all
doors
unlocked in
two stepsAll doors
unlocked in
one step
Automatic door lock
function to be activated
if door is not opened
after being unlocked ON OFF
Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked 60 seconds
30 seconds
120 seconds
Operation signal
(Emergency flashers) ON OFF
Operation signal
(Buzzer) ON OFF
Panic function ON OFF
Buzzer sounds when
pushing LOCK with any
door not closed ON
OFF
Your vehicle includes a variety of electronic features that can be per-
sonalized to your preferences. Programming these preferences
requires specialized equipment and may be performed by an autho-
rized Toyota dealership.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

673
6-2. Customization
6
Vehicle specifications
*: It is possible to select them only wh
en the power back door operation with the
open/close switch is made impossible when the door is locked.
Wireless
remote con-
trol
(
P. 3 3 )
Power back door oper-
ation
Push and holdPush twice*
One short push*
Power back
door
( P. 42) Switch operation Push and hold One short push
Wireless remote control
linked operation
ON
OFF
Operation signal vol-
ume OFF
ON
Operation when door
locks Possible Impossible
Time elapsed before
back door closing func-
tion is activated when
pushing switch in the
luggage compartment 1.5 seconds
0 seconds
1 seconds
2 seconds
Door lock
( P. 37) Speed-detecting auto-
matic door lock function
ON
OFF
Opening driver’s door
unlocks all doors. OFF
ON
Shifting gears to “P”
unlocks all doors. ON
OFF
Shifting gears to posi-
tion other than “P” locks
all doors. OFF
ON
ItemFunctionDefault settingCustomized
setting

696
Alphabetical index
Alphabetical index
A/C ..................................... 300, 308
ABS ........................................... 254
Active traction control ............. 254
Adaptive variable suspension system .................................... 246
Air conditioning filter............... 563
Air conditioning system Air conditioning filter .............. 563
Front air conditioning system ................................ 300
Rear air conditioning system ................................ 308
Airbags
Airbag operating conditions............................ 117
Airbag precautions for your
child .................................... 121
Airbag warning light............... 604
Curtain shield airbag operating conditions............ 117
Curtain shield airbag precautions ......................... 121
Front passenger occupant classification system ........... 127
General airbag
precautions ......................... 121
Locations of airbags .............. 114
Modification and disposal of airbags ................................ 125
Proper driving posture ........................ 112, 121
Side airbag operating conditions............................ 117
Side airbag precautions ........ 121
SRS airbags .......................... 114
Alarm ......................................... 109
Antenna..................................... 326
Anti-lock brake system............ 254
Armrest ..................................... 494
Ashtrays.................................... 480
A-TRAC ..................................... 254
Audio input ............................... 363 Audio system
A/V input port ........................ 409
Antenna................................. 326
Audio input ............................ 363
Audio visual input .................. 409
AUX port ............................... 363
CD player/changer ................ 329
DVD player............................ 392
iPod ....................................... 346
MP3/WMA disc ..................... 338
Optimal use ........................... 359
Portable music player ........... 363
Radio..................................... 321
Rear seat entertainment system ................................ 384
Steering wheel audio
switch.................................. 365
Type ...................................... 317
USB memory......................... 352
Audio visual input.................... 409
AUTO LSD system ................... 252
Automatic light control system .................................... 193
Automatic transmission .......................... 162
AUX port ................................... 363
Auxiliary box ............................ 473
A/V input port ........................... 409
AVS ........................................... 246
Back-up lights Replacing light bulbs ............. 580
Wattage................................. 655
Back door
Back door ................................ 42
Wireless remote control .......... 33
Back window ........................... 96
Battery Checking ............................... 544
If the vehicle has discharged battery................................. 634
Preparing and checking before winter ....................... 272A
B

700 Alphabetical index
Instrument panel light control .................................... 173
Intuitive parking assist ............ 220
Jack Positioning the jack ............... 622
Vehicle-equipped jack ........... 619
Jack handle .............................. 619
Keyless entry..............................33
Keys Engine switch ........................ 159
If you lose your keys ............. 633
Ignition switch........................ 159
Keyless entry...........................33
Key number .............................32
Keys ........................................32
Wireless remote control
key ........................................33
LATCH system ......................... 138
License plate lights Replacing light bulbs ............. 580
Wattage ................................. 655
Light bulbs Replacing .............................. 580
Wattage ................................. 655
Lights Door courtesy lights .............. 449
Emergency flasher switch ..... 594
Fog light switch ..................... 194
Hazard light switch ................594
Headlight switch .................... 188
Interior light switch ........451, 452
Outer foot lights ..................... 449
Personal light switch ............. 451
Replacing light bulbs ............. 580
Turn signal lever.................... 166
Vanity lights ........................... 476
Wattage ................................. 655
Load capacity ........................... 270
Lock steering column .............. 160 Luggage compartment
features .................................. 500
Maintenance Do-it-yourself maintenance ....................... 529
General maintenance............ 525
Maintenance data ................. 644
Maintenance requirements ... 523
Maintenance data..................... 524
Map holder................................ 459
Meter Accessory meter ................... 185
Instrument panel light
control ................................. 173
Meters ................................... 169
Mirrors Conversation mirror .............. 482
Inside rear view mirror ............ 84
Side mirror heaters ............... 312
Side mirrors............................. 87
Vanity mirrors ........................ 476
Moon roof ................................... 99
MP3 disc ................................... 338
Multi-information display .................................... 179
Noise from under vehicle .......... 25
Odometer .................................. 169
Off-road precautions ............... 261
Oil Engine oil .............................. 535
Opener Back door ................................ 42
Fuel filler door ....................... 102
Hood ..................................... 533
Outside rear view mirrors
Adjusting and folding............... 87
Indicator ................................ 236
Outside rear view mirror indicator ................................. 236
J
K
L
M
N
O

702 Alphabetical index
Seat heaters.............................. 489
Seating capacity....................... 270
SeatsAdjustment ........................50, 54
Adjustment precaution ......53, 64
Child seats/child restraint system installation .............. 136
Cleaning ................................ 520
Climate control seat .............. 492
Driver’s seat position memory .................................65
Head restraint..........................68
Properly sitting in the seat ..... 112
Seat heaters .................. 489, 492
Seat heaters and ventilators ........................... 492
Service reminder
indicators .............................. 174
Shift lever Automatic
transmission........................ 162
If the shift lever cannot be shifted ............................ 632
Shift lock system ..................... 632
Shopping bag hooks ............... 502
Side airbags.............................. 114
Side marker lights Replacing .............................. 580
Switch.................................... 188
Wattage ................................. 655
Side mirrors Adjusting and folding ...............87
Spare tire Inflation pressure................... 654
Storage location .................... 619
Spark plug ................................ 651
Specifications........................... 644
Speedometer ............................ 169 Steering
Column lock release ............. 160
Steering wheel Adjustment ........................ 82, 83
Audio switches ...................... 365
Climate remote control switches .............................. 315
Steering wheel memory .......... 65
Telephone switches .............. 424
Stop lights Replacing light bulbs ............. 580
Wattage................................. 655
Storage feature ........................ 453
Storage precautions ................ 268
Stuck If your vehicle becomes stuck ................................... 640
Sun visors ................................ 475
Sunshade.................................. 495
Switch BSM main switch .................. 236
Emergency flasher switch ..... 594
Engine switch ........................ 159
Fog light switch ..................... 194
Hazard light switch ................ 594
Ignition switch ....................... 159
Light switches ....................... 188
Power back door switch .... 33, 43
Power back window switch ..... 96
Power door lock switch ........... 37
Power window switch .............. 93
Rear window wiper and washer switch ..................... 200
Seatback folding/returning switch.............................. 57, 63
Window lock switch ................. 93
Wiper and washer switch.......................... 196, 200

704 Alphabetical index
Warning messages .................. 613
WasherChecking ............................... 547
Preparing and checking before winter ....................... 272
Switch............................ 196, 200
Washing and waxing ............... 518
Weight Cargo capacity ...................... 266
Load limits ............................. 270
Towing capacity .................... 645
Trailer Weight Rating .... 281, 645
TWR .............................. 281, 645
Vehicle capacity weight ......... 645
Weight ................................... 645
Wheels ...................................... 560
Window glasses ..................93, 96
Window lock switch ...................93
Windows Power back window ................96
Power windows .......................93
Rear window defogger .......... 312
Washer .......................... 196, 200
Windshield wiper de-icer......... 314
Windshield wipers ................... 196
Wireless remote control key Replacing the battery ............ 566
Wireless remote control ..........33
WMA disc .................................. 338
